HOSE CONNECTIONS
1. 1. Connect a 2-inch hose to the discharge port on the
pump as shown in Figure 6. Make sure that the hose
is attached correctly to the discharge port.
ATTACHING LIFTING ROPE
1. Attach a suitable lifting cable (rope) to the carrying
handle (Figure 6) on the pump and lower the pump
into place. For applications where there is an excessive
amount of mud, grit or silt, the use of a support platform
is desirable. When pumping water from applications
where there is little or no debris, the support platform
is not required.
Figure 6. Submersible Pump Upright
Position(Correct)
2. Make sure the pump is always placed in an upright
position, not tilted (Figure 7). Never position the pump
directly on a soft, loose bottom. Remember to attain
maximum pumping capacity and prevent excessive
wear, position the pump so it will not burrow itself into
sand or clay.
PAGE 14 — ST2037F/2040TF SUBMERSIBLE PUMP • OPERATION AND PARTS MANUAL — REV. #3 (12/14/17)
Figure 7. Submersible Pump Upright Position
(Incorrect)
3. If all of the pump's electrical requirements have been
met, place the circuit breaker or power ON/OFF switch
in the ON position.
4. Wait a few seconds and water should begin to flow
from the discharge hose.
5. If water is not flowing from the discharge hose or not
flowing freely after a few minutes, remove the power
from the pump and check the system for leaks.
6. To stop the pump from pumping, place the circuit
breaker or ON/OFF switch in the OFF position.
DANGER
NEVER grab or touch a live power
cord. DO NOT stand in water when
connecting the pump's power cord into
a voltage source. The possibility exists
of electrical shock, electrocution and
possibly death!

OPERATION
