MULTIQUIP ST2037F Operation And Parts Manual page 22

NO. PART NO.
1 020S500UL001
3 020S500UL003
4 020S500UL004
5 020S500UL005
7 020S500UL007
34 020S2037034
53 020S500UL053
60 020S500UL060
65 020S500UL065
67 020S500UL067
74 020S500UL074
102 0202005A102
103 0201503A103
119 020S2047119
120 0202037F120
121 0201503A121
121-1 0202037F1211
123 0202037F123
125 0201503A125
127 0202037F127
129 020S2047129
131 020S2047131
145 0202037F145
146 020S500UL146
157$ 020S2047157
170 020S500UL170
174 020S2037174
214 020S500UL214
224 0201503A224
236 0202037F236
238 020S500UL238
265 011008020
299 020S500UL299
300 020S500UL300
358 020S500UL358
358-1 020S500UL358
431 020S500UL431
444 020S500UL444
444-1 0202037F4441
445$ 020S2047445
446$ 020S2047446
829 020S500UL829
830#
830-1#
893 020S500UL893
894 020S500UL894
895 020S500UL895
896 020S500UL896
918 020S500UL918
ST2037F/2040TF SUBMERSIBLE PUMP • OPERATION AND PARTS MANUAL — REV. #3 (12/14/17) — PAGE 23
PART NAME
CASING
IMPELLER
IMPELLER NUT
SPRING WASHER
CASING COVER
SCREW
WASHER
MECHANICAL SEAL
PLUG
PACKING
PACKING
DISCHARGE PORT
PACKING
MOTOR ..................................................................1............INCLUDES ITEMS W/ $
AC CORD W/CORD GLAND .................................1............W/ FLOAT SWITCH
CORD CLAMP .......................................................1............REPLACES P/N 0201503121
CORD CLAMP
CHAIN
SCREW ..................................................................2............REPLACES P/N 0201503125
CARRYING HANDLE
FRAME COVER
BOLT
SET PIECE
STRAINER
PACKING
IMPELLER NUT CAP
OUTER PIPE
PACKING
PLUG .....................................................................1............REPLACES P/N 0201503224
S-TIP
SPACER
BOLT ......................................................................2............REPLACES P/N 020S500UL265
BOLT
WASHER
AC CORD BAND
FLOAT CORD BAND
NUT
SCREW
SCREW ..................................................................1............INCLUDES ITEMS W/ #
CAPACITOR
THERMAL PROTECTOR
WASHER
NUT
NUT
SEAT
V-RING
LINER
SCREW
STIRRER
ST2037F PUMP ASSEMBLY
QTY. REMARKS
1
1
1
1
1
3
1
1
1
1
1
1
1
1
1
1
1
3
1
1
1
1
1
1
1
3
3
3
1
1
2
1
1
1
2
1
1
1
1
1
3
1
