THIS MANUAL IS PART OF THE PRODUCT. READ IT
CAREFULLY IN ORDER TO USE AND MAINTAIN THE
EQUIPMENT CORRECTLY.
IT IS IMPORTANT TO KEEP IT FOR FUTURE
TROUBLESHOOTING AND REFERENCE.
WARNING
This machine is intended for use in domestic and similar applications such
as kitchen areas for staff in stores, offices and other work environments,
rural accommodation and hotels, motels and other residential-type
environments, bed and breakfast environments, catering services and
similar non-retail applications.
The installation of this equipment should be done by the Technical
Assistance Service department.
The socket should always be placed on an accessible location.
When positioning the appliance, ensure that the power cable is not trapped
or damaged.
Do not place multiple portable socket outlets or portable power sources in
the rear of the appliance
ALWAYS disconnect the power supply from the machine BEFORE any
cleaning or maintenance service.
Any change needed on the electrical installation for the appropriate
connection of the machine, should be exclusively performed by qualified
and certified professional personnel only.
Any use by the ice maker not intended to produce ice, using drinking water,
is considered inappropriate.
It is extremely dangerous to modify or intend to modify this machine and
shall make any type warranty void.
This device is not intended for use by persons (including children) whose
physical, sensory or mental capacities are limited, or who lack sufficient
experience or knowledge, unless they are acting under the supervision of
or have received instruction regarding proper use of the device from a
person responsible for their safety. Children should be supervised to
ensure they do not play with the device.
Children should be monitored to assure that they should not play near the
equipment.
This machine is not intended to be used outdoors nor exposed to the rain.
Connect the equipment to the drinking water network. See section 3 of this
manual.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ITV NG R290
Summary of Contents for ITV NG R290
- Page 1 THIS MANUAL IS PART OF THE PRODUCT. READ IT CAREFULLY IN ORDER TO USE AND MAINTAIN THE EQUIPMENT CORRECTLY. IT IS IMPORTANT TO KEEP IT FOR FUTURE TROUBLESHOOTING AND REFERENCE. WARNING This machine is intended for use in domestic and similar applications such as kitchen areas for staff in stores, offices and other work environments, rural accommodation and hotels, motels and other residential-type environments, bed and breakfast environments, catering services and...
- Page 2 The machine should be connected using the power cable supplied with the equipment. The connection is not intended for fixed cabling. This appliance uses flammable refrigerant (propane), stored in the unit's refrigeration circuit. For this reason, the following precautions should be followed: •...
- Page 3 of damages, contact your distributor. We recommend to always use original replacement and spare parts. Perform all discharge and recovery of materials or waste according the national regulations in force. RECEPTION OF THE MACHINE Inspect the outside packing. In case of damages, MAKE THE CORRESPONDING CLAIM TO THE CARRIER.
- Page 4 not obstruct the front grille with any objects. The unit can operate embedded, but with a reduction in output. In case the front louver is not enough, the exit is either total or partially obstructed or due to its placement it will receive hot air from another device, we recommend, in case it is not possible to change the location of the machine, TO INSTALL A WATER COOLED UNIT.
- Page 5 Water and Drainage Water quality has a remarkable influence on the appearance, hardness and flavor of the ice as well as, on the machines condensated by water, on the life of the condenser. Connections to the Water Network Use a flexible pipe (1.3 m – 4.27 feet length) with the two filter joints supplied with the machine.
- Page 6 damaged, it should be replaced by a cable of special assembly to be furnished by the manufacturer or post-sale service. Such replacement should be performed by qualified technical service only. The machine should be places in such a way as to allow a minimum space between the back and the wall to allow an easy access and without risks to the cable jack.
- Page 7 CAUTION: INSTRUCT THE USER ABOUT MAINTENANCE, INFORMING THAT MAINTENANCE AND CLEANING OPERATION AS WELL AS DAMAGES DUE TO THE LACK OF SUCH OPERATIONS: ARE NOT INCLUDED ON THE WARRANTY. MAINTENANCE AND CLEANING INSTRUCTIONS CAUTION: Maintenance and cleaning operations and damages as the lack of those activities: Are not included on the warranty.
- Page 8 2) Remove the louver of ice drop. (Clean as done with the curtain). 3) PULL THE COLLECTOR UPWARDS. IT IS PRESSURE MOUNTED. 4) Disassemble the nozzles and lids and clean them. 5) Disassemble and clean the main head filter. (IT IS PRESSURE MOUNTED). 6) Assemble the filter, nozzles and collector.
