BNC-26N Straight Connector for 0.6/2.8 Cables
Specifications
ELECTRICAL
Characteristic Impedance:
Voltage Rating:
Insertion Loss:
Return Loss:
Contact Resistance:
Insulation Resistance:
MECHANICAL
Mechanical Durability:
Center Contact Retention:
Coupling Mechanism:
Cable Pulloff Force:
Cable Bend and Twist:
Force to Engage/Disengage:
Interface Dimension:
ENVIRONMENTAL
Thermal Shock:
Moisture Resistance:
Corrosion (Salt Spray):
Flammability:
Vibration:
Solvent Resistance:
FINISH
Body/Bayonet:
Center Conductor:
0
-5
-10
-15
-20
-25
-30
-
-35
-40
-45
-50
w w w . a d c . c o m
75 Ohm
1000 Volts RMS
< 0.6 dB 1 MHz to 1 GHz (measured with 1 meter of 728 cable)
Better than 35 dB to 1 GHz; 30 dB to 2 GHz; 26 dB to 3 GHz
0.30 Ohm maximum change post environmental
200 megaohms minimum change
500 cycles minimum
6 lbs minimum
100 lbs minimum
Dependent on cable size
500 cycles minimum
Torque 2.5 in/lb maximum; longitudinal force 3 lbs maximum
MIL-C-39012 75 Ohm interface
-40 °C to 65 °C operating; -55 °C to 85 °C non-operating
0% to 95%; MIL-STD-202 Method 106
MIL-STD-202 Method 101, Test Condition B
UL94-VO rated (center conductor insulator)
MIL-STD-202 Method 201
MIL-STD-202 Method 215
Tarnish-resistant electroless nickel plating
5 0 millionths inch gold plating MIL-G-45204 Type 1, Grade C,
Class 1; requires 0.42" crimp station die
.035"
.0303/.040"
Typical Gated Return Loss
FREQUENCY (MHz)
•
+ 1 - 9 5 2 - 9 3 8 - 8 0 8 0
.675"
.278"
•
