Specifications - ADC DS1 VDSL-Grade Transport System Cable 103326AE Specification Sheet

DS1 VDSL-Grade Transport System Cable
26 AWG STC, Shielded, Riser
Compliances:
• UL Subject 444/CSA C22.2 No. 214
• (UL)-C(UL) Type CMR/CMG
• NEC 800 Type CMR

Specifications

CONSTRUCTION CHARACTERISTICS
Conductors:
Insulation:
Insulation diameter:
Pairing:
Color-coding:
Shielding:
Drain wire:
Rip cord:
Inner jacket:
Outer jacket:
ELECTRICAL CHARACTERISTICS
Conductor DC resistance @ 20°C (maximum):
Resistance unbalance (maximum):
Mutual capacitance:
Capacitance Unbalance Pair to Ground (maximum): 800 pF/1000 ft (262 pF/100m)
Characteristic impedance:
Temperature rating:
Voltage rating:
Frequency
(MHz) (dB/100m) Typical
0.772
1
4
8
10
16
20
25
31.25
62.5
100
w w w . a d c . c o m
Attenuation Return Loss
(dB Minimum)
2.3 19.4
2.7 20.0
5.3 23.0
7.6 24.5
8.4 25.0
10.6 25.0
11.6 25.0
12.8 24.3
13.9 23.6
19.1 21.5
24.2 20.1
• + 1 - 9 5 2 - 9 3 8 - 8 0 8 0
26 AWG solid tinned copper (.0159")
Polyethylene
0.76 mm (.030") nominal
12 twists per foot (min.)
Standard Telephony, solid colors
Aluminum/polyester foil, face in, 25% overlap
24 AWG solid tinned copper
Applied under jacket
Lead-free, flame retardant PVC
Lead-free, flame retardant PVC
46.1 Ω/1000 ft (15.12 Ω/100 m) @ 20°C (68° F)
5%
20 pF/ft (6.6nF/100 m) @ 1 kHz
100 +/- 15Ω
75°C (167° F)
300 VDC
PSNEXT PSELFEXT
(dB Minimum) (dB Minimum)
64.0 63.0
62.3 60.8
53.3 48.8
48.8 42.7
47.3 40.8
44.2 36.7
42.8 34.8
41.3 32.8
39.9 30.9
35.4 24.9
32.3 20.8
• 1 - 8 0 0 - 3 6 6 - 3 8 9 1
PSFEXT
(dB Typical)
67.0
65.4
55.8
51.8
50.6
48.6
47.8
47.2
46.3
45.3
45.0
3
