Summary of Contents for HiWeigh PCP
-
Page 3: Table Of Contents
CONTENT Safety First ........................3 About warning and cautionicons ..............3 Warning........................ 3 Power plug and AC outlet................. 4 Caution......................... 4 Summarize ........................5 External view....................... 5 Display........................6 Standard keyboard layout ................. 6 indicator ....................... 7 Name and function of the key................7 Capability ...................... -
Page 4: Safety First
Congratulations on your choice of an PCP Series Price Computing Label Scale, designed to give you many years of service. 1 Safety First To use this product safely and correctly, read this manual thoroughly and operate as instructed. After reading this guide, keep it close at hand for future reference. -
Page 5: Power Plug And Ac Outlet
4. Never try to open the scale apart or modify it in any way. High-voltage components inside the scale create the danger of fire and electric shock. 1.3 Power plug and AC outlet 1. Use only a proper AC electronic outlet: 190V ~ 250V; Temperature: -10°C~ +40°C;... -
Page 6: Summarize
2 Summarize 2.1 External view... -
Page 7: Display
2.2 Display 2.3 Standard keyboard layout... -
Page 8: Indicator
2.4 indicator Indicator Scale current status AUTO Under Auto-print status LOCK The current product is locked ZERO No weighing or weight=0 STABLE Label scale operating stably TARE “TARE” key is pressed SHIFT “SHIFT” key is pressed 2.5 Name and function of the key Function NUMERIC Number and letter entering... -
Page 9: Capability
2.6 Capability Parameter Specification 3Kg—20g—1g Maximum division of Singular division 6Kg—40g—2g weighing -detection: 5Kg—100g—5g MAX-MIN-e 6/15Kg—40g—2/5g (scale with Double division 15 Kg maximal weighing) 15/30Kg—80g—5/10g (scale with 30 Kg maximal weighing) Precision 1/3000 F. S NAME 20 Bits WEIGHT LCD Display UNIT PRICE TOTAL PRICE UNIT... -
Page 10: The Main Functions Of Products And Features
times around the spool shaft, and then use U-pin to lock it. 7. Put down the printer head and lock it. 8. Close the printer side cover. 9. Turn on the power, press [feed key] to feed the label to correct print position. Note Load the label through the paper chute correctly and adjust the width of paper chute to the label. -
Page 11: Sales Operation
Sales Operation 3.1 Inspection before usage 1. Switch on the scale. 2. To ensure that the level hole is clean. 3. Anything on the scale pan should be cleared up. 4. Adjust the scale feet until the level bubble showing adjustment to the horizontal. -
Page 12: Change The Price Sales
3.4 Change the price sales (Attn: Open PLU mus t be set as “PRICE CHANGEAB ” during programming.) Enter the new price, press the “PRICE”. 3.5 Sale in Package Enter package quantity, Press the “PACKAGE”. Note when quantity is“1“, direct key sales. 3.6 Coupon selling 1. -
Page 13: Programming Basic Data
5 Programming Basic Data 5.1Setting label and scale 1. In the Programming interface, enter [2]. It displays label and scale setting interface. 2. Enter the Scale Number (0 -99).Press the “OK”. 3. After setting, and so on. Note: T ype of label code POS code + Sales amount not round Kopeck POS code + Weight... -
Page 14: Programming
6 Programming 6.1 Setting PLU 1. Under the programming interface. 2. Enter [3], It displays PLU setting interface. 3. Enter PLU (e.g. PLU = 1), press the “OK”. 4. Enter product name Using ? and ? to shift the input method 0 for numeric; 1 for small letter; 2 for capital letter Enter letter, Press the “OK”... -
Page 15: Editing Letter String
Editing letter string 1. Under the programming interface, Enter [14], Enter number letter string (1 -8). Press the “OK”. 2. Enter letter string (maximal 24 letters). When finish, Press the “OK”. Setting is finished with a “BEE” sound. Editing label code Under the programming interface ,Enter [16], Enter number of label editing (1-32) -
Page 16: Sales And Label Report
Setting whether to print (0=: not to print, Others: pint) e.g. Whether to print= [0] Press the “OK” to enter next printing setting After setting, and so on. 7 Sales and Label Report Under the programming interface, Enter [4], It shows current date (year-month-date): 20131203. -
Page 17: Getting Information Of Version
It shows the printer testing interface, Enter [1]. To do a testing printing. Print a black-and-white pattern. Getting information of Version Under the programming interface ,Enter [7], It shows current software version: [1.110-090416]. Press the “OK” to return to upper level submenu. If need to return to programming interface, Press the “DLR”. -
Page 18: Troubleshooting And Technique Support
10 Troubleshooting and Technique Support Before you inform the technique representative, you may refer the error to the following list. Many questions occur do not because of the quality of the product rather a simple incorrect operation. Eorrors Discription ERROR-0 Invalid error number ERROR-01 Invalid PLU code... - Page 19 Name 3 PLU Code 4 Price 5 Weight 6 Amount after discount 7 Label code 8 Date 9 Effective days 10 Frame 11 Time 12 Amount before discount 13 Expiry date Discount rate 15 Title 1 16 Titlle 2 17 Title 3 18 Title 4 19 Title 5 20 Title 6...
- Page 20 Annex B. Default system parameters Setting parameters Volume Discription Sacle No. Label width 448 x 0.125mm = 56mm Label height Label internval space Printing greyness Label paper peel check Check label paper peel PLUS printed in the center Plu in the center Label code type Code + Sales amount (Not rounding Kopeck)
