Summary of Contents for HiWeigh PH
- Page 3 Warning Ask professional personnel to debug, detect and repair controller. Warning Warning Please keep good grounding of controller. In electrical connection of controller, please cut off the power supply in advance. Wait for 30 seconds between power-on of the controller for 2 times. Pay Attention to Static Electricity The controller is a device sensitive to static electricity, thus please take anti-static precautions in use and maintenance.
-
Page 4: Table Of Contents
Contents TECHNICAL INDICATORS ....................... 3 MAIN FUNCTION ........................3 BOUNDARY DIMENSION ...................... 3 INTRODUCTION TO PANEL ....................4 PARAMETER SETTING ......................5 ..........................5 ETTING ENTRY F1 Parameter Setting of Sca .................... 5 ..................7 PPLICATION UNCTION ETTING ................8 NERGY SAVING ARAMETER... -
Page 5: Itechnical Indicators
I Technical Indicators ● 6-digit 1.2-inch LED display, 7 state indicator lamps. Long service life and shock resistance ● 7 function keys. Operation is simple and convenient ● Protection level: IP5x ● Excitation voltage: +5VDC ● Load capacity of sensor: at most 4 350Ω simulation sensors ●... -
Page 6: Introduction To Panel
IV Introduction to Panel ● Introduction to indicator lamps Identificati Analysis Remark The lamp is on when scale is in dynamic state, otherwise, the Dynamic and static indication lamp is off The lamp is on when the absolute value of weight on the scale Zero center indication is less than ±0.2d, otherwise the lamp is off Identification of gorses weight and... -
Page 7: Parameter Setting
Skin removal key Short key → net weight turns to gross weight; Flicker bit is on the right. induction lamp of net weight “Net” is off. Skin removal key Short key →gross weight turns to net weight. Digit flicker position Indication lamp of net weight “Net”... - Page 8 Selectable parameters: 1 (default value), 2, 5, 10, 20, 50 F1.4 Calibration Unit Selectable parameters: 0 ---- kg (default value) 1 ---- lb F1.5 Gravitational Acceleration Selectable parameters: 9.7000069.99999. Default value = 9.79455. F1.6 Null-point Calibration Keeping empty the scale Remove the weights on the weighing platform to guarantee the scale is in the empty state.
-
Page 9: F2 Application Function Setting
1 ---- Moderate Filtering (default value) 2 ---- Severe Filtering F1.12 Steady Range Selectable parameters: 1 d, 2 d, 3 d (default value) F1.13 Overload Display Range Selectable Parameters: 9d, 5% (default value), 10%, 20% F1.14 F1 Menu Protection Selectable Parameters: 0 ---- Enter F1 menu by keyboard operation 1 ---- Enter F1 menu by pressing the calibration button F1.15 Restoring Factory Default... -
Page 10: F3 Energy-Saving Parameter Setting
Selectable Parameters: 0 ---- Access to Platform Weighing (default value) 1 ---- Manual Input Access F3 Energy-saving Parameter Setting F3.1 Time-out Screensaver Time Setting Selectable Parameters: 0~ 99 minutes, (default value: 30 minutes) If set to be 0, this function shall not be allowed. During the screen protection, the display will randomly show “... -
Page 11: F5 Maintenance And Service
8_O_1 ---- 8-pit even parity check F4.1.3 Baud Rate Selectable Parameters: 1200, 2400, 4800, 9600 (default value) F4.1.4 Continuous Output & Delivery Parity Check and Character (only for F4.1=3) Selectable Parameters: 0 ---- no delivery (default value) 1 ---- delivery F4.1.5 Bluetooth Node Setting (effective only when Bluetooth module option is configured) Selectable Parameters: xxxxi01~xxxx99 (default value: xxxx01) -
Page 12: Function Description
VI Function Description ● Weight maintenance function F2.1 = 1 Operation method In normal weighing state, press Hold on the operation panel, the will instrument lock display weight of the current scale, and “Hold” indication lamp is on. Only when weight setting value≥F2.2 is displayed, weight maintenance operation is effective. -
Page 13: Prompt Message Of Instrument
dynamic state. Adjustment, clearing and printing of accumulated value In normal weighing state, press Total on operation panel for more than 2 seconds, the display will show for a second, and then the display shows current total accumulated value and flickers. To clear accumulated value, press Zero , to make flicker weight be 0. -
Page 14: Appendix 1. Continuous Output Format Specification
Remove weight. Invalid operation Press Print reprint factory value. Start up again. If the information occurs again, return to factory for repair. Please calibrate the scale EEPROM checksum and error again if the situation does not occur; Attention: this place is provided with all parameters of instruments of the factory. - Page 15 5. <CR> ASCII carriage return (ODH) 6 <CKS> optional checksum and (no output in F4.2.3 = 0) Status word: A, B, C. Status word A Bit 0 Bit 1 Bit 2 Position of decimal point XXXXXX XXXXX.X XXXX.XX XXX.XXX XX.XXXX Bit 3 Constant 0 Bit 4...
-
Page 16: Appendix 2. Printing Format Specification
Net weight of 15.000kg Gross weight-15.000kg w w - Note: the above position of the decimal point is determined according to that in the instrument. 3. Continuous output B format Continuous output agreement B format: HEAD1 , HEAD2 , DATA UNIT CR/LF HEAD12OL... - Page 17 REPORT ---------------------- 25.000kg Status Hold F2.1 = 3 selection, check weight, press Print : REPORT REPORT REPORT ----------------------- ----------------------- ----------------------- Gross 1.980kg Gross 2.000kg Gross 2.020kg State Less State State Over Underweight Qualified Overweigh F2.1 = 4 accumulation scale, print detailed statement or format of total weight: Print details and total weight Only print total weight REPORT...
- Page 18 APPENDIX 3 GUIDE TO SAFE OPERATION For safe operation of the truck, please read all warning signs and instructions here and on the truck before using this truck. Do not operate the pallet truck unless you are familiar with it and have been trained or authorised to do so. Do not operate the truck unless you have checked its condition.
- Page 19 Figure 1...
- Page 20 WIRING DIAGRAM OF JUNCTION BOX Connect meter connector Connect sensor connector L0 － L1～L4 silver silver white white －S －S green green ＋S ＋S black black －E －E ＋E ＋E...
