- Page 3 Please read the manual in details Please use the right plug and right voltage before operation Be much attention of 110V or 220V!!! Don’t clean the indicator with the Avoiding the insects in for protecting PCB Flush water and other electronic components Don’t touch the keypad with the Don’t open the indicator by yourself and Items with sharp end...
- Page 4 I. Technical Parameter 1.A/D Conversion: ∑-⊿ 2.Input Signal Range: 0-10mv 3.A/D Resolution: 1,000,000 4.A/D Conversion Speed: 10times/second 5.Excitation Voltage: DC5V Excitation Current: (4) 350 Ohm load cells or (8) 700 Ohm load cells 6.Display: 18 digits LCD 0.8” 7.Divisions: 1/2/5/0.1/0.2/0.5/0.01/0.02/0.05/0.001/0.002/0.005/10/20/50/100/200/500 8.Serial Output Interface: RS—232 continuous transmitting, Baud Rate 1200 2400 4800 9600 optional...
- Page 5 III. Keypad & Signs ON, Keep pressing for OFF Clear, Keep pressing for ZERO SET, Memory unit set Memory retrieve, Keep pressing Kg/Lb M+(accumulation), printing Tare, Keep pressing for preTare set : digits …… Display: The 1 line---weight value The 2 line----unit price or unit weight The 3 line----total amount or quantity...
- Page 6 3. Press to confirm and enter next step Step Operation Display Note UEr10.0 Press Switch on and then press EnSEt CLoCK EnSEt Means parameter setting and calibration allowed (CLoCK is plus model with clock) 000000 Self-Checking … 999999 ------ Needs password Press Input 2003 and press to enter parameter setting...
- Page 7 Ones place digit (the 0 of 10) represents the option of Press automatically power off function or not. AutP Ones place 0:No automatic power off function Ones place 1:Automatic power off Tens place digits (the 1 of 10) represents zero tracking Press 1 range (1~9): Press 1...
- Page 8 n LOAd Zero Calibration Press xxxxxx A/D internal code CAL 0 xxxxxx Make sure no ------ Displays the full scale value after object on CAL 0 several seconds of finish of zero ------ platform and calibration then press Put the full LOAd Prepare for full scale calibration scale weight...
- Page 9 following steps (ASCII code table refer to appendix at last page) Step Operation Display Note Pressing 1 for Input start 2 seconds more Press 6 The ASCII code of A is 65 A entered Press Press 7 A7 Input Press Input B Press to backwards and input...
- Page 10 1-- The present chosen words/sentence printing at end 2-- The present chosen words/sentence printing at head, the following sentence printing at end (such as words/sentence chosen of [2] now, the words/sentence of [2] will be printed at head and the sentence/words of position [3] will be printed at end. 7.
- Page 11 Printing example: Price computing Counting 0018 0018 1926.72Kg 6215.72Kg 2369.87$ 891213p 10.Price computing/Counting exchange: Press and then keep pressing for 2 seconds or more can exchange the mode of price computing or counting, the P light means price computing and C light means counting 11.
- Page 12 When the battery is over, the 1 window displays and 2 window displays bAtt the indicator will power off automatically 16. Power saving: When the automatic power off function work, it will display only to save power if 5 minutesno operation 17.Automatic power off: When the automatic power off function work, it will power off automatically if 30 minutes no operation...
- Page 13 APPENDIX (ASCII CODE) LETTER display ASCII LETTER display ASCII LETTER display ASCII LETTER display ASCII Number digits can be input by number keys and also can be input by ASCII code 0-9 with ASCII code of 48-57...
