Summary of Contents for Osaki Pro Maestro
- Page 1 Instruction Manual Osaki Pro Maestro...
-
Page 3: Table Of Contents
Contents Important safety instructions ……………………..…….......... Product parts ………………………………………..……............ Before use ……………………..……..................The controller instructions ……………………..……..........Operation guide ……………………..……................ After massage ……………………..……................Cleaning and maintenance ……………………..……..........Q & A ……………………..……....................……………………..……................ Troubleshooting Specification ……………………..……................ -
Page 4: Important Safety Instructions
Any person with a pacemaker of medical device can not use this product. The chair produces an ual physical discomfort during usage of the chair immediately stop using the re is abnormal discomfort after using the chair, contact your physician and refrain from using the chair unless recommended by your physician. is replaceable it, has no signs of damage or tears, to avoid from damaging the roller head... - Page 5 sounds. Do any cushions or obstructions between the backrest pad and the backrest. This may lead to damaging the mechanism and personal injury. When moving or handling the chair , be sure to grab from its frame and the recommended grabbing When massaging the neck area, be attentive to the intensity of the massage to make sure that it is not applying to much pressure which may aggravate neck muscles or nerves.
- Page 6 ・The following persons (even if they are physically healthy at present) should consult a physician before using the product. (1) Persons with muscular atrophy due to aging or below normal weight; (2) Persons feeling lumbago (pain in the muscles and joints of the lower back) because of bone or viscus problems;...
- Page 7 Do not put hands or feet between footrest and seat base. Do not put hands or feet between footrest and side panel. Do not put hands or feet between seat base and side panel. Do not put hands or feet between upper and lower part of the footrest. Do not put hands or feet in the gap of seat base.
- Page 8 If the power plug is damage,it must be replaced by a special plug available from Osaki or an authorize agent .
-
Page 9: Product Parts
Bluetooth Speaker Pillow Shoulder OSAKI Logo Armrest Back Cushion Controller Side Panel Controller Side Panel Seat Pad Footrest... - Page 10 2 Air bags 12 Air bags 6 Air bags...
-
Page 11: Before Use
Before use Make sure there is enough space to recline the chair and for the user to get in and out of the chair freely. PLEASE MAKE SURE TO USE A MAT OR RUG UNDER CHAIR IF YOU PLACED ON TOP OF A HARD SURFACE LIKE HARWOOD AND CERAMIC FLOORS. - Page 12 Do not put hands or feet between footrest and seat base. Do not put hands or feet between footrest and side panel. Do not put hands or feet between seat base and side panel. Do not put hands or feet between upper and lower part of the footrest. Do not put hands or feet in the gap of seat base.
- Page 13 Be sure the power cord is firmly and completely inserted into the power outlet. 110-120 backrest in the retracted position, press "ON" button to bring back to the default position.
- Page 14 Inspect the synthetic leather portian in which Before use, raise the back cushion and check the massaging rollers travel along the backrest. whether fabrics lining pointeddout in the Be sure there is no damage or unusual ware. figure are undamaged. (Even if the fabric is slightly damaged,stop the product immediately,pull out the power plug and send notify the manufacturer for a...
-
Page 15: The Controller Instructions
The controller instructions Power switch on the top of controller ON /OFF button Touch screen The touch keys AUTO 1. Power switch on the top of controller ON /OFF button Press this button to start massage chair.Touch any massage function icon to start massage. - Page 16 3. The touch keys Main page: When starting the chair, touch this key can change the screen between main page and massage page. Reset: Once this key is touched, Position: Once this key is massage chair will return to its touched the screen will change original possition，while the AUTO...
-
Page 17: Operation Guide
Operation guide 1. Neck & Shoulder Touch this icon，the screen will change to the page [Neck & Shoulder] There are 4 auto massage programs, if 1 of 4 auto program is activated，chair will automatically perform a shoulder hight scan.The screen will that the [Shoulder scanning] is being conducted. - Page 18 2. Lower back Touch this icon，the screen will change to the page [Lower back] There are 4 auto massage programs. Select 1 of 4 auto program to start the preset program. 3. Auto Touch this icon，the screen will change to the [Auto] page. There are 8 auto massage programs.
- Page 19 NOTE: (1) 4D Intensity: There are 8 different levels available for adjustment to suit various massage strength. In Auto programes, users can adjust 4D intensity instead of Strength and Speed. Strength and Speed will be locked for better massage experience. (2) Air Intensity ：...
- Page 20 NOTE: (1) 4D Intensity: There are 8 different levels for the 4D intensity. In massage mode, the intensity will set to default. (2) Intensity / strength / speed: There are 5 different levels for adjustment. (3) Upward / downward: When pressing the [Spot] button, it will freeze the massage rollers from moving up or down, concentrating the massage at that point.
- Page 21 NOTE: Heating: The heated rollers will automatic activate in the auto program.Touch this icon to turn off the roller heat. Touch again to activate it. Fast pump: To dispaly the various airbag massage program on the arms and waist select the [air massage] to select the region and intensity.
- Page 22 Control Buttons on the side panel USB mobile phone charger Power: ON /OFF button Z-G: A key to start Zero gravity position AUTO 4D +/- : 4D Intensity adjustment Auto: A key to start demo auto program Pause: Massage function pause/start button...
-
Page 23: After Massage
After massage Turn off the power switch on the controller. Pull the power switch to “O” position. Pull out the power plug. After using, it is recommended to put the power switch to the OFF position and pull out the power plug; otherwise accidents and injuries by playing with them by children may happen. -
Page 24: Cleaning And Maintenance
Do not clean the product with solutions containing chemicals such as thinners, gasonline and alcohol. Be sure that leather cleaner will not harm the synthetic leather by reading the label. Wet a soft cloth into water or 3% to 5% neutral detergent containing hot water and wring it out. -
Page 25: Q & A
Can someone with a medical condition or disease use this product? It is located at behind the backrest They must consult with their physicians at the back of the chair by the before using the product. power cord. Massage can aggravate or worsen muscle injuries, bone disease, spinal abnormalities, skin disease and kill ones with medical devices implanted in their body. -
Page 26: Troubleshooting
If an issue occurs, inspect and trouble shoot according to the corresponding method below. If the problem is not resolved, contact the manufacturer for further instructions or service. As a safety protocol the massage heads will stop if pressure/weight load has exceeded its limit. To avoid potentially over heating or damaging the massage mechanism the chair is designed to automatically shut off if over strained or over heated. - Page 27 Expected sounds and feelings when using the massage chair. You will hear or have the following feelings when using the product. These not defective indicators but a normal function of the chair. When chair extends or retracts you will hear gears moving an clicking.
-
Page 28: Specification
Model Osaki Pro Maestro Rate Voltage 110 -120V 60Hz Power 250W Working time 15min Guide L Shape 52.8" Forward distance 8 level Approx 3.9" Massage Strength 5 level Roller Speed 5 level Airbag Intensity 5 level Backrest Approx 128°- 155° (Ground Angle)
