ERA Protect SALAPWHESSU Installation And Operating Manual

BATTERY OPERATED WIRELESS SIREN
1. OVERVIEW
The ERA Protect Siren is a battery operated wireless
Siren that works with the ERA Protect Alarm System.
The Siren is a visual deterrent and has flashing comfort
lights to show potential intruders that it is a live siren.
When the Alarm is triggered, the Siren will sound at
104dB and the strobe will flash.
2. GET TO KNOW YOUR
PRODUCT
Front Cover
Reset
Button
Comfort
LEDs
Cover Screw
3. INSTALLING AN
ACCESSORY
Add Device to app.
1.
Place the protect tamper sleeve provided over the
2.
tamper switch at the back of the siren before installing
onto the wall.
Place in required position.
3.
The Tamper function is disabled for 15 minutes after
4.
power up to allow for installation. After 15 minutes the
Tamper will become enabled, if the siren is removed from
its position after this point the alarm and siren will be
triggered.
Note: Accessory Tamper Switch is disabled to allow easy
installation.
ERA Home Security Ltd.
Valiant Way, Wolverhampton,
West Midlands, WV9 5GB.
Email: support@eraprotect.com
Web: www.eraprotect.com
Screw
Tamper
Bayonet
ABS Plastic Feet
CUSTOMER HELPLINE
0345 257 2500
INSTALLATION AND
OPERATING MANUAL
ADD DEVICES
4.
Once your hub is set up you will be taken to your Protect
home screen.
To add a device press the Add ( + ) button in the top right
hand corner and select Add Device.
Follow the on-screen instructions to add your device. Repeat
as necessary for each device you would like to add. You can
add sensors in any order.
Once all devices have been added please check the Protect
Hub settings page, accessible via the side bar menu (
ensure all devices are listed and displayed correctly.
5. WIRELESS OUTDOOR
SIREN INSTALLATION
Using the drilling template mark up the mounting holes
1.
required to be drilled.
Drill the marked holes where you will place your wall
2.
plugs.
Model: SALAPWHESSU
), to
