8. Adding Paper and Ink
Names of the parts of the paper holder
1
3
1. Left flange
2. Spool
3. Paper roll adjustment levers
4. Right flange
5. Lock lever
Paper roll direction
When loading the paper roll to the paper holder and machine, make sure that the edge of the
paper feeds from top of the roll toward the front.
1. Right flange
You can load the paper roll into Paper Input Locations 1 and 2. Each paper input location is loaded in
the same way. In the following example procedure, the paper roll is loaded into Paper Input Location 1.
1. Press [Home] (
2. Press the [Copy] or [Printer (Classic)] icon.
Make sure that "Ready" appears on the screen.
142
2 3
5
1
) at the bottom of the screen in the center.
4
