Power Supply

The recommended power adapter is EMSA050300-P5RP-SZ. Note that the recommended power adapter
is not included in the kit. The power adapter must be bought separately or an equivalent adapter should
be used.
External Power Supply Requirements:
• Nom Output Voltage — 5 VDC
• Max Output Current — 3 A
• Efficiency Level — V
NOTE: TI recommends using an external power supply that complies with applicable regional safety
standards such as (by example) UL, CSA, VDE, CCC, PSE, and so forth.
5

Top-Level Specifications Of The EVM

The top-level specifications of the EVM are listed in
External power supply requirements
Maximum average optical output power
Operating Conditions
The details of the laser illumination are listed in
Pulse repetition frequency
Laser Beam Divergence
Transverse Beam Mode
6

System Requirements

The system requirements are as follows:
1. Microsoft Windows
®
2. 2GB RAM
3. Minimum of 500MB free space
SBOU156B – October 2015 – Revised February 2017
Submit Documentation Feedback
Table 2. EVM Specification
Item
Pixel resolution
Field of View
Connectivity
Table 3. Laser Illumination Profile
Item
Wavelength
Peak Optical Output
Pulse train width
Laser Beam Shape
7 / Ubuntu 14.04 64 bit PC
®
Copyright © 2015–2017, Texas Instruments Incorporated
Table 2.
87° Diagonal. 74 (H) x 59 (V)
0°C to 40°C (Ambient)
Table 3.
12-MHz to 80-MHz square wave at 50% duty cycle.
80° at 90% power relative to the center
Power Supply
Value (Typical)
3 A at 5 V
320 × 240
1.5 W
USB 2.0
Value (Typical)
850 nm
10 W
18 µs–28 ms
Circular
Diffused
OPT8241 Evaluation Module
