Foxtech Bi-Focus User Manual page 9

Channel configuration software instructions:
Setting com port
Baud rate 115200 Data Bit 8
Click the "Receive" button to get the current channel configuration status.
Click the "Send" button to write the configuration after manually setting the channel configuration.
Close the serial
port
Current
status
display area
1、 Select the serial port number
2、
Configure this option
according to the setting
Serial port status indicator (off)
3、Open serial port
Stop Bit 0 Parity No
Serial port
status
indicator
(on)）
Data collection button
Bi-Focus
Send data button
2019 FOXTECH All Rights Reserved
©
User Manual
9
