Foxtech Bi-Focus User Manual page 8

Serial Number Model
1
2
3
4 8PIN socket
5
6
7
8
high 0x06A4(1700)
YAW
PITCH
ZOOM
FOCUS
RECORD CAPTURE
Picture_In_ Picture Pseudo_Color
Gimbal Mode
Digital ZOOM Some models support
Types of interface
power interface
power interface
communication interface
communication interface
communication interface
communication interface
communication interface
communication interface
middle 0x03E8(1000)
middle to low yaw right
middle to high yaw right
high and low to middle yaw stop
middle to low pitch down
middle to high pitch up
high and low to middle pitch stop
middle to low ZOOM -
middle to high ZOOM +
high and low to middle ZOOM stop
middle to low FOCUS +
middle to high FOCUS -
high and low to middle ZOOM stop
middle to low photograph
middle to high video state switching
middle to low thermal imager pseudo-color switching
middle to high PIP switching
middle to low switch between high speed mode and low speed mode
middle to high switch between follow mode and lock mode
middle to low ZOOM +
middle to high ZOOM -
high and low to middle ZOOM stop
Interface Definition Features
GND GND
5V +5V output
S/I BUS SBUS channels
TXD4 UART4_Tx(Reserved)
RXD3 Serial port reception
TXD3 Serial port transmission
DA- Reserved
DA+ Reserved
low 0x012C (300)
2019 FOXTECH All Rights Reserved
©
Bi-Focus User Manual
8
