Foxtech FH310Z User Manual

Foxtech FH310Z is a plug and play kit for FPV and UAV platform such as inspection, surveillance, search and
rescue.It features in a HD 1080P camera with 10X zoom function. The camera is stabilized by a 3 axis gimbal
that is RC controllable in pan, tilt and roll axis. It offers smoother and more stable footage.

SPECIFICATIONS

1. Adopted 1/4" 300 megapixel CMOS sensor
2. Output resolution:1920x1080@30fps;1280*720@60fps
3. 10X optical zoom
4. Zoom focus length: f=4.9~49mm,diaphragm diameterφ12.0
5. Wide dynamic, dynamic range up to 105dB
6. HDMI and AV output,up to 32GB SD card storage at 1080P
7. Real-time quick focus function，focus time<1S; Manual focus available
8. Low Lux: 0.05 lux @ F1.6
9. Support flip vertical/flip horizontal/still image,AWB,auto gain control，auto color correction
10. Working temperature range : -10℃ - 55 ℃
11. Dedicated control protocol to achieve camera's controls.

FEATURES

1. mall size yet 10X zoom
S
Zoom focus length: f=4.9~49mm with up to 10X zoom capability, offers perfect display of image details.
2.Ultra quick auto focus
Special fast focusing algorithm for UAV application,focus time<1S
3.Wide dynamic
Up to 105dB dynamic range, ensures clear capture in strong or low light condition
4.Low Lux
In low light conditions,images features can be clearly displayed
5.Dedicated interface
Support PWM zoom control
6.Small size:63mm×47mm×40mm
7. Light weiht:108g
FOXTECH FH310Z
1080P 10X OPTICAL ZOOM CAMERA WITH 3 AXIS
FH310Z HD 1080P 10X OPTICAL ZOOM CAMERA
USER MANUAL
