- Page 1 Installation, use and maintenance instructions Light oil - kerosene burner One stage operation CODE BOULTER CODE MODEL TYPE 3744364 8-716-111-549 COH 110 443T58 2903209 (0)
-
Page 2: Technical Data
TECHNICAL DATA TYPE 443T58 Output - Thermal power 1.5 – 3.4 kg/h - 17 – 40 kW Kerosene, viscosity 1.6 – 6 mm /s at 20 °C Fuel Light oil, viscosity 4 – 6 mm /s at 20 °C ± 10% Electrical supply Single phase, 230 V 50Hz... -
Page 3: Firing Rate
FIRING RATE, (as EN 267) Fuel output - kg/h D7263 Thermal power - kW OVERALL DIMENSIONS Flange Burner D6103 BURNER FIXING S7386 3209... -
Page 4: Hydraulic Systems
HYDRAULIC SYSTEMS PRIMING PUMP L meters Loosen the plu g of the vacuum gauge (8, fig. 1) and wait until the I. D. I.D. meters fuel flows out. 8 mm 10 mm D5299 H = Difference of level. L = Max. length of t he suc- L meters tion line. -
Page 5: Electrical Wiring
ELECTRICAL WIRING 230V 50Hz ATTENTION: ® Do not swap neutral and phase over, follow the diagram shown carefully and carry out a good earth connection. The section of the conductors must be at least 1mm². ® (Unless requested otherwise by local standards and legislation). The electrical wiring carried out by the installer must be in com- ®... -
Page 6: Combustion Adjustment
COMBUSTION ADJUSTMENT In conformity with Efficiency Directive 92/42/EEC the application of the burner on the boiler, adjust - ment and testing must be carried out observing the instruction manual of the boiler, including verifica- tion of the CO and CO concentration in the flue gases, their temperatures and the average temperature of the water in the boiler. -
Page 7: Electrode Setting
AIR DAMPER ADJUSTMENT The regulation of the air-rate is made by adjusting the air damper (1), after loosing the screws (2). The settings indicated in the schedule refer to the burner with its metal cover fitted and the combustion chamber with “zero”... -
Page 8: Safety Warnings
ONLY FOR LIGHT OIL ADJUSTMENTS, TO AVOID FLAME - DETACHMENT, AT BURNER IGNITION This inconvenience can occur, when the temperature of the light oil decreases below +8 °C. CORRECT POSITIONING OF THE ELECTRODES (See page 6) PUMP - SETTING When the temperature of the light oil decreases below +8 °C, increase the pressure to 14 bar. COMBUSTION-HEAD SETTING Regulate the combustion head one set-point further ahead than indicated in the instructions. - Page 9 Catalogo ricambi Catalogue pièces détachées Ersatzteile Katalog Onderdelencatalogus • • Oil - Kerosene burner Bruciatore di gasolio - kerosene Brûleur fioul domestique - kérosène • Öl-Kerosen - Gebläsebrenner Stookoliebrander kerosine MOD. COD. BOULTER COD. TIPO/TYPE/TYP COH 110 3744364 8-716-111-549 443T58...
- Page 10 ADVISED SPARE PARTS RICAMBI CONSIGLIATI RECHANGE CONSEIL COD. DESCRIPTION DESCRIZIONE DESCRIPTION BESCHREIBUNG BENAMING EMPFOHLENE ERSATZTEILE AANGERADEN RESERVEONDERDELEN SEAL GUARNIZIONE JOINT DICHTUNG PAKKING 3007077 PUMP POMPA POMPE PUMPE POMP 3007811 COIL BOBINA BOBINE MV SPULE SPOEL 3002279 O - RING MANTELLO E POMELLO JOINT TORIQUE O - RING DICHTING O - RING...
