- Page 1 ECscan10 Pocket Conductivity Tester Instruction Manual Bante Instruments Inc.
-
Page 2: Prior To Use
ECscan10 Overview Thank you for selecting the ECscan series pocket conductivity tester. This manual provides a step-by-step guide to help you operate the instrument, please carefully read the following instructions before use. Installing the Batteries Remove the battery compartment lid. -
Page 3: Conductivity Calibration
ECscan10 Conductivity Calibration The ECscan10 conductivity tester allows 1 point calibration. For better accuracy, we recommend to calibrate the tester regularly. The following table shows acceptable conductivity range of standard solution for each tester. Model Calibration Solution Range Default ECscan10 L 100 to 180 µ... - Page 4 ECscan10 Temperature Measurement • Press the C key, the tester shows the temperature readings. Press the Meas key to return to the conductivity measurement. • Hold Function This function lets you lock the conductivity reading for viewing and recording. •...
-
Page 5: Specifications
ECscan10 Specifications Model ECscan10L ECscan10M ECscan10H Range 1.0 to 199.9 μS/cm 10 to 1999 μS/cm 0.1 to 19.99 mS/cm Resolution 0.1 μS/cm 1 μS/cm 0.1 mS/cm Conductivity Accuracy ± 1% F.S. Calibration Point 1 point Calibration Solution 146.5 μS/cm 1413 μS/cm 12.88 mS/cm... - Page 6 Bante Instruments Inc. Office: 4715 Castlewood St., Sugar land, TX 77479, USA Tel: (+1) 346-762-7358 E-mail: banteinstruments@yahoo.com Factory: A10, No.2066, Laifang Rd., Shanghai 201615, China Tel: (+86) 21-6404-1598 E-mail: banteinstrument@hotmail.com www.bante-china.com...
