Z-Shaped 47" Gaming Desk with LED Lights
Instruction Manual
SKU: DESK-GMZ1R
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/desk-gmz1r
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo DESK-GMZ1R
Summary of Contents for Vivo DESK-GMZ1R
- Page 1 Z-Shaped 47” Gaming Desk with LED Lights Instruction Manual SKU: DESK-GMZ1R Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-gmz1r GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 Insert cable grommets (A) into holes in legs (2, 3). Screw adjustable feet (B) into underside of legs. ×4 ×4 STEP 2 Fit pre-installed bolts on crossbar (4) into slots on tops of legs as shown. Insert M6x12 bolts (D) into lower holes of crossbar, then tighten all bolts with the Allen wrench (I). - Page 4 STEP 3 Connect cables on decorative covers (G) to cables in legs. Insert tabs of decorative covers into “keyholes” and press down to secure. STEP 4 Place tabletop (1) on assembled frame (do not engage security pins at this time). Connect cables from tabletop to cables in legs.
- Page 5 STEP 5 Hang power strip/UPS holder (5) and cable clips (C) on crossbar, being careful not to stretch and damage power cables. Align tabletop security pins with legs and support bar. Press security pins through holes to secure tabletop to frame. (NOTE: Desk shown upside down.)
- Page 6 STEP 6 Insert knobs (E) through holes in crossbar and tighten into tabletop.
- Page 7 STEP 7 Install baffle (6) to tabletop using M6x12 bolts (D) and tighten with the Allen wrench (I). Connect power adapter (H) to desk and plug into AC power outlet. If needed, turn adjustable feet to sit level. ×2...
- Page 8 - 92% within < 3hr www.vivo-us.com : < 15 M AVG. RESOLUTION TIME (within office hrs) Chat live with an agent! : 5M 4S AVG. RESOLUTION TIME 309-278-5303 (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
