Electric Dual Motor Desk Frame
Instruction Manual
SKU: DESK-E-200B/W
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/desk-e-200b
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DESK-E-200B and is the answer not in the manual?

Questions and answers

Related Manuals for Vivo DESK-E-200B

Summary of Contents for Vivo DESK-E-200B

  • Page 1 Electric Dual Motor Desk Frame Instruction Manual SKU: DESK-E-200B/W Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-e-200b GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com...

  • Page 2: Electrical Safety Instructions

    WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury.

  • Page 3: Assembly Steps

    ASSEMBLY STEPS STEP 1 Install Feet (F) to Legs (A) using M6x11mm Screws (S-A) and 5mm Allen Wrench (T-A). STEP 2 Install Left and Right Crossbars (C,D) to Legs (A) using M6x11mm Screws (S-A) and 5mm Allen Wrench (T-A). Ensure the tabs on Left and Right Crossbars (C,D) are facing outwards.
  • Page 4 STEP 3 Slide Inner Crossbars (B) into both Leg assemblies. Ensure the slots on Inner Crossbars (B) are facing inwards towards the center of the frame. STEP 4 Attach Side Brackets (E) to Legs (A) using M6x11mm Screws (S-A) and a 5mm Allen Wrench (T-A). Partially install M6x11mm Screws (S-A) into the outer crossbars using 5mm Allen Wrench (TA).
  • Page 5 STEP 5 Install Anti-Vibration Pads (J) to the frame assembly. STEP 6 Adjust the crossbars to fit your desktop width. If your desktop contains pilot holes for the side brackets, adjust the width of the crossbars to match the hole positions. Attach the frame assembly and Control Panel (G) to the desktop using M5x16mm Screws (S-B) and a Phillips screwdriver...
  • Page 6 STEP 7 Connect Extension Cable (I) to the leg opposite from the control panel position. Remove protective film from Cable Clips (K) and manage cables as desired. Plug in the leg cables and AC Power Adapter (H) into Control Panel (G).

  • Page 7: Operating Control Panel

    OPERATING CONTROL PANEL OPERATING INSTRUCTIONS: Press and hold the up arrow, the desk will raise to the highest position. Holding the down arrow will lower the desk to the lowest position. Memory Mode To store a certain height in the controller’s memory, short press S key and "S-" will appear. Short press one of the number buttons to store the height.
