Summary of Contents for Eclipse AirHeat AH series
- Page 1 135 Design Guide 6/16/2010 Eclipse AirHeat Burner AH Serie Version 2...
- Page 2 Please send your corrections and comments to our Marketing Communications Manager. It must be understood that Eclipse’s liability for its product, whether due to breach of warranty, negligence, strict liability, or otherwise is limited to the furnishing of replacement parts and Eclipse will not be liable for any This is the safety alert symbol.
-
Page 3: Table Of Contents
Step 4: Ignition System ......................9 Step 5: Flame Monitoring Control System................9 Step 6: Main Gas Shut-Off Valve Train ................10 Appendix ........................... i Conversion Factors ......................i Key to Schematics........................ ii Eclipse AirHeat Burner, V2, Design Guide 135, 6/16/2010... -
Page 4: Introduction
Introduction Product Description Audience Eclipse AirHeat Burners are line type burners ideal for This manual has been written for personnel already generating large volumes of clean, hot air. Applications familiar with all aspects of a gas burner and it’s add-on include ovens, dryers, fume incinerators, and similar components, also referred to as the burner package. -
Page 5: Safety
Replacement Parts and explosions if improperly applied, installed, Order replacement parts from Eclipse only. Any customer adjusted, controlled or maintained. supplied valves or switches should carry UL, FM, CSA, Do not bypass any safety feature; fire or explosion CGA and/or CE approvals where applicable. -
Page 6: System Design
• Flame Monitoring Control combustion air blower directly mounted to the burner. For remote blower applications, see "Remote Blower Sizing". 6. Main Gas Shut-Off Valve Train Selection: • Component Selection • Valve Train Size Eclipse AirHeat Burner, V2, Design Guide 135, 6/16/2010... -
Page 7: Step 2: Blower Option Selection
@ standard conditions (MJ/m @ normal conditions) • minimum torque of 25 in-lb. (2,8 Nm) • 90° stroke If using an alternative fuel supply, contact Eclipse with an accurate breakdown of the fuel components. • continuous modulating or high/low modulating control Manifold Type •... -
Page 8: Step 3: Control Methodology
Step 3: Control Methodology WARNING Input is normally controled by a motorized butterfly valve in the gas line to the burner. Do not use other control methods without prior approval from Eclipse. Eclipse AirHeat Burner, V2, Design Guide 135, 6/16/2010... -
Page 9: Step 4: Ignition System
• Bi-Flame series 6500 (Instruction Manual 826) • Multi-Flame series 6000 (Instruction Manual 820) Main Gas shut-off If other controls are considered, contact Eclipse to valve train determine how burner performance may be affected. Flame monitoring controls that have lower sensitivity flame detecting circuits may limit burner turndown and change the requirements for ignition. -
Page 10: Step 6: Main Gas Shut-Off Valve Train
Step 6: Main Gas Shut-Off Valve Train Component Selection Eclipse can help in the design of a main gas shutoff valve train that satisfies the customer and complies with all local safety standards and codes set by the authorities within that jurisdiction. -
Page 11: Appendix
Appendix Conversion Factors Metric to English From Multiply By cubic meter (m³) cubic foot (ft³) 35.31 cubic meter/hr (m³/h) cubic foot/hr (cfh) 35.31 degrees Celsius (°C) degrees Fahrenheit (°F) (°C x 9/5) + 32 kilogram (kg) pound (lb) 2.205 kilowatt (kW) BTU/hr 3415 meter (m) - Page 12 The pressure regulator reduces Pressure Regulator gas pressure to a stable, usable pressure. An automatic gas control valve adjusts gas flow to the burner Automatic Gas Control Valve based on control system requirements. Eclipse AirHeat Burner, V2, Design Guide 135, 6/16/2010...
- Page 13 Notes Eclipse AirHeat Burner, V2, Design Guide 135, 6/16/2010...
- Page 14 Offered By: Power Equipment Company 2011 Williamsburg Road Richmond, Virginia 23231 Phone (804) 236-3800 (804) 236-3882 www.peconet.com...
