Summary of Contents for Eclipse TFB030
- Page 1 Installation Guide 310 11/14/2014 Eclipse Tube Firing Burners Models TFB030, TFB075, TFB200 Version 2 TFB030-075 TFB200...
- Page 2 Please send your corrections and comments to our Technical Documentation Specialist. Product Name Item # It must be understood that Eclipse’s liability for its product, DD MMM YYYY whether due to breach of warranty, negligence, strict liability, or otherwise is limited to the furnishing of...
-
Page 3: Table Of Contents
Stop Procedure ........................15 Static Air Pressures......................15 Maintenance & Troubleshooting..................... 16 Maintenance ........................16 Monthly Checklist ......................... 16 Yearly Checklist ........................16 Troubleshooting Procedures ....................17 Appendix ........................... i Conversion Factors ......................i Eclipse TFB, V2, Installation Guide 310, 11/14/2014... -
Page 4: Introduction
Eclipse Engineering Related Documents • EFE 825 (Combustion Engineering Guide) TFB030-075 • Eclipse Bulletins and Info Guides: 610, 710, 720, 730, 742, 744, 760, 930, I-354 Purpose The purpose of this manual is to ensure that you carry out the installation of a safe, effective, and trouble free TFB200 combustion system. -
Page 5: Safety
■ The burners, described herein, are designed to mix should adjust, maintain or troubleshoot any mechanical or fuel with air and burn the resulting mixture. All fuel electrical part of this system. Contact Eclipse for any burning devices are capable of producing fires and needed commissioning assistance. -
Page 6: Installation
• NFPA Standard 70 NOTE: Most of the illustrations in this chapter are based • IEC60364 on a TFB030, but are typical for all TFB burners. Where • CSA C22 necessary, customized illustrations are used to describe specific details. -
Page 7: Checklist Before Installation
Dimension A is different for each fuel type, tube diameter and burner size. • For TFB030, use Table 3.1 • For TFB075, use Table 3.2 • For TFB200, use Table 3.3 Table 3.1 Dimension A Inches (mm) for TFB030 Fuel 50k-100k 101k-150k 151k-200k... - Page 8 5/8” (16 mm) Spark rod location if flame rod is used Spark rod location if flame rod is used. Figure 3.4. Position the Spark Rod & Figure 3.2. Disassemble the Burner Flame Rod (if used) Eclipse TFB, V2, Installation Guide 310, 11/14/2014...
-
Page 9: Burner Installation
Refer to the manual of your selected control for proper selection of the scanner. NOTICE ■ Adjustments may vary from Eclipse published Figure 3.5. Assemble the Burner values if the flame controls other than those recommended in the Design Guide are used. - Page 10 • Connect an impulse line to the ratio regulator from air supply line. • Install the ratio regulator in accordance with Bulletin/ DANGER Info Guide 742. ■ Refer to the Moist PAK-D MSDS sheet for proper PPE required when handling this product Eclipse TFB, V2, Installation Guide 310, 11/14/2014...
-
Page 11: Checklist After Installation
3. Set the high gas pressure switch so that it comes on at 4" w.c. (10 mbar) above the gas pressure measured at the inlet to the main gas valve train. 4. Close all the burner gas cocks or pressure taps. Eclipse TFB, V2, Installation Guide 310, 11/14/2014... -
Page 12: Adjustment, Start & Stop
Step 2: Set High Fire Air NOTE: The following steps apply to an ambient air system with orifice plates installed. 1. Make sure that the system is at high fire. 2. Set high fire air. Eclipse TFB, V2, Installation Guide 310, 11/14/2014... -
Page 13: Step 3: Set Low Fire Air
■ Make sure that all the pressure taps are closed. low fire static air pressure is: • 0.05" w.c. for the TFB030 ■ Verify the required input levels. Firing at higher levels will reduce tube life or even destroy tubes. -
Page 14: Step 6: Set High Fire Gas
This is the target value for high fire. NOTE: A pressure tap is open when the screw inside the tap is unscrewed approximately half a turn. Eclipse TFB, V2, Installation Guide 310, 11/14/2014... -
Page 15: Step 7: Verify The Gas Settings
You will get a shock. Manual Ignition 1. Make sure the gas cock at each burner is closed. 2. Start air blower. 3. Drive the automatic zone air control valve to low fire. Eclipse TFB, V2, Installation Guide 310, 11/14/2014... -
Page 16: Maintenance & Troubleshooting
7. View down the peepsights on the burners and down the exhaust legs of the tubes to check for unusual flame or carbon build-up. If necessary, remove the burner to investigate. Eclipse TFB, V2, Installation Guide 310, 11/14/2014... -
Page 17: Troubleshooting Procedures
Ratio regulator incorrectly set. Adjust to proper setting. The low fire flame is weak or unstable Not enough gas. Readjust gas flow at ratio regulator. Not enough air. Open automatic valve slightly. Eclipse TFB, V2, Installation Guide 310, 11/14/2014... - Page 18 “pulls” on the exhaust outlet of the tube. By placing a washer or restriction pate over the tube outlet, this suction can be equalized by burner pressure. Eclipse TFB, V2, Installation Guide 310, 11/14/2014...
- Page 19 Purge cycle not completed. Check flame safeguard system, or purge timer. Main power is off. Make sure power is on to control system. No power to control unit. Have a qualified electrician investigate and rectify. Eclipse TFB, V2, Installation Guide 310, 11/14/2014...
-
Page 20: Appendix
Appendix Conversion Factors Metric to English From Multiply By actual cubic meter/h (am³/h) actual cubic foot/h (acfh) 35.31 normal cubic meter/h (Nm³/h) standard cubic foot /h (scfh) 38.04 degrees Celsius (°C) degrees Fahrenheit (°F) (°C x 9/5) + 32 kilogram (kg) pound (lb) 2.205 kilowatt (kW) - Page 22 © Eclipse, Inc. All Rights Reserved Installation Guide 310, 11/14/2014...
