I N S TA L L AT I O N A N D
M A I N T E N A N C E M A N U A L
N A B O O
S A P I E N S
A R O M A N A B O O
A R O M A S A P I E N S
CAUTION: Read the instructions
prior to using the equipment
90027911rev04
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NABOO Series and is the answer not in the manual?

Questions and answers

Related Manuals for Lainox NABOO Series

Summary of Contents for Lainox NABOO Series

  • Page 1 I N S TA L L AT I O N A N D M A I N T E N A N C E M A N U A L N A B O O S A P I E N S A R O M A N A B O O A R O M A S A P I E N S CAUTION: Read the instructions...
  • Page 2 90027911rev04...
  • Page 3 MODELS Each letter of the model number identifies an oven feature followed by a number that identifies the capacity of the model. NA_B = Naboo with boiler NA_V = Naboo with direct steam NA_M = Naboo with boiler + Naboo with direct steam SA_B = Sapiens with boiler SA_V = Sapiens with direct steam SA_M = Sapiens with boiler + Sapiens with direct steam...

  • Page 4: Table Of Contents

    CONTENTS Page 1 • GENERAL REMINDERS 2 • TECHNICAL DATA 3 • SPECIAL REQUIREMENTS FOR THE INSTALLATION SITE 4 • STATUTORY REQUIREMENTS, TECHNICAL REGULATIONS AND DIRECTIVES 5 • POSITIONING 6 • ELECTRICAL CONNECTIONS AND EQUIPOTENTIAL BONDING 7 • POINTS TO REMEMBER WHEN MAKING THE ELECTRICAL CONNECTION 8 •...

  • Page 5: General Reminders

    1 •GENERAL REMINDERS • The oven must be installed, commissioned • Example of a data plate: and maintained only by an authorized service agent. LOGO • Carefully read the directions given in this TYP. XXXXXXXX manual; they contain important information 2014 NR XXXXXXXXXX on safety during installation, operation and...

  • Page 6: Technical Data

    2 • TECHNICAL DATA TABLE 1: GENERAL DATA - ELECTRIC OVENS Supply Frequency Total power Chamber Boiler Oil-proof connection Model Amps Motor voltage (**) imput power power cable ( * ) 3N AC 400 V 5 x 2,5 mm NAEB071. 3 AC 230 V 50/60 Hz 10,5 kW...
  • Page 7 2 • TECHNICAL DATA TABLE 2: GENERAL DATA GAS OVENS Oil-proof Supply Frequency Gas power Gas power Model Imput Motor connection cable voltage (**) w/boiler w/o boiler connection ( * ) NAGB071. AC 230 V 50/60 Hz 0,5 kW 1 x 0,37 kW 3 x 1 mm 15 kW 1 x R 1/2”...
  • Page 8 2 • TECHNICAL DATA TABLE 3: GENERAL WATER DATA WITH STEAM GENERATOR WITHOUT STEAM GENERATOR Softened Softened Water Water water Water water Water Model pressure Model pressure consumption connection consumption connection max. l/h max. l/h 7 x GN 1/1 7 x GN 1/1 200 - 500 2 x R 3/4 200 - 500...
  • Page 9 2 • TECHNICAL DATA TABLE 5: GENERAL DATA - NET WEIGHT Naboo Net Weight Sapiens Net Weight Naboo Net Weight Sapiens Net Weight Model Model Model Model NAEV071. SAEV071. NAEB071. SAEB071. NAEV101. SAEV101. NAEB101. SAEB101. NAEV072. SAEV072. NAEB072. SAEB072. NAEV102. SAEV102.

  • Page 10: Special Requirements For The Installation Site

    3 • SPECIAL REQUIREMENTS FOR THE INSTALLATION SITE • The room where the oven is to be fitted • The room must have a water drain in a has to be well ventilated with all the good position for the oven to be installed, openings required for rooms with gas its specifications are given under the installations (see specific regulations).

  • Page 11: Statutory Requirements, Technical Regulations And Directives

    4 • STATUTORY REQUIREMENTS, TECHNICAL REGULATIONS AND DIRECTIVES Throughout installation it is vital to observe the following requirements: • the regulations of the gas supply company Throughout installation it is vital to observe the following requirements: or agency; • a n y h e a l t h a n d h y g i e n e s t a n d a rd s •...
  • Page 12 5 • POSITIONING • LIFTING AND HANDLING OF FLOOR-STANDING OVENS • Lift the appliance using forklifts or jack DO NOT LIFT TOO MUCH, RISK OF pallets only where indicated TIPPING. • To remove the appliance from the pallet using a forklift, cautiously and slightly lift it by the minimum necessary amount, manually Do not insert forklift or jack pallet forks in the supporting it on the right-hand side, then...
  • Page 13 5 • POSITIONING • Remove all packing materials and peel away the protective plastic film from all external surfaces of the oven. • For free-standing models, the appliance needs to be levelled: small differences in level of the supporting surface can be eliminated with the adjustable feet (by screwing or unscrewing them).

  • Page 14: Electrical Connections And Equipotential Bonding

    6 • ELECTRICAL CONNECTIONS AND EQUIPOTENTIAL BONDING • As this oven is an appliance with a type Y • The oven must be kept in an equipotential attachment, (oven without power cable system. This connection is made by wiring a and plug), the cable and other hardware conductor of nominal cross section 10 mm needed to make the connection to the...

  • Page 15: Points To Remember When Making The Electrical Connection

    7 • POINTS TO REMEMBER WHEN MAKING THE ELECTRICAL CONNECTION • As all ovens of the series are fitted with • Check also that the neutral registers an alternating fan motor (clockwise and zero potential when tested. If not, the anticlockwise rotation), there is no need fault already described in point three of for the fan to rotate in any particular...

  • Page 16: Water And Drain Connections

    8 • WATER AND DRAIN CONNECTIONS A p p l i a n c e s a r e i n t e n d e d t o b e 8.3 • WATER SPECIFICATIONS permanently connected to the water The characteristics of the water must come mains within the limits given below, in order to...
  • Page 17 8 • WATER AND DRAIN CONNECTIONS 8.5 • DRAINING Fig. 1 The water is drained off by gravity through a heat-resistant pipe DN 50 (not flexible), maximum length 2 m, installed at an angle of no less than 4°. Mean temperature of the drain water: 65 °C. For the range with the drain as per fig.1 it is possible to make a direct connection with an air trap, without fitting a drain cup, as the drainage...

  • Page 18: Washing System

    9 • WASHING SYSTEM AVAILABLE WASHING SYSTEM TYPES FOR COUNTERTOP MODELS: 071 / 101 / 072 / 102 / 064 / 084 LIQUID DETERGENTS SOLID DETERGENTS FOR FLOOR MODELS: 171 / 201 / 202 / 144 / 154 ONLY LIQUID DETERGENTS 90027911rev04...
  • Page 19 9 • WASHING SYSTEMS 9 • WASHING SYSTEMS LIQUID DETERGENTS LIQUID DETERGENTS FOR SA../ ARGS../ ARES..MODELS 9.1 • P O S I T I O N I N G A N D S E T T I N G C O M B I C L E A N D E T E R G E N T With the device receiving power and the...
  • Page 20 9 • WASHING SYSTEMS LIQUID DETERGENTS FOR SA../ ARGS../ ARES..MODELS 9.2 • P O S I T I O N I N G A N D S E T T I N G With the device receiving power and the CALFREE DESCALER CARTRIDGE/ display off, press the button 6 "Cooking CONTAINER...
  • Page 21 9 • WASHING SYSTEMS LIQUID DETERGENTS FOR SA..R / ARGS..R / ARES...R. MODELS 9.3.1 • COUNTER TOP MODEL - REPLACING THE CARTRIDGE: 9.3 • R E P L A C I N G T H E C O M B I C L E A N DETERGENT CARTRIDGE Unscrew the cap of the empty cartridge and remove it.
  • Page 22 9 • WASHING SYSTEMS LIQUID DETERGENTS FOR SA..R / ARGS..R / ARES..R MODELS 9.4.1 • COUNTER TOP MODEL - REPLACING THE CARTRIDGE: 9.4 • REPLACING THE CALFREE DESCALER Unscrew the cap of the empty cartridge CARTRIDGE/TANK and remove it. If when you recall the ECO, SOFT, HARD Position the new cartridge in its dedicated or HARD PLUS wash procedure, the housing in the oven.
  • Page 23 9 • WASHING SYSTEMS LIQUID DETERGENTS FOR NA../ ARGN../ AREN..NA..R / ARGN..R / AREN..R MODELS Press the SET MAX button for the 9.5 • P O S I T I O N I N G A N D S E T T I N G COMBICLEAN or CALFREE cartridge/ C O M B I C L E A N D E T E R G E N T...
  • Page 24 9 • WASHING SYSTEMS SOLID DETERGENTS FOR SA../ ARGS../ ARES..MODELS 9.6.1 • FIRST DETERGENT CREATION 9.6.3 • D E T E R G E N T A N D D E S C A L E R Only for appliances equipped with CREATION wash kit.
  • Page 25 9 • WASHING SYSTEMS SOLID DETERGENTS FOR NA../ ARGN../ AREN..NA..R / ARGN..R / AREN..R MODELS Press the “Generate SolidClean” icon and follow the guided procedure to 9.7 • F I R S T D E T E R G E N T / D E S C A L E R create the detergent.

  • Page 26: Calout

    10 • CALOUT (if present) 10.1 • THE CALOUT W A R N I N G : FA I L U R E T O C O M P LY The CALOUT is a cleaning system, which WITH THE CALOUT USAGE TIMES keeps the steam generator free from MAY AFFECT THE OPERATION AND limescale and prevents the latter from...
  • Page 27 10 • CALOUT (if present) 10.2 • INSTALLING OVENS WITH CALOUT IMPORTANT: DEVICE The manufacturer to avoid connection (SEE CHAPTER 9) errors and tank exchange or confusion has • Place the tank of the anti-limescale provided the following features: “Calfree” with the GREEN cap (supplied with the oven) on the right side of the oven.

  • Page 28: Vents

    11 • VENTS 11.1 • Under no circumstances must vents A and B be shut, blocked or ducted into other pipes. A - Vent to extract vapours from the oven B - Safety vent 90027911rev04...

  • Page 29: Gas Connection Procedures

    12 • GAS CONNECTION PROCEDURES 12.1 • GAS CONNECTION 12.3 • EXHAUSTING FLUE GASES The section of the gas supply pipe must be Model 7 GN 1/1 - 6 x 600x400 chosen according to the type of gas and Since this appliance due to its capacity has the consumption of the appliance to be installation type A3, it is not necessary to connected.
  • Page 30 12 • GAS CONNECTION PROCEDURES Stack connection Installation type B13 pipe Extraction with natural draught fitted with a Adaptor damper and a heat-resistant pipe (see “Flue gas temperatures” in Table 4 under the heading Damper “Technical Data”) connected to the stack. Selecting this type of installation the oven must be fitted with a damper that is specific for each oven (as shown in the drawing).

  • Page 31: Operating At The Rated Heat Output

    13 • OPERATING AT THE RATED HEAT OUTPUT 13.1 • All appliances, during final testing in the 13.4 • The lower calorific value of the gas can be factory, are fitted for the type of gas shown checked with the supply company or agency, on the sticker next to the data plate.
  • Page 32 13 • OPERATING AT THE RATED HEAT OUTPUT CHECKING NOMINAL HEAT CAPACITY SAGB..- SAGV..- ARGS..- Chamber Burner Check the depth of the screw “A” in accordance with table 5 of the “Tecnical gas data” booklet, using a gauge. Check that the burner fan speed, corresponds to the data given in table 5 of the “Technical gas data”...
  • Page 33 13 • OPERATING AT THE RATED HEAT OUTPUT Turn knob 5 until [br1] on display 2 and confirm by Turning knob 3 takes us to display 2 visualisation pressing knob 3. of parameter [152] minimum speed, and display 4 shows the minimum speed value (example [136]). display 2 shows parameter [151] IGN ignition speed and display 4 shows the ignition speed value Turning knob 3 again takes us to display 2...
  • Page 34 13 • OPERATING AT THE RATED HEAT OUTPUT Then, to test the correct functioning of the burners, During testing, it is possible to manually block the exit the screen by pressing 1. sequence by pressing button 1; this way, the burner blocks in the desired phase (ex.
  • Page 35 13 • OPERATING AT THE RATED HEAT OUTPUT CHECKING NOMINAL HEAT CAPACITY SAGB..R - SAGV..R - ARGS..R - Chamber Burner Check the depth of the screw “A” in accordance with table 5 of the “Tecnical gas data” booklet, using a gauge. Check that the burner fan speed, corresponds to the data given in table 5 of the “Technical gas data”...
  • Page 36 13 • OPERATING AT THE RATED HEAT OUTPUT Select the burner, by turning knob 16 and confirm by Set the new value, by turning knob 16 and confirm by pressing knob 16. pressing knob 16. To change a value, highlight it by turning knob 16 Proceed in the same way to change the values of the and confirm by pressing knob 16.
  • Page 37 13 • OPERATING AT THE RATED HEAT OUTPUT Then, to test the correct functioning of the burners, NOTE: To check/adjust the boiler burner, activate the select “start”by turning knob 16 and confirm by Boiler Burner section (example “Boiler burner 1”) as pressing knob 16.
  • Page 38 13 • OPERATING AT THE RATED HEAT OUTPUT Check the combustion, CO (ppm) and CO2 The CO must be no greater than 300 ppm (%) values, with an appropriate instrument. (measured). Start the oven working, with the door open, If these readings are outside the ranges, and wait for approximately 5 minutes.
  • Page 39 13 • OPERATING AT THE RATED HEAT OUTPUT CHECKING NOMINAL HEAT CAPACITY Check the combustion, CO (ppm) and CO2 (%) values, with an appropriate instrument. AGB..- NAGV..- ARGN..Start the oven working, with the door open, AGB..R - NAGV..R - ARGN..R and wait for approximately 5 minutes.

  • Page 40: Commissioning And Testing

    14 •COMMISSIONING AND TESTING 14.1 • Check the appliance and the entire 14.2 • Now proceed to light the oven as directed installation straight after connecting. in the user manual, checking the smooth Check in particular: ignition of the burner. •...

  • Page 41: Important Information For The User

    15 • IMPORTANT INFORMATION FOR THE USER 15.1 • With the user manual to hand, show 15.5 • Explain to the user that certain faults in the user the functions, safety devices, operation are often due to simple errors appropriate use and, above all, the or oversights such as failure to switch on time intervals for servicing the oven.

  • Page 42: Dismantling And Disposal

    16 • DISMANTLING AND DISPOSAL “Implementation of Directives 2002/95/ 16.2 • The user must therefore dispose of the E C , 2 0 0 2 / 9 6 / E C a n d 2 0 0 3 / 1 0 8 / E C equipment at the end of its useful life at re l a t i n g t o t h e u s e o f h a z a rd o u s the appropriate centres for the separate...

  • Page 43: Installation Diagrams

    INSTALLATION DIAGRAM 17 • INSTALLATION DIAGRAMS DISTANCES TO OBSERVE 50mm / 1,9inch Keep a distance of 500mm/20inch on the right-hand side in order to 500mm carry out maintenance work. 20inch For installations different to those described, consult the manufacturer/distributor of the appliance.
  • Page 44 ALI Group S.r.l. - Via Schiaparelli 15 - Z.I. S. Giacomo di Veglia - 31029 Vittorio Veneto (TV) - Italy - Tel. (+39) 0438 9110 - Fax (+39) 0438 912300...
