USER'S MANUAL
C O M B I N AT I O N O V E N
W I T H D I R E C T S T E A M A N D
W I T H S T E A M G E N E R ATO R
V E R S I O N E X
H E A R T
Technical service
90024570rev00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Heart X and is the answer not in the manual?

Questions and answers

Related Manuals for Lainox Heart X

Summary of Contents for Lainox Heart X

  • Page 1 USER’S MANUAL C O M B I N AT I O N O V E N W I T H D I R E C T S T E A M A N D W I T H S T E A M G E N E R ATO R V E R S I O N E X H E A R T Interactive Cooking System...

  • Page 3: Table Of Contents

    CONTENTS PAGE 1 • GENERAL REMINDERS 2 • POINTS TO REMEMBER 3 • DESCRIPTION OF KEYS 4 • DESCRIPTION OF SYMBOLS 5 • SWITCHING THE OVEN ON 6 • PREHEATING THE OVEN 7 • COOKING WITH CORE PROBE 8 • FAST DRY HUMIDITY EVACUATION SYSTEM 9 •...

  • Page 4: General Reminders

    1 • GENERAL REMINDERS Repairs may become necessary over time; these and all major servicing o p e r a t i o n s m u s t b e p e r f o r m e d LX TYP.

  • Page 5: Points To Remember

    2 • POINTS TO REMEMBER • Before any food is cooked in a new oven, the interior must be thoroughly cleaned (see D a i l y C l e a n i n g Ó • At the end of the working day, clean the •...

  • Page 6: Description Of Keys

    3 • DESCRIPTION OF KEYS ON-OFF (1) SCROLLER+ (5) Setting/selection knob. TURNS on the control panel, To personalize oven parameters; turn the activates self-diagnosis. Scroller+ to move between menus and confirm Key light on: appliance ready for use. your selection by pressing the Scroller+. Key light off: appliance powered, control panel off.

  • Page 7: Description Of Symbols

    3 • DESCRIPTION OF KEYS OVEN MOISTURE This precludes the possibility that food could INLET KEY (KEY 8) start cooking with too high a temperature in the This function is useful for foods that oven. require added humidity when cooking. Press In addition, the added moisture prevents foods the key and hold for as long as it is wished to from drying up.

  • Page 8: Switching The Oven On

    5 • SWITCHING THE OVEN ON Press the “ON” key to start the oven. the key light stays on steady. • Wait 15 seconds for the oven to start. PLEASE WAIT 15 seconds 5.1 - SAVING HACCP LOG • With the first start-up of the day, the oven 01/02/06 Pre-heat prompts the operator to save the HACCP...

  • Page 9: Preheating The Oven

    6 • PREHEATING THE OVEN Before cooking it is essential to preheat With ICS cooking and recipes selected the oven while empty in order to reduce from the manual, preheating is performed the cooking time and ensure good automatically. results. The preheating temperature depends on the type of product, size and quantity;...
  • Page 10 6 • PREHEATING THE OVEN • Start preheating by pressing the START Pre-heat (4) key; The progress towards completion percentage of the set temperature is Press Start shown. On reaching the set temperature, an acoustic signal sounds to alert the user that the oven is fully preheated.
  • Page 11 7 • COKING WITH CORE PROBE Foreword multipoint U s i n g t h e Ó c o r e p r o b e , w i t h T h e c o r e p r o b e a l l o w s c o o k i n g t o b e f o u r s e n s o r p o i n t s , e n s u r e s t h e m i n i m u m r e g u l a t e d b y m o n i t o r i n g t h e t e m p e r a t u r e t e m p e r a t u r e i s r e a c h e d a t t h e c o r e o f...
  • Page 12 7 • COKING WITH CORE PROBE 7.2 - APPLICATIONS - ADVANTAGES Advantages of core probe cooking Traditionally with core probe cooking it was always important to position the • Improves control over the cooking probe in the very centre of the food. process, eliminating the risk of loss and The probe had always to be positioned waste;...

  • Page 13: Cooking With Core Probe

    7 • COKING WITH CORE PROBE 7.3 - SETTING COOKING WITH CORE PROBE Manual • Having selected ICS cooking or set a cooking cycle of your choice (manual or CYCLES Setting preset recipes) press the “Core probe” key and set the core temperature of the product by turning the Scroller+ to the desired value, then confirm by pressing 130°...

  • Page 14: Fast Dry Humidity Evacuation System

    8 • FAST DRY HUMIDITY EVACUATION SYSTEM The Fast Dry humidity evacuation Ideal for patisserie and bakery products system exploits the Venturi effect such as: generated by the movement of the - choux pastries fan, enabling rapid, efficient removal of - puff pastry excess humidity.
  • Page 15 11 • INTERACTIVE COOKING 11.1 - SELECTING COOKING Cooking P r e s s t h e C o o k i n g I n t e r a c t i v e I C S Ó k e y t o s t a r t c o o k i n g i m m e d i a t e l y w i t h p r e s e t s e t t i n g s .

  • Page 16: Extra

    11 • INTERACTIVE COOKING 11.2 - PERSONALIZATION OF PARAMETERS B a s e d o n t h e c o o k i n g m o d e s e l e c t e d , I C S a u t o m a t i c a l l y p r o p o s e s p a r a m e t e r s w h i c h c a n b e p e r s o n a l i s e d t o s u i t i n d i v i d u a l n e e d s .
  • Page 17 11 • INTERACTIVE COOKING 11.3 - PERSONALIZATION OF COOKING CYCLES D u r i n g c o o k i n g c y c l e s , t h e p a r a m e t e r s d i s p l a y e d a r e g i v e n i n r e a l t i m e : w h e n t h e s y m b o l s o r c o r r e s p o n d i n g v a l u e s a r e p r e s s e d , t h e s e t v a l u e s a r e s h o w n .
  • Page 18 11 • INTERACTIVE COOKING 11.4 - ADVANCE TO THE NEXT COOKING CYCLE • During cooking, to advance to the next First coursesos CYCLES PROCEED CYCLES cooking cycle, press the “Cycles” key and Setting Crepes-flan then “Proceed” on the display. 170° FAST DRY 11.5 - ELIMINATING COOKING CYCLES •...
  • Page 19 11 • INTERACTIVE COOKING 11.6 - MANAGEMENT ICS/EXTRA PROGRAMS First courses • After personalizing the desired parameters, Save Crepes-flan setting these settings can be saved by pressing Before loading the “Save Setting” key. preheat oven Browning • Press the “Copy” key to create a copy 130°...
  • Page 20 12 • EXTRA P r e s s t h e E X T R A S Ó k e y t o a c c e s s s e t t i n g EXTRA o f a d d i t i o n a l f u n c t i o n s , n a m e l y : R e g e n e r a t i o n , H o l d i n g , D e f r o s t i n g , M u l t i l e v e l .
  • Page 21 12 • EXTRA 12.1 REGENERATION EXTRA • Select the desired type of regeneration on the touch screen or turn the Scroller+ to the desired Regeneration regeneration position and confirm by pressing On dish the Scroller+. On dish-probe On baking tin On baking tin-probe Banqueting B a s e d o n t h e c o o k i n g m o d e s e l e c t e d , H e a r t...
  • Page 22 12 • EXTRA 12.2 - HOLDING EXTRA • Select the desired type of holding on the touch screen or turn the Scroller+ to the desired Holding holding position and confirm by pressing the Au gratin products Scroller+. Various meats Braised and stewed meats B a s e d o n t h e c o o k i n g m o d e s e l e c t e d , H e a r t a u t o m a t i c a l l y p r o p o s e s p a r a m e t e r s w h i c h c a n b e p e r s o n a l i s e d t o s u i t i n d i v i d u a l n e e d s .
  • Page 23 12 • EXTRA 12.3 - THAWING EXTRA • Select the desired type of defrosting on the touch screen or turn the Scroller+ to Thawing the desired defrosting position and confirm Slow by pressing the Scroller+. Slow-probe Quick • Place food to be defrosted in the oven. Quick-probe EXTRA •...
  • Page 24 12 • EXTRA EXTRA • During defrosting, parameters can be Thawing CYCLES changed as desired by selecting the Slow-probe symbol of the relevant parameter on the touch screen, turning the Scroller+ to the desired value, then confirm by pressing the Scroller+. 30°...
  • Page 25 12 • EXTRA 12.4 - MULTILEVEL COOKING Multilevel cooking makes it possible “JIT - Just in Time” cooking makes to cook different products together it possible to cook a number of at the same time: the oven will foodstuffs, setting the oven so that signal when the various products all the food finishes cooking at are ready to be served.
  • Page 26 12 • EXTRA Multilevel E a c h l e v e l c a n b e p e r s o n a l i z e d w i t h a n a m e a s f o l l o w s : Cooking parameters •...
  • Page 27 12 • EXTRA 12.4.1 - MULTILEVEL TIMED/CORE PROBE COOKING Multilevel • Personalize the Time/Core temperature by turning the Scroller+ and confirm by Cooking parameters pressing the Scroller+. Level 01 Repeat the same procedure for the Level 02 desired levels. Level 03 Level 04 1 - Level 01 Level 05...
  • Page 28 12 • EXTRA 12.4.2 - MULTILEVEL ”JIT” JUST IN TIME COOKING Multilevel • Personalize the “JIT” value by turning the Scroller+, then confirm by pressing Cooking parameters the Scroller+. Level 01 Repeat the same procedure for the Level 02 desired levels. Level 03 Level 04 1 - Level 01...
  • Page 29 12 • EXTRA Multilevel • Preheat the oven by pressing the “Pre- heat” key or, if the oven is already Cooking parameters preheated, place the food in the oven and press “START/STOP”. Level 01 Level 02 Level 03 Level 04 Level 05 Level 06 Load...

  • Page 30: Manual Cooking

    13 • MANUAL COOKING 13.1 - SELECTING COOKING P r e s s t h e M a n u a l Ó k e y t o a c c e s s m a n u a l MANUAL s e t t i n g o f c o o k i n g .
  • Page 31 13 • MANUAL COOKING 13.2 - ADDING COOKING CYCLES • To add a cooking cycle, press the “Cycles” Manual key on the touch screen and turn the CYCLES CYCLES Scroller+ until the next cycle number appears and then confirm by pressing the Scroller+.

  • Page 32: Programs

    13 • MANUAL COOKING 13.3 - SAVING RECIPES Manual H a v i n g s e l e c t e d a r e c i p e o r a t t h e e n d CYCLES o f c o o k i n g , t h e r e c i p e i n q u e s t i o n c a n b e Setting...
  • Page 33 14 • PROGRAMS 14.1 -RETRIEVE A STORED PROGRAM P r e s s t h e P r o g r a m s Ó k e y t o a c c e s s t h e U s e r p r o g r a m s Ó / N e w p r o g r a m Ó s e l e c t i o n PROGRAMS s c r e e n .

  • Page 34: Favourites

    14 • PROGRAMS 14.2 - ADDING PROGRAMS TO FAVOURITES • Select the desired recipe directly on the USER PROGRAMS touch screen or turn the Scroller+ to the Programs 004 / 400 desired recipe, then press the “Add to Crepes-flan (001) favourite”...
  • Page 35 14 • PROGRAMS 03 • PROGRAMS 14.4 - CREATING A NEW PROGRAM • Select “New program” to create a new PROGRAMS recipe by pressing the touch screen or turning the Scroller+ to highlight “New program”, then confirm by pressing the User programs Scroller+.
  • Page 36 14 • PROGRAMS • Select the cooking mode directly on the SELECT THE COOKING MODE touch screen by pressing the symbol below Hot air mode Steam mode Combi mode the description of the type of cooking. • Personalize the parameters Crepes - Temperature, CYCLES...
  • Page 37 14 • PROGRAMS • Select the type of foodstuff for the new SELECT THE COOKING MODE cycle directly on the touch screen, modify Hot air mode Steam mode Combi mode the desired parameters as for the previous cycle. Add new cycles if necessary until the recipe is completed.
  • Page 38 14 • PROGRAMS 14.5 - CHANGE A STORED PROGRAM Crepes • All the settings of an existing program can be changed. CYCLES Before loading According to your requirements, change preheat oven the parameters for: - Temperature, - Time/Core temperature, 180° - Fast Dry/Autoclima, - Fan speed, for the program cycle displayed, simply by...
  • Page 39 14 • PROGRAMS Crepes • “Save modification” allows you to overwrite the existing recipe. CYCLES Before loading Press “Save modification” to overwrite, a preheat oven window appears confirming that the recipe has been overwritten. Confirm by pressing 180° “YES” Save modification FAST DRY FAST DRY FAST DRY...
  • Page 40 15 • FAVOURITES 15.1 - SELECTING FAVOURITES P r e s s t h e F a v o u r i t e s Ó k e y t o a c c e s s t h e f a v o u r i t e r e c i p e s s e l e c t i o n s c r e e n .
  • Page 41 15 • FAVOURITES 15.2 - ELIMINATING FAVOURITES • Select the recipe directly on the touch FAVOURITES screen and press the “Delete” key or turn the Scroller+ to the desired recipe and Crepes-flan then press “Delete”. Roasts 1 - probe Large cream puffs (001) Bread 2 •...

  • Page 42: Plus - Special Functions

    16 • PLUS - Special Functions P r e s s t h e P L U S Ó k e y t o a c c e s s t h e v a r i o u s S p e c i a l F u n c t i o n s , s u c h a s : Δ...
  • Page 43 16 • PLUS - Special Functions 16.1 - COOKING TIMER D u r i n g c o o k i n g , t h e o p e r a t o r c a n s e e h o w m u c h t i m e h a s e l a p s e d s i n c e t h e s t a r t o f c o o k i n g .
  • Page 44 16 • PLUS - Special Functions 16.2 • COOKING WITH ∆T SYSTEM Δ Δ T h e T f u n c t i o n a l l o w s t h e c o r e p r o b e t o W i t h t h e T s y s t e m , f o o d n e e d n o t b e u s e d w h i l e m a i n t a i n i n g a c o n s t a n t...
  • Page 45 16 • PLUS - Special Functions 16.2.1 - ADVICE, APPLICATIONS AND ADVANTAGES Advice - applications Advantages This type of cooking takes longer; the During cooking, the heat penetrates the lower the ΔT the longer the cooking time food gradually and uniformly, rendering and the greater the yield: this introduces it succulent and tender and avoiding any an important new chapter which,...
  • Page 46 16 • PLUS - Special Functions Manual • Select “Delta T” directly on the touch screen or turn the Scroller+ to “Delta CYCLES Before loading T” and then confirm by pressing the Special Functions Scroller+. Total cooking time Delta T cooking Vent management Fan management Hold...
  • Page 47 16 • PLUS - Special Functions Manual • Preheat the oven by pressing the “Pre- heat” key or, if the oven is already CYCLES Before loading preheated, press “START/STOP”. preheat oven 50° 70° FAST DRY • Insert the probe in the connection (10), place the food in the oven and insert the Manual probe, then confirm insertion by pressing...
  • Page 48 16 • PLUS - Special Functions 16.3 - VENT MANAGEMENT A l l o w s t h e o p e r a t o r t o m a n a g e t h e o v e n Õ s a i r v e n t m a n u a l l y f o r c o n v e c t i o n c o o k i n g w i t h o u t A U T O C L I M A .
  • Page 49 16 • PLUS - Special Functions Manual • Select the desired vent position directly on the touch screen or turn the Scroller+ CYCLES Before loading to the desired setting and confirm by Special Functions pressing the Scroller+. Total cooking time Delta T cooking VENT CLOSED: the oven vent is Vent Management...
  • Page 50 16 • PLUS - Special Functions 16.4 - FAN MANAGEMENT F a n m a n a g e m e n t i s a s p e c i a l f u n c t i o n w h i c h c a n b e a c t i v a t e d w i t h a n y c o o k i n g c y c l e .
  • Page 51 16 • PLUS - Special Functions Manual • Select “ON” directly on the touch screen or turn the Scroller+ to “ON” and confirm CYCLES Before loading by pressing the Scroller+. Special Functions Total cooking time Delta T cooking Vent management Fan management Intermittent Fans Hold...

  • Page 52: Special Functions

    16 • PLUS - Special Functions 16.5 - HOLDING H o l d i n g i s a s p e c i a l f u n c t i o n w h i c h H O L D I N G f o l l o w s t h e l a s t p r o g r a m a l l o w s t h e o p e r a t o r t o k e e p a p r o d u c t c y c l e , i f t h e l a s t c y c l e i s t i m e b a s e d h o t a f t e r t h e L A S T C O O K I N G C Y C L E ,...
  • Page 53 16 • PLUS - Special Functions Manual • Select the desired type of Holding directly on the touch screen or turn the Scroller+ CYCLES Before loading to the type of finish desired and confirm by Special Functions pressing the Scroller+. Total cooking time Delta T cooking OFF: no holding...
  • Page 54 16 • PLUS - Special Functions 16.6 - FINISH F i n i s h i s a s p e c i a l f u n c t i o n w h i c h i s T h e F I N I S H i s a n i n t e g r a l p a r t o f t h e l a s t u s e d i n c o m b i n a t i o n w i t h t h e l a s t o r o n l y c y c l e o f t h e p r o g r a m .
  • Page 55 16 • PLUS - Special Functions Manual • Select the desired type of Finish directly on the touch screen or turn the Scroller+ CYCLES Before loading to the type of finish desired and confirm by Special Functions pressing the Scroller+. Total cooking time Delta T cooking OFF: No finish...

  • Page 56: Additional Functions

    17 • Additional functions 17.1 - ONLINE HELP O n l i n e H e l p e x p l a i n s t h e f u n c t i o n o f e a c h k e y , m a k i n g e v e r y t h i n g e v e n e a s i e r .
  • Page 57 17 • Additional functions • In the submenu, select the line of text for which you need online help by turning the First courses Scroller+ to that line. Recipes: Crepes-flan Cannelloni Crepes Lasagne-moussaka-sonda Flan Manicaretti Baked Roman dumplings Steamed rice Soups with lid •...
  • Page 58 17 • Additional functions 17.2 - SETTING DATE/TIME • Press the “date/time” key. 01/02/06 Pre-heat 15.35 the oven PROGRAMS Cooking MANUAL EXTRA Interactive FA VOURITES • Turn the Scroller+ to day - month - year 01/02/06 Pre-heat 15.35 the oven and/or date - time.
  • Page 59 17 • Additional functions 17.3 - DELAYED START Manual • If desired, once you have set a manual program or retrieved a stored program CYCLES Setting from the program list, oven switch-on can be delayed. Press the “date/time” key. 130° FAST DRY Manual •...

  • Page 60: Useful Tips

    18 • USEFUL TIPS • PREHEATING THE OVEN • FROZEN/DEEP-FROZEN PRODUCTS The oven preheating cycle is extremely The oven must be preheated and loaded in important and useful for successful relation to the quality and characteristics of cooking. these foods. For example, frozen spinach As a general rule, always preheat the oven must not be exposed to excessively high when empty, setting the temperature...

  • Page 61: Daily Cleaning

    19 • DAILY CLEANING It is a good rule at the end of the • METICULOUS CLEANING ... wash cycle to rinse the inside of ... is a prerequisite for impeccable the oven again with the hand-held cooking results and better yields: shower and wipe the front seal of the •...

  • Page 62: Washing The Oven

    20 • WASHING THE OVEN P r e s s t h e W C S Ó k e y t o a c c e s s t h e s e l e c t i o n s c r e e n l i s t i n g t h e o v e n w a s h i n g o p t i o n s .
  • Page 63 20 • WASHING THE OVEN 20.1 - MANUAL WASH OVEN WASHING • Press the “START/STOP” key to start the MANUAL manual wash cycle. PRESS START TO START 83° CYCLES • The display shows “COOLING” if the oven OVEN WASHING temperature is high or “WAIT” if the oven MANUAL temperature is too low.
  • Page 64 20 • WASHING THE OVEN OVEN WASHING • The oven proceeds with the subsequent MANUAL cycles, the display shows the time MANUAL WASHIING remaining until the end of the washing cycle (total duration of wash: 10’). 58° CYCLES • At the end of the washing cycle a window OVEN WASHING appears on the display indicating that the MANUAL...
  • Page 65 20 • WASHING THE OVEN 20.2 - WASHING KIT OPTIONAL: The appliance equipped Make sure that the quick-fit coupling for the detergent is properly inserted (see with washing kit (see details shown in photo below) and that the detergent tank photos below) allows the operator to contains enough of the manufacturer’s select one of two oven cleaning cycles...
  • Page 66 20 • WASHING THE OVEN 20.3 - SOFT WASH OVEN WASHING • Press the “START/STOP” key to start the SOFT Soft wash cycle. PRESS START TO START 83° CYCLES • The display shows “COOLING” if the oven OVEN WASHING temperature is too high or “WAIT” if the SOFT oven temperature is too low.
  • Page 67 20 • WASHING THE OVEN OVEN WASHING • The oven proceeds with the subsequent SOFT cycles, the display shows the time SOFT WASHING remaining until the end of the washing cycle (total duration of wash: 24’). 58° CYCLES • At the end of the washing cycle a window OVEN WASHING appears on the display indicating that the SOFT...
  • Page 68 20 • WASHING THE OVEN 20.4 - HARD WASH OVEN WASHING • Press the “START/STOP” key to start the HARD Hard wash cycle. PRESS START TO START 83° CYCLES • The display shows “COOLING” if the oven OVEN WASHING temperature is high or “WAIT” if the oven HARD temperature is too low.
  • Page 69 20 • WASHING THE OVEN OVEN WASHING • The oven proceeds with the subsequent HARD cycles, the display shows the time HARD WASHING remaining until the end of the washing cycle (total duration of wash: 38’). 58° CYCLES • At the end of the washing cycle a window OVEN WASHING appears on the display indicating that the HARD...

  • Page 70: Routine Maintenance

    21 • ROUTINE MAINTENANCE • PERIODICALLY ... • PROLONGED DISUSE ... clean the deflector and pan racks If the oven is to stand idle for any as necessary. length of time (e.g. holidays or seasonal For this purpose, proceed as follows: closing) it must be cleaned thoroughly, •...

  • Page 71: Oven Management

    23 • OVEN MANAGEMENT 23.1 - SERVICE P r e s s t h e S E R V I C E Ó k e y t o a c c e s s t h e o v e n Õ s m a i n t e n a n c e a n d s e r v i c e f u n c t i o n s , n a m e l y : S e r v i c e , U s e r s e t t i n g s , U s e r l a n g u a g e .
  • Page 72 23 • OVEN MANAGEMENT 23.2 - USER SETTINGS • Press “User setting” or turn the Scroller+ OVEN MANAGEMENT to “User setting” and confirm by pressing the Scroller+ to access the menu for personalized user settings. Service User setting User Language MODELLO: ME061 MATRICOLA: LA0200AAAA SOFTWARE: VER098REV019c...
  • Page 73 23 • OVEN MANAGEMENT 23.2.1 - USER PARAMETERS - Block Functions T h i s f u n c t i o n a l l o w s t h e o p e r a t o r t o b l o c k User parameters a l l t h e f u n c t i o n s o f t h e m a i n m e n u e x c e p t F a v o u r i t e s Ó...
  • Page 74 23 • OVEN MANAGEMENT • Turn the Scroller+ to highlight the number User parameters “1”. Confirm by pressing the Scroller+. Modifica parametro Attuale 001 blocco forno • Press the “BACK” key to exit the “User parameters” function. RESTORING ALL THE MENU FUNCTIONS •...
  • Page 75 23 • OVEN MANAGEMENT • Enter the user password and confirm by Enter user password pressing ENTER. (Default Password: USERPWD1). B C D E G H I M N O P Q R U V W X SPACE canc ENTER Moves the cursor one space to the left Moves the cursor one space to the right Cancels the character immediately to the...
  • Page 76 23 • OVEN MANAGEMENT 23.2.2 - DOWNLOADING HACCP LOG • Press the “Download log” key. HACCP Save HACCP on USB stick Download log • A screen will appear asking the operator HACCP to insert a USB pen. Unscrew the protective screw of the USB port until the protective cover is turned Save HACCP on USB stick through 90°, allowing access to the USB...
  • Page 77 23 • OVEN MANAGEMENT • Upon completion, a window will appear HACCP indicating that the data has been successfully exported. Confirm by pressing “OK” or press the Save HACCP on USB stick Scroller+. Log downloaded successfully Press the “BACK” key to return to the Scarica log oven’s main menu.
  • Page 78 23 • OVEN MANAGEMENT 23.2.3 - RECIPE MANAGEMENT • Select “Copy recipes” if you wish to save Recipe management user recipes on the USB pen or “Load recipes” if you wish to load previously saved recipes into the oven. Copy recipes onto USB stick User Recipes: 010 Copy recipes Upload recipes from USB stick...
  • Page 79 23 • OVEN MANAGEMENT • After copying/loading, a window appears Recipe management on the display informing the operator that copying/loading has been successfully completed. Copy recipes onto USB stick User Recipes: 010 Confirm by pressing “OK on the touch screen or press the Scroller+. Loading completed Recipes loaded no.
  • Page 80 23 • OVEN MANAGEMENT 23.2.4 - CHANGE USER PASSWORD • Enter the user password and confirm by Enter user password pressing ENTER. (Default Password: USERPWD1) B C D E G H I M N O P Q R U V W X SPACE canc ENTER...
  • Page 81 23 • OVEN MANAGEMENT • Enter the new user password again Repeat new user password B C D E G H I M N O P Q R U V W X SPACE canc ENTER • A window appears informing the operator that ******** the Password has been successfully changed.
  • Page 82 23 • OVEN MANAGEMENT 23.3 - SELECTING USER LANGUAGE • Press “User language” or turn the Scroller+ OVEN MANAGEMENT to highlight “User language” and confirm by pressing the Scroller+. Service User setting User Language MODELLO: ME061 MATRICOLA: LA0200AAAA SOFTWARE: VER098REV019c •...

  • Page 83: Self-Diagnosis And Fault Identification

    24 • SELF-DIAGNOSIS AND FAULT IDENTIFICATION • Whenever the appliance is powered “NON SERIOUS” alarms are indicated by up by pressing the main switch (1), an a window with the message “CAUTION” electronic diagnostics routine is run and an intermittent acoustic signal; automatically to check the principal they only block the function specifically functions.
  • Page 84 24 • SELF-DIAGNOSIS AND FAULT IDENTIFICATION 24.1 - SERIOUS ALARM The main fault warning messages • NO GAS are indicated on the display with the No gas. Check that the shutoff valve appearance of an alarm window. is open and that there is gas coming from the main.
  • Page 85 23 • SELF-DIAGNOSIS AND FAULT IDENTIFICATION • BOILER PROBE • CONDENSATION PROBE ( I f o v e n c o o k i n g i n ( I f o v e n s t e a m m o d e , c o m b i n e d o r p r e h e a t i n g c o o k i n g i n s t e a m o r c o m b i n e d m o d e ) .
  • Page 86 24 • SELF-DIAGNOSIS AND FAULT IDENTIFICATION • CONDENS. PROBE. • PREALARM T. COMP. ( i f o v e n n o t An abnormally high temperature c o o k i n g o r c o n v e c t i o n c o o k i n g ) . Vapour condensation temperature rise has registered in the compartment probe faulty.
  • Page 89 TOUCH SCREEN MAIN CONTROL PANEL Press to confirm or change preheat mode and temperature. Then press START to start it up. It is possible to save the changed settings by pressing “Save new setting”. Select HELP and then any button 01/02/06 Pre-heat to receive information on the use...
  • Page 90 CONTROL PANEL DISPLAY, SCROLLER AND KEYS ON/OFF button Touch screen display 01/02/06 Preriscaldare 15.35 il forno PROGRAMMI EXTRA MANUALE PREFERITI Back / Return to previous menu key START / STOP key Scroller+ Setting / selection knob Rapid cooling with door open key Oven steam evacuation vent key Cooking chamber light key Manual humidifier key...
