ATX Motherboard supports LGA775 Intel® Core™2
Dual/Quad CPU with 1333/1066/800MHz FSB, VGA, PCIe
x16, PCIe x4(x1 signal), PCI, 6COM, Dual PCIe GbE,
USB2.0, CF, SATAII and Audio, RoHS
Quick Installation Guide
Package Contents
IMBA-G410 package includes the following items:
l
1 x IMBA-G410-R20 Single Board Computer
l
2 x Dual RS-232 cable
l
2 x SATA cable
l
1 x I/O Shielding
l
1 x Mini Jumper Pack
l
1 x Utility CD
l
1 x QIG (Quick Installation Guide)
l
1 x One Key recovery CD
IMBA-G410
Version 2.01
Jan. 17, 2012
©2012 Copyright by IEI Technology corp.
All rights reserved.
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for IEI Technology IMBA-G410
Summary of Contents for IEI Technology IMBA-G410
- Page 1 IMBA-G410 Quick Installation Guide Version 2.01 Jan. 17, 2012 Package Contents IMBA-G410 package includes the following items: 1 x IMBA-G410-R20 Single Board Computer 2 x Dual RS-232 cable 2 x SATA cable 1 x I/O Shielding 1 x Mini Jumper Pack...
-
Page 2: Specifications
Specifications l CPU: LGA775 45nm Intel® Core™2 Quad, Core™2 Duo, Pentium® D, Celeron® at FSB 800/1066/1333MHz processors l System Chipset: Intel® G41+ ICH7 l BIOS: AMI l System Memory: Two 240-pin 800/1066MHz Dual-Channel DDR3 SDRAM DIMM slot supported (system max. 8GB) l Ethernet: Dual Realtek RTL8111E PCIe GbE Controllers, LAN1 with ASF2.0 support... -
Page 3: Ordering Information
Dimension: 305mm x 244mm l Weight: GW:1200g, NW:650g Ordering Information IMBA-G410-R20: ATX Motherboard supports LGA775 Intel® Core™2 Dual/Quad CPU with 1333/1066/800MHz FSB, VGA, PCIe x16, PCIe x4(x1 signal), PCI, 6COM, Dual PCIe GbE, USB2.0, CF, SATAII and Audio, RoHS 32200-000052-RS：IDE cable... -
Page 4: Jumpers Setting And Connectors
Jumpers setting and Connectors LABEL FUNCTION CMOS state setting jumper Compact Flash Card Master/Slave Select RS-232/422/485 Select JAUTO1/2 AT/ATX Power Select USB_PWR1/2 USB PWR Select JP_CF1 CF Voltage Choice 3IN1_DSUB1B 3 in 1 D-Sub-RS-232 COM Port COM3~6 RS-232 Pin Header COM2 RS-232/422/485 Pin Header F_PANEL1... - Page 5 JP1 : Clear CMOS Setup DESCRIPTION Keep CMOS Setup (default) (Normal Operation) Short 2-3 Clear CMOS Setup JP2 : Compact Flash Card Master/Slave DESCRIPTION Open Slave Short Master（Default） JP4: RS-232/422/485 Select DESCRIPTION RS-232 Short 1-3 RS-422 Short 2-4,3-5 RS-485 Short 4-6 JAUTO1/2: AT/ATX Power Select DESCRIPTION Open...
- Page 6 3IN1_DSUB1B : COM1(RS232) PIN NO. DESCRIPTION PIN NO. DESCRIPTION NDCD NDSR NRTS NCTS NDTR COM3~COM6：RS-232 Pin Header PIN NO. DESCRIPTION PIN NO. DESCRIPTION NRLSD NDSR NRTS NCTS NDTR COM2(RS-232/422/485)：RS-232/422/485 Pin Header PIN NO. DESCRIPTION PIN NO. DESCRIPTION NDCD NDSR NRTS NCTS NDTR F_PANEL1 : PWR、RST Buttons、Indicators and Speaker...
- Page 7 3IN1_DSUB1C: 3 in 1 D-Sub—VGA Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION VGAVCC Green Hot plug Blue DDCDAT HSYNC VSYNC DDCCLK DIO1 : 8Bit Digital Input / Output Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION VCC5S GPO0 GPO1 GPO2 GPO3 GPI0 GPI1 GPI2...
- Page 8 IR1 : IR Connector DESCRIPTION DESCRIPTION IR_RX IR_TX CPU_FAN1: SYS_FAN1: CPU FAN,1X4PIN SYSTEM FAN, 1X3 PIN HEADER,P=2.54 HEADER,P=2.54 DESCRIPTION DESCRIPTION FANIN2 +12V +12V FANIN1 FANCTL1 CN9:SMBUS Connector PCN1:PCIe Power Source Connector DESCRIPTION DESCRIPTION VCC +5V SMBDATA SMBCLK VCC +12V BAT1 : SYS_FAN2/3: System Fan CONN Coin battery holder 1X3 PIN PINHEADER,P=2.54...
- Page 9 TPM1: TPM Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION TPMCLK LFRAME- PCIRST4- LAD3 LAD2 LAD0 LAD1 SMBCLK_MAIN SMBDATA_MAIN +3.3V SERIRQ CLKRUN- +3.3V LDRQ0- SATA1/2/3/4：SATA Connector DESCRIPTION SATATXP SATAXN SATARXN SATARXP LAN1/USB1A,LAN2/USB2A: RJ45 Connector DESCRIPTION DESCRIPTION 3,3V LAN1/2_MDI3+ LAN1/2_MDI0+ LAN1/2_MDI3- LAN1/2_MDI0- LAN1/2_MDI1+ LAN1/2_LINK100 LAN1/2_LINK1000...
- Page 10 PWR2: ATX POWER Connector DESCRIPTION DESCRIPTION +3.3V +3.3V +3.3V -12V PS_ON- +12V +12V +3.3V 3IN1_DSUB1A: LPT Connector DESCRIPTION DESCRIPTION RSTB- RPDR0 RPDR2 RPDR1 RPDR4 RPDR3 RPDR6 RPDR5 RACK- RPDR7 RBUSY RAFD- RSLCT ERR- RINIY_P- RSLIN- KBMS2: KB/MS Connector DESCRIPTION DESCRIPTION KB_DATA KBPWR KB_CLK...
- Page 11 JSPI1: SPI Connector. PIN HEADER2*4,8PIN, P:2.54MM DESCRIPTION DESCRIPTION SPI_VCC SPI_CS SPI_CLK SPI_SO SPI_S1...
- Page 12 Board Layout: Jumper and Connector Locations （Unit：MM）...
