Manual
3400 Series
LP Gas Barbecue
Step-By-Step Instructions
WARNING: Follow all leak check
procedures carefully in this manual prior
to barbecue operation. Do this even
though the barbecue is assembled.
NOTICE TO INSTALLER: These
instructions must be left with the owner
and the owner should keep them for
future use.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
WARNING: Do not try to light this
appliance without reading "Lighting"
instructions section of this manual.
FOR YOUR SAFETY
1. Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
2. An LP tank not connected for use shall
not be stored in the vicinity of this or any
other appliance.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, immediately call
your gas supplier or your fire
department.
E
F
63601
6/96
Advertisement
Table of Contents
Related Manuals for Weber 3400 LP
Summary of Contents for Weber 3400 LP
- Page 1 3400 Series LP Gas Barbecue Step-By-Step Instructions WARNING: Follow all leak check procedures carefully in this manual prior to barbecue operation. Do this even though the barbecue is assembled. NOTICE TO INSTALLER: These instructions must be left with the owner and the owner should keep them for future use.
-
Page 3: Supplies Needed
While we give much attention to our products, unfor- tunately an occasional error may occur. If a part is missing, do not go back to the store. Call the Weber Customer Service Center toll free 1-800-446-1071 to receive immediate assistance. Have your owner’s manual and serial number of the barbecue available for reference. - Page 4 Step 3 Reinstallation of Stainless Steel Flavorizer Bars, Cooking Grates and Warming Rack Set the long stainless steel Flavorizer bars side to side in the lower position of the cooking box, then set the short stainless steel Flavorizer bars, front to back in the upper position.
- Page 5 Step 5 Removal of LP Tank Note - You must remove tank and it's packaging before lifting grill out of lower carton. 1) Loosen tank lock wing nut and turn tank lock up out of the way. Tighten wing nut. Figure 9 (a). 2) Lift tank straight up.
-
Page 6: Install Lid
Step 8 Install Weber Warm-Up Basket Insert one end of the Weber Warm-Up Basket into the hole in the right end of the lid and the other end into the slot in the left end of the lid. Figure 12. -
Page 7: Fill Lp Tank
If the tank manufacturer has not resolved the issue to your satisfaction, then call Weber-Stephen Products Co., Customer Service Center. To fill, take the LP tank to an RV center or look-up gas- propane in the phone book for other sources of LP gas. - Page 8 Remove the burner control knobs. Figure 15 (a). While standing at the right end of the barbecue, grasp the under the edge of the control panel at the control panel push-in buttons and slide along the frame toward you. Figure 15 (b). Lift off the control panel. Figure 15 Step 12 Check that items are secured...
-
Page 9: Connect Filled Lp Tank
Check that the tank panel tabs are in their slots in the frame brace. Figure 18. Figure 18 Check that all the burner valves are off. Valves are shipped in the OFF position, but you should check to be sure. Put the knob on each valve. Check by pushing down and turning clockwise. - Page 10 The burners have been flame tested. As a safety precaution you should recheck all fittings for leaks before using your Weber Genesis Gas Barbecue. Shipping and handling may have loosened or damaged a gas fitting.
- Page 11 Step 15 Put the control panel back on Set the control panel in place over both frame braces. (Hold the Crossover Ignition button up while setting the control panel in place.) Place your thumbs over the control panel push-in buttons, and push them into the frame brace until they snap into place.
- Page 12 15-16 18-20 29 30 31 32 34 35 61-64 65-66...
-
Page 13: Parts List
Parts can be ordered directly from Weber-Stephen Products Company by phone or mail. Note - Do not return parts to Weber-Stephen Products Co. without first contacting the Customer Service Center by phone or mail. Returning the part may not be necessary. - Page 16 INAL HANKS hank you for choosing a Weber Barbecue. Our family here at Weber has worked hard to produce the highest quality products for your satisfaction. While we give much attention to our products, an occasional error may occur. Our knowledgeable Customer Service staff is prepared to help you with any problems with parts or assembly.
