Platinum Series II
2200 LP
Platinum Series II
3200 LP
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
WARNING: Follow all leak check
procedures carefully in this manual
prior to barbecue operation. Do this
even if barbecue was dealer assembled.
NOTICE TO INSTALLER: These instructions
must be left with the owner and the owner
should keep them for future use.
PLATINUM
Platinum Series II
3400 LP
SERIES II
™
LP Gas Barbecues
Step-By-Step Guide
National
PROPANEGAS
Association
FOR YOUR SAFETY
1. Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
2. An LP tank not connected for use shall
not be stored in the vicinity of this or
any other appliance.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, immediately call your
gas supplier or your fire department.
CANADIAN GAS ASSOCIATION
®
A P P R O V E D
R
97460
12/96
Advertisement
Table of Contents
Related Manuals for Weber Platinum 2200 LP
Summary of Contents for Weber Platinum 2200 LP
- Page 1 Platinum Series II 2200 LP Platinum Series II 3200 LP THIS GAS APPLIANCE IS DESIGNED FOR OUTDOOR USE ONLY. WARNING: Follow all leak check procedures carefully in this manual prior to barbecue operation. Do this even if barbecue was dealer assembled.
-
Page 2: Tools Needed
While we give much attention to our products, unfor- tunately an occasional error may occur. If a part is missing, do not go back to the store. Call the Weber Customer Service Center toll free 1-800-446-1071 to receive immediate assistance. Have your owner’s manual and serial number of the barbecue available for reference. - Page 3 REMOVE PACKAGED PARTS FROM LOWER CARTON Left work surface Right work surface (Platinum Series II 2200 LP only) Side burner (Platinum Series II 3200 LP and 3400 LP only) Note: For the Platinum Series II 3200 and 3400, remove the white plastic on the stainless steel of the side burner.
-
Page 4: Flavorizer Bars
INSTALLATION OF CATCH PAN INTO BOTTOM TRAY Hook the ends of the catch pan holder into the hole in the bottom tray. Figure 3. The front of the catch pan holder must be on the same side as the finger grip of the bottom tray. -
Page 5: Install Warm-Up Basket
REINSTALLATION OF COOKING GRATES Note: The cooking grates are already in place. This step is only for reinstallation. Set the cooking grates onto the ledges in the cooking box. The open "U" of the cooking grate goes down. Figure 6. Figure 6 INSTALLATION OF WARMING RACK... -
Page 6: Set Lp Fuel Scale
SET LP FUEL SCALE You will need: LP tank (empty). Note - For accuracy, the fuel scale must be set with an empty tank. We utilize various LP tank manufacturers. Some of the tanks we receive have differing top collar assemblies. (The top collar is the metal protective ring around the valve.) One series of tanks mounts with the valve facing front. -
Page 7: General Tank Information
This vent should be free of dirt, grease, bugs etc. The LP tank and connections supplied with your Weber Gas Barbecue have been designed and tested to meet government, American Gas Association and Underwriters Laboratories requirements. - Page 8 If you have the Platinum Series II 2200, continue to step “Install Work Surfaces” on this page. If you have the Platinum Series II 3200, go to step “Install Work Surface and Side Burner” on page 9. If you have the Platinum Series II 3400, go to step “Install Work Surface and Side Burner”...
- Page 9 INSTALL WORK SURFACE AND SIDE BURNER FOR THE PLATINUM SERIES II 3200 You will need... left work surface, side burner assembly, four 1/4-20 x 1/2 inch bolts, four nylon washers and a 7/16 inch or adjustable wrench. Insert the left work surface tabs in the slots to the left of the cooking box.
- Page 10 INSTALL WORK SURFACE AND SIDE BURNER FOR THE PLATINUM SERIES II 3200 (CONTINUED) Check that the side burner is properly assembled. Windshield Burner cap Burner ring Grate Lugs Slots Igniter electrode Figure 16 Burner head Burner base Burner orifice WARNING: Set the burner ring onto the burner head. Rotate the burner ring until the four lugs on the burner ring are seated in the four slots on the burner head.
- Page 11 INSTALL WORK SURFACE AND SIDE BURNER FOR THE PLATINUM SERIES II 3400 You will need... left work surface, side burner assembly, four 1/4-20 x 1/2 inch bolts, four nylon washers and a 7/16 inch or adjustable wrench. Insert the left work surface tabs in the slots to the left of the cooking box.
- Page 12 INSTALL WORK SURFACE AND SIDE BURNER FOR THE PLATINUM SERIES II 3400 (CONTINUED) Route the side burner hose around the tank panel so it will not interfere with scale indicator rod. The side burner hose is connected in the following manner: Slide back the collar of the quick disconnect on the manifold.
-
Page 13: Check That All Burner Valves Are Off
INSTALL BOTTOM RACK Place the bottom rack between the frame supports. Figure 22. Figure 22 For the Platinum Series II 3400, place the bottom rack under the cart between the frame supports. Lift up one end of the rack so it clears the crosspiece. Continue to lift until the opposite end clears the opposite crosspiece. -
Page 14: Connect Filled Lp Tank
CONNECT FILLED LP TANK WARNING: Make sure that the LP tank valve is closed. Close by turning clockwise. Hook the LP tank onto the fuel scale. Loosen the tank lock wing nut. Swing the tank lock down. Tighten the wing nut. -
Page 15: Check For Gas Leaks
CHECK FOR GAS LEAKS WARNING The gas connections of your Weber Gas Barbecue have been factory tested. We do however recommend that you leak check all gas connections before operating your Weber Gas Barbecue. Remove the knobs from the control panel. Figure 27. - Page 16 If a leak persists after retightening the fitting, turn OFF the gas. DO NOT OPERATE THE BARBECUE. Contact Weber-Stephen Customer Service. b) Regulator to tank connection. Figure 30 (b). c) Manifold to side burner hose connection.
- Page 17 REINSTALL THE CONTROL PANEL Set the control panel in place over both frame braces. (Hold the Crossover Ignition button up while setting the control panel in place.) Slip washers on Phillips screws, insert into holes as shown, and tighten. Figure 31 (a). Push on the burner control knobs.
