Weber Genesis 310 Owner's Manual

Natural gas grill
Hide thumbs Also See for Genesis 310:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual
GAS GRILL
Natural Gas Grill Owner's Guide
ESNA
Guía del Propietario de la Barbacoa de Gas Natural - Pg. 23
Guide de l'utilisateur du barbecue au gaz naturel - Pg. 43
310
YOU MUST READ THIS OWNER'S GUIDE
BEFORE OPERATING YOUR GAS GRILL.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
Leaking gas may cause a fire or explosion
which can cause serious bodily injury or
death, or damage to property.
WARNING:
1. Do not store or use gasoline or other
flammable liquids or vapors in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
#56515
WARNING: Follow all leak-check
procedures carefully in this manual prior
to barbecue operation. Do this even if the
barbecue was dealer-assembled.
NOTICE TO INSTALLER: These instructions
must be left with the owner and the owner
should keep them for future use.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
WARNING: Do not ignite this appliance
without first reading the BURNER
IGNITION sections of this manual.
56515 09/17/10 NG
US ENGLISH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Genesis 310 and is the answer not in the manual?

Questions and answers

Related Manuals for Weber Genesis 310

Summary of Contents for Weber Genesis 310

  • Page 1 GAS GRILL Natural Gas Grill Owner’s Guide ESNA Guía del Propietario de la Barbacoa de Gas Natural - Pg. 23 Guide de l’utilisateur du barbecue au gaz naturel - Pg. 43 #56515 YOU MUST READ THIS OWNER’S GUIDE WARNING: Follow all leak-check BEFORE OPERATING YOUR GAS GRILL.

  • Page 2: Warnings

    Do not attempt to disconnect the gas regulator and hose attempting to relight, using the igniting instructions. assembly or any gas fitting while your barbecue is in Do not use charcoal or lava rock in your Weber ® operation. barbecue.

  • Page 3: Table Of Contents

    CLEANING ............17 WEBER ®...

  • Page 4: E Xploded View 310

    v E XPLODED VIEW 310 • DIAGRAMA DE DESPIECE 310 • VUE ECLATEE 310 Genesis_310_NG_US_061110...

  • Page 5: Exploded View List 310

    Rueda giratoria con bloqueo Plateau de récupération des graisses amovible Pinces de retenue des câbles Roulette à verrouillage 14. Rear Frame Support 28. Control Panel Soporte posterior del bastidor Tablero de control Support du châssis arrière Panneau de commande WWW.WEBER.COM ®...

  • Page 6: Warranty

    Weber does not authorize any person or company to assume for it any other obligation or liability in connection with the sale, installation, use, removal, return, or replacement of its equipment; and no such representations are binding on Weber.

  • Page 7: General Instructions

    Standards CAN/ CGA-B149.1 (Installation Code for Natural Gas Burning Appliances and Equipment). STORAGE AND/OR NONUSE ® • The gas must be turned off at the natural gas supply when the Weber gas barbecue is not in use. • When the Weber ®...

  • Page 8: Gas Instructions (Model 310)

    • The quick disconnect connects to a 3/8" NPT thread from the gas source. The quick disconnect fitting is a hand-operated device that automatically shuts off the flow of This is a typical installation of a Weber ® natural gas barbecue.

  • Page 9: Gas Instructions

    Your grill operates at 7" of water column pressure. If replacement of the hose becomes necessary, factory specified parts are required. See your local dealer. For safety and design reasons, the conversion of a Weber ® grill from operation using Natural gas to operation using LP gas is not allowed.

  • Page 10: Check For Gas Leaks

    Note: All factory-made connections have been thoroughly checked for gas leaks. The burners have been flame-tested. As a safety precaution however, you should recheck all fittings for leaks before using your Weber® gas barbecue. Shipping and handling may loosen or damage a gas fitting.
  • Page 11 Contact the Customer Service Representative in your area using the contact information on our web site. ® Log onto www.weber.com D) Flexible Hose to Quick Disconnect connection (4). E) Valves to manifold connections (5). WARNING: If there is a leak at connections (4 or 5), turn OFF the gas.

  • Page 12: Before Using The Grill

    If the hose is found to be damaged in any way, do not use the barbecue. Replace ® using only Weber authorized replacement hose. Contact the Customer Service Representative in your area using the contact information on our web site.

  • Page 13: Main Burner Ignition & Usage

    WARNING: Check hose before each use of barbecue for nicks, cracking, abrasions or cuts. If the hose is found to be damaged in any way, do not use the barbecue. Replace using only Weber ® authorized replacement hose. Contact the Customer Service Representative in your area using the contact information on our web site.

  • Page 14: Main Burner Manual Ignition

    MAIN BURNER IGNITION & USAGE MAIN BURNER MANUAL IGNITION DANGER Failure to open the lid while igniting the barbecue’s burners, or not waiting five minutes to allow the gas to clear if the barbecue does not light, may result in an explosive flare-up which can cause serious bodily injury or death.

  • Page 15: Grilling Tips & Helpful Hints

    • Using a timer will help to alert you when “well-done” is about to become “over- done.” Note: If grill looses heat while cooking refer to the troubleshooting section of this manual. WARNING: Do not move the Weber ® gas barbecue when operating or while barbecue is hot.

  • Page 16: Troubleshooting

    Check the adjustment pin on the bottom of each door. Loosen adjustment nut/s. Slide door/s until aligned. Tighten nut. If problems cannot be corrected by using these methods, please contact the Customer Service Representative in your area using the contact information on our ® web site. Log onto www.weber.com...

  • Page 17: Maintenance

    Customer Service Representative in your area using the contact information on in a fire, which can cause serious bodily injury or death, and ® our website. Log onto www.weber.com cause damage to property. Catch pan - Disposable foil trays are available, or you can line the catch pan with aluminum foil.

  • Page 18: Burner Tubes Cleaning Or Replacement

    MAINTENANCE BURNER TUBES CLEANING OR REPLACEMENT You will need: Phillips screwdriver and flathead screwdriver. ® A) Your Weber gas barbecue must be OFF and cool. B) Turn gas OFF at source. ® C) Remove cookbox components - warming rack, grates and Flavorizer bars.
  • Page 19 Your actions, if you fail to follow this Product Warning, may cause a fire, an explosion, or structural failure resulting in serious personal injury or death as well as damage to property. WWW.WEBER.COM ®...

  • Page 20: Electronic Ignition System Operations

    If the Electronic Ignition System still fails to light, contact the Customer Service Representative in your area using the contact information on our web site. Log ® onto www.weber.com IGNITER MODULE WIRE GUIDE 310/320 Wire End & Terminal Color Burner Tube...

  • Page 21: Annual Maintenance

    Insect screens and burners are clean, replace the burners. If the Spider/Insect screen becomes damaged or cannot be cleaned, please contact the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber.com ® Burner Flame Pattern ®...
  • Page 22 ATTENTION: This product has been safety tested and is only certified for use in a specific country. Refer to country designation located on outer carton. These parts may be gas carrying or gas burning components. Please contact Weber-Stephen Products Co., Customer Service Department for genuine Weber-Stephen Products Co. replacement part(s) information.
  • Page 23 MISE EN GARDE : Ne tentez pas d’effectuer des réparations sur des éléments contenant du gaz ou sur des éléments dont la combustion produit du gaz sans contacter le service clientèle de Weber-Stephen Products Co. Si vous ne suivez pas la présente Mise en garde relative au produit, vos actions risquent de provoquer un incendie ou une explosion entraînant des blessures physiques graves voire un décès ainsi que des dégâts matériels.
