SUMMIT
GAS GRILL
LP Gas Grill Owner's Guide
YOU MUST READ THIS OWNERS GUIDE
BEFORE OPERATING YOUR GAS GRILL
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open fl ames.
3. Open lid
4. If odor continues, keep away from the
appliance and immediately call your
gas supplier or your fi re department.
Leaking gas may cause a fi re or explosion
which can cause serious bodily injury or
death, or damage to property.
WARNING
1. Do not store spare liquid propane
cylinder within 10 feet (3m) of this
appliance.
2. Do not store or use gasoline or other
fl ammable liquids or vapors within 25
feet (8m) of this appliance.
®
#38008
WARNING: Follow all leak-check
procedures carefully in this manual
prior to barbecue operation. Do this
even if the barbecue was dealer-
assembled.
NOTICE TO INSTALLER: These
instructions must be left with the owner
and the owner should keep them for future
use.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
WARNING: Do not try to light this
appliance without reading the "Lighting"
Instructions section of this manual.
38008 US 04/12/05
LP
US ENGLISH

Advertisement

Table of Contents
loading

Related Manuals for Weber Summit Series

Summary of Contents for Weber Summit Series

  • Page 1 SUMMIT ® GAS GRILL LP Gas Grill Owner’s Guide #38008 YOU MUST READ THIS OWNERS GUIDE WARNING: Follow all leak-check BEFORE OPERATING YOUR GAS GRILL procedures carefully in this manual prior to barbecue operation. Do this even if the barbecue was dealer- assembled.

  • Page 2: Dangers And Warnings

    Do not use a fl ame to check for gas leaks. ® Combustible materials should never be within 24 inches of the top, bottom, back or sides of your Weber barbecue. Do not put a barbecue cover or anything fl ammable on, or in the storage area under the barbecue.

  • Page 3: Warranty

    Limited Warranty. ©2003 The following trademarks are registered in the name of Weber-Stephen Products Co., an Illinois corporation, located at 200 East Daniels Road, Palatine, Illinois 60067 U.S.A. Australia; Smokey Joe, Weber, Kettle Silhouette , Genesis, Austria;...

  • Page 4: General Instructions

    Weber gas barbecue you can grill, barbecue, roast and bake with results • The gas must be turned off at the liquid propane cylinder when the Weber ® that are diffi cult to duplicate with indoor kitchen appliances. The closed lid gas barbecue is not in use.

  • Page 5: Grilling Methods

    Customer Service Representative in your area using the Note: The temperature inside your cooking box for the fi rst few uses, while contact information on our website. Log onto www.weber.com ® surfaces are still very refl ective, may be hotter than those shown in your cookbook.

  • Page 6: Gas Instructions

    You will need: LP cylinder, a soap and water solution and a rag or brush to apply it. Turn the LP cylinder so the opening of the valve is either to the front, side or rear of the Weber ® gas barbecue. Lift and hook the cylinder onto the fuel gauge.
  • Page 7 If leak does not stop, Contact the Customer Service at 1-800-446-1071 or locate the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber.com ® . Do not use the barbecue.
  • Page 8 Note - All factory-made connections have been thoroughly checked for gas leaks. The burners have been fl ame-tested. As a safety precaution however, you should recheck all fi ttings for leaks before using your Weber Gas Barbecue. Shipping and handling may loosen or damage a gas fi tting.
  • Page 9 If a leak persists after re-tightening the fi tting, turn OFF the gas. DO NOT OPERATE THE GRILL. Contact the Customer Service Representative in your area using the contact information on our web site. Log onto www.weber.com ® Regulator to cylinder connection. Hose to regulator connection.

  • Page 10: Reinstall Control Panel

    GAS INSTRUCTIONS REINSTALL CONTROL PANEL Parts required: control panel, screws, and burner control knobs. Place the control panel back onto the control panel brackets on either side of the front of the cooking box. Line up screws with screw holes on both the control panel and control panel brackets.

  • Page 11: Refilling The Liquid Propane Cylinder

    GAS INSTRUCTIONS REFILLING THE LIQUID PROPANE CYLINDER We recommend that you refi ll the LP cylinder before it is completely empty. Removal of the LP cylinder Close cylinder valve (turn clockwise). Unscrew regulator coupling by turning counterclockwise, by hand only. Loosen cylinder lock wing nut and turn cylinder lock up out of the way.
  • Page 12 This vent should be free of dirt, grease, bugs etc. ® • The gas connections supplied with your Weber gas barbecue have been designed and tested to meet 100% CSA and ANSI requirements. WARNING: Replacement LP tanks must match the regulator connection supplied with this barbecue.

  • Page 13: Direct Cooking

    OPERATING INSTRUCTIONS GRILLING METHODS Covered cooking All grilling is done with the lid down to provide uniform, evenly circulated heat. With the lid closed, the Summit ® gas grill cooks much like a convection NOTE: If grill looses heat while cooking refer to the troubleshooting oven.

  • Page 14: Indirect Cooking

    OPERATING INSTRUCTIONS INDIRECT COOKING The Indirect Method is similar to roasting, but with the added benefi ts of that grilled texture, fl avor, and appearance you can’t get from an oven. To set up for Indirect cooking, gas burners are lit on either side of the food but not directly beneath it.
  • Page 15 WARNING: Check hose before each use of barbecue for nicks, cracking, abrasions or cuts. If the hose is found to be damaged in any way, do not use the barbecue. Replace using only Weber ® authorized replacement hose. Contact the Customer Service Representative...

  • Page 16: Manual Lighting

    OPERATING INSTRUCTIONS DANGER MAIN BURNER LIGHTING When the “excess gas fl ow control” feature is activated, a small amount of gas is still fl owing to the burners. After turning OFF the cylinder knobs, wait at least 5 minutes for the gas to clear before attempting to light the barbecue.
  • Page 17 OPERATING INSTRUCTIONS DANGER MAIN BURNER LIGHTING When the “excess gas fl ow control” feature is activated, a small amount of gas is still fl owing to the burners. After turning OFF the cylinder and burner control knobs, wait at least 5 minutes for the gas to clear before attempting to light the barbecue.

  • Page 18: Lighting With Igniter

    OPERATING INSTRUCTIONS SIDE BURNER LIGHTING INSTRUCTIONS LIGHTING WITH IGNITER DANGER SUMMIT B, C, D ® Failure to open the lid while igniting the side burner, or not waiting 5 minutes to allow the gas to clear if the side burner does not light, may result in an explosive fl...
  • Page 19 OPERATING INSTRUCTIONS MANUALLY LIGHTING SIDE BURNER MANUAL LIGHTING SUMMIT B, Cc , D DANGER ® Failure to open the lid while igniting the side burner, or not waiting 5 minutes to allow the gas to clear if the side burner does not light, may result in an explosive fl ame- up which can cause serious bodily injury or death.

  • Page 20: Using The Smoker

    OPERATING INSTRUCTIONS USING THE SMOKER The smoker uses presoaked wood chips. For best results with faster cooking foods like steaks, burgers and chops, etc., we recommend using fi ner wood chips because they ignite and create smoke faster. For longer cooking foods such as roasts, chicken and turkeys, etc., we recommend using larger wood chunks because they ignite slowly and provide smoke for a longer period of time.

  • Page 21: Lighting The Smoker Burner

    ® WARNING: Check hose before each use of grill for nicks, cracking, abrasions or cuts. If the hose is found to be damaged in any way, do not use the grill. Replace using only Weber ® authorized replacement 2,3,9 hose. Contact the Customer Service Representative in your area using the contact information on our web ®...

  • Page 22: Manually Lighting The Smoker Burner

    C, D nicks, cracking, abrasions or cuts. If the hose is found ® to be damaged in any way, do not use the grill. Replace using only Weber ® authorized replacement hose. Contact the Customer Service Representative in your area using the contact information on our web site.
  • Page 23 OPERATING INSTRUCTIONS WARNING: The burner control knobs must be in SUMMIT C, D ® the OFF position before turning on the liquid propane cylinder tank valve. If they are not in the OFF position, when you turn on the LP cylinder valve, the "excess gas fl...

  • Page 24: Rotisserie Assembly

    OPERATING INSTRUCTIONS ROTISSERIE ASSEMBLY SUMMIT ® Parts required: rotisserie motor bracket(1), rotisserie motor(1), rotisserie shaft(1), spit forks(4) and fork screws (4). Install the motor bracket Attach the stainless steel motor bracket to the left side of the cooking box, using the 1/4-20 fasteners and the 1/4-20 Keps nuts. Attach the motor.

  • Page 25: Using The Rotisserie

    OPERATING INSTRUCTIONS USING THE ROTISSERIE • Do not expose to rain. • To reduce the risk of electric shock, keep extension cord connection dry and off the ground. Note - Before using your rotisserie, measure your food at the widest point. If it exceeds 9 1/2”...

  • Page 26: Lighting The Rotisserie Burner

    WARNING: Check hose before each use of grill for nicks, cracking, abrasions or cuts. If the hose is found to be damaged in any way, do not use the grill. Replace using only a Weber ® authorized replacement hose. Contact the Customer Service Representative in your area using the contact information on our web site.
  • Page 27 OPERATING INSTRUCTIONS Make sure all burner control knobs are turned OFF. (Push control knob SUMMIT ® down and turn clockwise to ensure that it is in the OFF position.) WARNING: The burner control knobs must be in the OFF position before turning on the liquid propane cylinder tank valve.

  • Page 28: Manually Lighting The Rotisserie Burner

    If the hose is found to be damaged in any way, do not use the grill. Replace *The grill illustrated may have slight differences than ® using only a Weber authorized replacement hose. the model purchased. Contact the Customer Service Representative in your area using the contact information on our web site.
  • Page 29 OPERATING INSTRUCTIONS WARNING: The burner control knobs must be in the SUMMIT ® OFF position before turning on the liquid propane cylinder tank valve. If they are not in the OFF position, when you turn on the LP cylinder valve, the "excess gas fl...
  • Page 30 fl aking off. THIS IS NOT A DEFECT. If problems cannot be corrected by using these methods, please contact the Customer Service Representative in your area ® using the contact information on our web site. Log onto www.weber.com...

  • Page 31: Side Burner Troubleshooting

    If problems cannot be corrected by using these methods, please contact the Customer Service Representative in your area ® using the contact information on our web site. Log onto www.weber.com SIDE BURNER MAINTENANCE WARNING: All gas controls and supply valves should be in the OFF position.

  • Page 32: Rotisserie Troubleshooting

    Reconnect the regulator to the cylinder. Turn cylinder valve on slowly. Refer to “Lighting Instructions”. If problems cannot be corrected by using these methods, please contact the Customer Service Representative in your ® area using the contact information on our web site. Log onto www.weber.com...

  • Page 33: Weber ® Spider /Insect Screens

    Lightly tap the burner to get debris and dirt out of the burner tube. Once the spider/insect screens and burners are clean replace the burners. If the spider/insect screen becomes damaged or cannot be cleaned, call Weber-Stephen Products Customer Service for replacement parts.

  • Page 34: Main Burner Flame Pattern

    MAINTENANCE MAIN BURNER FLAME PATTERN The Weber ® gas barbecue burners have been factory set for the correct air and gas mixture. The correct fl ame pattern is shown. Burner tube Tips occasionally fl icker yellow Light blue Dark blue If the fl...
  • Page 35 MAINTENANCE Disconnect the Thermocouple from the IR Burner valve. Remove screws from the manifold assembly: (a) Locate the screws on both sides of the manifold frame. (b) Remove the screws from manifold frame. (a ) (b ) (b ) Pull manifold assembly out from the manifold frame. ®...

  • Page 36: Crossover ® Ignition System Operations

    ® ignition system still fails to light, contact the Customer (2 ) Service Representative in your area using the contact information on our web site. Log onto www.weber.com ® REPLACE IGNITER BATTERIES Parts required: 1 AA alkaline battery per igniter.
