LP Gas Grill Owner's Guide
Register your grill online at www.weber.com
YOU MUST READ THIS OWNER'S GUIDE
BEFORE OPERATING YOUR GAS GRILL
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open fl ames.
3. Open lid.
4. If odour continues, keep away from the
appliance and immediately call your gas
supplier or your fi re service.
Leaking gas may cause a fi re or explosion,
which can cause serious bodily injury or
death, or damage to property.
WARNING
1. Do not store or use petrol or other
fl ammable vapours and liquids in the
vicinity of this or any other appliance.
2. A gas supply cylinder not connected for
use should not be stored in the vicinity
of this or any other appliance.
Assembly - Pg 9
PLACE STICKER HERE
INFORMATION FOR THE INSTALLER:
This manual must remain with the owner,
who should keep it for future use.
OUTDOOR USE ONLY.
0845
WARNING: Follow all leak-check
procedures carefully in this manual
before operating barbecue. Do this even
if barbecue was dealer assembled.
WARNING: Do not try to light the Weber
gas barbecue without fi rst reading the
"Lighting" instructions in this manual.
0845BQ-0033
#41081
®
41081 11/16/07 LP
GB - ENGLISH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Weber 300

  • Page 1 DANGER If you smell gas: ® WARNING: Do not try to light the Weber 1. Shut off gas to the appliance. gas barbecue without fi rst reading the 2. Extinguish any open fl ames. “Lighting” instructions in this manual.
  • Page 2: Dangers And Warnings

    Improper assembly may be dangerous. Please carefully follow the assembly instructions in this manual. After a period of storage and/or non-use, the Weber Gas Barbecue should be checked for gas leaks and burner obstructions before use. See instructions in this manual for correct procedures.
  • Page 3: Warranty

    Weber’s satisfaction, that they are Weber does not authorise any person or company to assume for it any other obligation or liability in defective. Before returning any parts, contact the Customer service representative in your region using connection with the sale, installation, use, removal, return, or replacement of its equipment;...
  • Page 4: Exploded View- Q300

    EXPLODED VIEW- Q300 EXPLODED VIEW- Q300...
  • Page 5: Exploded View List- Q300

    EXPLODED VIEW LIST- Q300 EXPLODED VIEW LIST- Q300 Swing-Up Work Surface 13. Small Control Knob 25. Valve & Manifold - Regulator Assembly Thermometer Assembly 14. Disposable Drip Pan 26. Manifold-Hardware Handle Assembly 15. ¼ x 20 x 1½ ˝ Truss Head Screw 27.
  • Page 6: Exploded View- Q320

    EXPLODED VIEW- Q320 EXPLODED VIEW- Q320 5860XX_Q320_EURO_100207...
  • Page 7: Exploded View List- Q320

    EXPLODED VIEW LIST- Q320 EXPLODED VIEW LIST- Q320 Swing-Up Work Surface 13. Large Control Knob 25. Fire box Thermometer Assembly 14. Small Control Knob 26. Fire Box Mounting Hardware Handle/Light Assembly 15. Disposable Drip Pan 27. Valve & Manifold - Regulator Assembly Handle Assembly 16.
  • Page 8: Parts List

    PARTS LIST PARTS LIST TOOLS NEEDED: STAINLESS STEEL PAN HEAD TRUSS HEAD SCREW PHILLIPS SCREW Q320...
  • Page 9 ASSEMBLY ASSEMBLY Wheel Frame goes on the right. Lighting instruction sticker faces forward.
  • Page 10 ASSEMBLY ASSEMBLY...
  • Page 11 ASSEMBLY ASSEMBLY...
  • Page 12 ASSEMBLY ASSEMBLY ® 1) Uncoil the hose and regulator of the Weber Q™ 300/320. 2) Remove leg screw and secure hose and retention clip(1) to cart leg. WARNING: The hose must be secured to the cart leg by the hose retention clip. Failure to do so could cause damage to hose resulting in a fi...
  • Page 13 ASSEMBLY ASSEMBLY CAUTION: Read this step carefully before installing tables. 1) Place top right post of side table into right side cradle slot(A) approximately one inch behind cradle slot opening(B). 2) Place opposite (top left) post into the opposite cradle slot(C). Using both hands, apply pressure towards the right until the top left post pivots into cradle slot.
  • Page 14 ASSEMBLY ASSEMBLY...
  • Page 15 Q320 Requires 3 “AAA” alkaline batteries (not Use alkaline batteries only. Do not mix old and new batteries or different types of batteries (standard, alkaline or rechargeable). If you do not plan to use the Weber Q included) Grill Out ™...
  • Page 16 You may hear a rattle in lightpod. This is normal. ™ The Weber Q Grill Out Handle Light has a “Tilt Sensor”: Lid up - ON / Lid Closed - OFF. The power button(a) activates or deactivates the “Tilt Sensor.” For daytime use, deactivate the sensor by pressing power button(a).
  • Page 17 ASSEMBLY ASSEMBLY Q320 Q320...
  • Page 18: General Instructions

    ® • The gas must be turned off at the liquid propane cylinder when the Weber WARNING: Do not move the appliance while it is alight. barbecue is not in use. WARNING: Wear protective gloves when using this ®...
  • Page 19 Remove excess grease to avoid a grease fi re in to sear steaks, you would set both burners at H (high). Then to complete cooking, you would set OUTSIDE burner at M (medium). Refer to your Weber ®...
  • Page 20: Gas Instructions

    GAS INSTRUCTIONS GAS INSTRUCTIONS PURCHASE A FULL CYLINDER OF GAS FROM YOUR GAS DEALER The cylinder must always be installed, transported and stored in an upright position. Never allow the cylinder to drop or be handled carelessly. Never store cylinder where temperatures can exceed 51°...
  • Page 21: Connecting The Liquid Propane Cylinder

    GAS INSTRUCTIONS GAS INSTRUCTIONS CONNECTING THE LIQUID PROPANE CYLINDER WARNING: Make sure that the LP cylinder valve is closed. Close by turning valve clockwise. DANGER Do not use an open fl ame to check for gas leaks. Be sure there are no sparks or open fl ames in the area while you check for leaks.
  • Page 22 If leak does not stop, contact the Customer Service Representative in your area using the contact information on our website. Log onto www.weber.com ® 5) When leak checking is complete, turn gas supply OFF at the source and rinse connections with water.
  • Page 23: Refilling The Liquid Propane Cylinder

    GAS INSTRUCTIONS GAS INSTRUCTIONS REFILLING THE LIQUID PROPANE CYLINDER We recommend that you refi ll the LP cylinder before it is completely empty. To refi ll, take LP cylinder to a “Gas Propane” dealer. Removal of the gas supply cylinder: 1) Shut off gas supply.
  • Page 24: Operating Instructions

    If the hose is found to Summary lighting instructions are posted on the cart leg under the control knobs (L). be damaged in any way, do not use the barbecue. Replace using only Weber ® authorized replacement hose. Contact...
  • Page 25: Manual Lighting

    OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS MANUAL LIGHTING DANGER Failure to open the lid while igniting the barbecue’s burners, or not waiting 5 minutes to allow the gas to clear if the barbecue does not light, may result in an explosive fl ame-up which can cause serious bodily injury or death.
  • Page 26: Troubleshooting

    fl ickering fl ame in the HIGH position. -or- Instructions”. Barbecue temperature only reaches 250˚F (121˚C) to 300˚ F (148˚C) in the HIGH position. Burner does not light, or fl ame is low in HIGH Is LP fuel low or empty? Refi...
  • Page 27: Annual Maintenance

    Insect Screens and burners are clean, replace the burners. If the Spider/Insect Screen becomes damaged or cannot be cleaned, please contact the Customer Service Representative in your area using the contact information on our web ® site. Log onto www.weber.com...
  • Page 28: Main Burner Flame Pattern

    MAINTENANCE MAINTENANCE MAIN BURNER FLAME PATTERN The Weber ® gas barbecue burners have been factory set for the correct air and gas mixture. The correct fl ame pattern is shown. 1) Burner tube 2) Tips occasionally fl icker yellow 3) Light blue 4) Dark blue If the fl...
  • Page 29: Replacing Main Burners

    MAINTENANCE MAINTENANCE REPLACING MAIN BURNERS 1) Your Weber ® gas barbecue must be OFF and cool. 2) Turn gas OFF at source. 3) Open lid and remove the cooking grates. 4) Remove the 1/4 X 20 inch screw that holds the burner tube to the cookbox (x).
  • Page 30: Ignition System Operations

    If the Electronic Ignition System still fails to light, contact the Customer Service Representative in your area using the contact ® information on our web site. Log onto www.weber.com ELECTRONIC IGNITION SYSTEM REPLACEMENT If replacement of the ignition module is necessary it must be removed and disposed...
  • Page 32 WEBER-STEPHEN PRODUCTS CO. www.weber.com ® ©2008- The following trademarks are registered in the name of Weber-Stephen Products Co., an Illinois corporation, located at 200 East Daniels Road, Palatine, Illinois 60067 U.S.A. Australia; Smokey Joe, Weber, Kettle Silhouette , Genesis, Austria; Kettle Silhouette , Smokey Joe, Weber, Benelux;...
