METHVEN ROUND DRY RAIL Installation Manual

Step 4
• Fix the bottom rail connector to the wall at the
desired position using the mounting screw provided.
Check the top and bottom connectors are vertically
aligned.
Maximum centre distance between the
connectors is 650mm.
Step 5
• Screw the top end of the rail (with o-ring) into the top rail
bracket.
• Check the grub screws in the rail brackets are wound out.
• Match the rail brackets to the connectors and push rail
into place.
• Tighten grub screws top and bottom.
Step 6
• Connect one end of the hose to the bottom of the rail or the elbow.
• Screw the other end of the hose to the shower handset.
• Ensure there is a washer in both ends of the hose.
Care and Cleaning:
Never use abrasives or abrasive cleaning agents to clean this
product. Clean regularly with contamination free warm soapy
water and a damp soft cloth.
Periodically the filter washer should be removed from the end of
the shower hose and cleaned.
Methven warrants this product against manufacturing defects and that it is suitable for use
under the general operating conditions specified in this instruction sheet. However, regional
regulations apply and may affect your warranty. Please refer to www.methven.com or call
customer service for full details.
New Zealand
0800 804 222
439982
Australia
1300 638 483
ROUND WET/DRY RAIL
Installation Guide
Technical Specifications:
Inlet Connections:
All ½" BSP
* Regional specific regulations apply.
Please refer to your warranty statement at
www.methven.com
UK
0800 195 1602
ISSUE B
