Dalì liner Plus
Dalì liner plus 50lT with hose reel Code: SE9030
Dalì liner plus 30lT with hose reel Code: SE9031
for sanitation
Dalì liner plus 50lT Code: SE9032
Dalì liner plus 30lT Code: SE9033
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Larius Dali Liner Plus Series and is the answer not in the manual?

Questions and answers

Related Manuals for Samoa Larius Dali Liner Plus Series

Summary of Contents for Samoa Larius Dali Liner Plus Series

  • Page 1 w w w . l a r i u s . c o m Dalì liner Plus for sanitation Dalì liner plus 50lT with hose reel Code: SE9030 Dalì liner plus 30lT with hose reel Code: SE9031 Dalì liner plus 50lT Code: SE9032 Dalì...
  • Page 2 This manual is to be considered as an English language translation of the original manual in Italian. The manufacturer shall bear no responsibility for any damages or inconveniences that may arise due to the incorrect translation of the instructions contained within the original manual in Italian. Due to a constant product improvement programme, the factory reserves the right to modify technical details mentioned in this manual without prior notice.

  • Page 3: Table Of Contents

    DALì LINER PLUS FOR SANITATION Dalì liner Plus Horizontal street marking INDEX WARNINGS ................................P.2 USE ..................................P.3 WORKING PRINCIPLE ............................P.4 TECHNICAL DATA ..............................P.4 DESCRIPTION OF THE EQUIPMENT ........................P.6 TRANSPORT AND UNPACKING ..........................P.8 CONDITIONS OF GUARANTEE ..........................P.8 SAFETY RULES ..............................

  • Page 4: Awarnings

    DALì LINER PLUS FOR SANITATION WARNINGS The table below provides the meaning of the symbols used in this manual in relation to using, earthing, operating, maintaining, and repairing of this equipment. • Read this operator’s manual carefully before using the equipment. •...

  • Page 5: Buse

    DALì LINER PLUS FOR SANITATION SANITIZING FLUID APPLICATIONS ON: SANITIZING PRODUCTS SPRAYING EQUIPMENT The spraying of liquids under high pressure allows you cover- • Office buildings, public bodies ing large surfaces with sanitizing agents, thus reducing the • Industrial sheds, factories, logistics centers presence of bacteria, fungi and viruses.

  • Page 6: Cworking Principle

    DALì LINER PLUS FOR SANITATION WORKING PRINCIPLE In the LARIUS models, the sanitation product canister can be loaded directly upon The DALI LINER PLUS equipment was conceived and designed the undercarriage or else for sanitization. poured into the non-stick, 50 The internal combustion engine, mounted upon the undercarriage, L tank.
  • Page 7 DALì LINER PLUS FOR SANITATION Fig. 1D www.larius.com ED. 1 - 06/2020 - Cod. 150144...

  • Page 8: Edescription Of The Equipment

    DALì LINER PLUS FOR SANITATION DESCRIPTION OF THE EQUIPMENT Fig. 1E Pos. Description Pos. Description Tank Rotating wheel Recirculation tube Oil level cap combustion engine Manometer high pressure Petrol tank Filter Fuel tap OPEN/CLOSE Air cold starting Air filter Lock brake safety Rope starter motor Pumping group Belt tensioning screw...
  • Page 9 DALì LINER PLUS FOR SANITATION Fig. 2E Pos. Description Pos. Description Spraying gun feeding tube Driving pulley Product feeding tube Transmission belt pumping group Accelerator lever Cooling fan ON - OFF switch combustion engine Free pulley www.larius.com ED. 1 - 06/2020 - Cod. 150144...

  • Page 10: Ftransport And Unpacking

    DALì LINER PLUS FOR SANITATION TRANSPORT AND UNPACKING Each LARIUS sanitizing sprayer is supported by a 90-day warranty for the replacement of only • The packed parts should be handled as indicated in the the components. symbols and markings on the outside of the packing. No return.

  • Page 11: Isetting-Up

    DALì LINER PLUS FOR SANITATION SETTING-UP • NEVER MODIFY ANY PART IN THE EQUIPMENT. CHECK REGULARLY THE COMPONENTS OF THE SYSTEM. RE- PLACE THE PARTS DAMAGED OR WORN. TUBE CONNECTIONS • TIGHTEN AND CHECK ALL THE FITTINGS FOR CONNEC- TION BETWEEN PUMP, FLEXIBLE HOSE AND SPRAY GUN Collegamento tubo flessibile di ricircolo BEFORE USING THE EQUIPMENT.
  • Page 12 DALì LINER PLUS FOR SANITATION CONNECTION OF THE GUN STARTING THE COMBUSTION ENGINE To switch the internal combustion engine proceed as follows: • Connect the high pressure flexible hose (I5) to the fitting (I6) and the gun (I7) tightening the fittings strongly (the use of two •...
  • Page 13 DALì LINER PLUS FOR SANITATION Turn the equipment’s switch (I11) to ON (I). • • Fill the product tank with wash fluid. • Clean the inside of the tank with a brush. Fig. 8I • Bring the accelerator lever (I12) to about 1/2 of its run. Fig.
  • Page 14 DALì LINER PLUS FOR SANITATION • Open the recirculating-safety valve (I16). • Once the wash fluid has circulating enough, close the recirculating-safety valve (I16). CLOSE OPEN Fig. 17I Fig. 14I • Direct the gun (I14) against a container (I19) holding the trigger •...

  • Page 15: Jregulations

    DALì LINER PLUS FOR SANITATION PRODUCT PREPARATION MAKE SURE THE PRODUCT IS SUITABLE TO BE USED WITH A SPRAY GUN. • Mix and filter the product before using it. For filtration use CLOSE-MESH (rif. 214) and LARGE-MESH (rif. 215) LARIUS METEX braids.

  • Page 16: Lsanitation Operationes

    DALì LINER PLUS FOR SANITATION Turn the equipment knob (K2) on ON (I). ADJUSTING PUMP UNIT SPEED • • Move the motor acceleration lever (K5) gently to increase or decrease the speed of the pump. During the sanitation operation it is normally recommended to maintain the position of the accelerator lever (K5) at about 3/4 of its maximum run.

  • Page 17: Cleaning At The End Of Work

    DALì LINER PLUS FOR SANITATION NEVER point the spray gun at yourselves or at other people. The contact with the casting can use serious injuries. In case of injuries caused by the gun casting, seek immediate medical advice specifying the type of the product injected. Recirculating-safety valve: when working at the maximum pressure available, releasing the gun trigger sudden increases of pressure can occur.

  • Page 18: Ngeneral Maintenance

    DALì LINER PLUS FOR SANITATION ROUTINE MAINTENANCE • Empty all of the wash fluid from the tank and turn off the equipment. • Turn the pressure adjustment handle (L1) to minimum (pump CONTROL THE OIL LEVEL IN THE MOTOR stopped). •...
  • Page 19 DALì LINER PLUS FOR SANITATION SOSTITUZIONE OLIO IDRAULICO After operating for 100 hours, replace the oil in the pump; • Discharge the waste oil through the plug (O4) fitted at the bottom of the pump casing. • Clean the seals on the cap and replace it if worn. •...

  • Page 20: Correct Procedure Of Decompression

    DALì LINER PLUS FOR SANITATION CORRECT PROCEDURE OF • Point the gun (P4) at the receptacle (P5) used to collect the product and press the trigger to release the pressure. When DECOMPRESSION completed, activate the safety catch again. Turn the switch (P1) to "OFF" (0) to switch off the equipment. •...

  • Page 21: Problems And Solutions

    DALì LINER PLUS FOR SANITATION PROBLEMS AND SOLUTIONS Problem Cause Solution The equipment does not start The petrol manifold is closed; Open the petrol manifold; Engine is out of gas; Refill gas tank; Cold engine; Use choke; Setting valve faulty pressure; Verify and replace it, if necessary;...

  • Page 23: Spare Parts

    DALì LINER PLUS FOR SANITATION SPARE PARTS Tank 50L page 28 Transmission unit and positioning Complete product body Tank 20L page 26 page 27 page 29 Filter group Rif. 16200 page 32 Complete frame page 30 Complete pumpunit pages 22-23-24-25 www.larius.com ED.
  • Page 24 DALì LINER PLUS FOR SANITATION COMPLETE PUMP UNIT REF. 18306 WARNING: Always indicate code and quantity for each part required. www.larius.com ED. 1 - 06/2020 - Cod. 150144...
  • Page 25 DALì LINER PLUS FOR SANITATION Pos. Code Description Pos. Code Description 95114 Washer 18970 Complete hydraulic bpdy 18171 Screw 18919 18342 18321 Spacer 81014 18341 Ring 18320 Pulleya 42255 Bearing 96031 Screw 18314 Flange 95153 Washer 18324 Spacer 18316 Shaft 32024 Washer 18357...
  • Page 26 DALì LINER PLUS FOR SANITATION www.larius.com ED. 1 - 06/2020 - Cod. 150144...
  • Page 27 DALì LINER PLUS FOR SANITATION Pos. Code Description Pos. Code Description 18946 Dowel 18910 Identification plate 220V 50Hz 18901 Hydraulic body 18931 Identification plate 110V 60Hz 32018 Cylinder liner 18357 Petrol identification plate 32033 Piston insert 18933 Identification plate 380V 50Hz 33002/5 34020 Rivet...
  • Page 28 DALì LINER PLUS FOR SANITATION TRANSMISSION UNIT AND POSITIONING RIF. 18358 WARNING: Always indicate code and quantity for each part required. 5 6 7 Slide positioning complete Pos. Code Description Q. ty Pos. Code Description Q. ty 32024 Washer 18185 Motor 6151 Nut auto b.
  • Page 29 DALì LINER PLUS FOR SANITATION COMPLETE PRODUCT BODY REF. 18940 WARNING: Always indicate code and quantity for each part required. Pos. Code Description Pos. Code Description 33004 Screw 18915 Body 33017 Complete valve body 33033 Valve assembly 33018 Gas-ring 33026 Gasket 33019 Conical shutter...
  • Page 30 DALì LINER PLUS FOR SANITATION TANK 50L RIF. 4895 WARNING: Always indicate code and quantity for each part required. Pos. Code Description Pos. Code Description 4894 Spport 18249/1 Cover 18215 Elbow 85014 Filter 34107 Adaptor 18231 Union 95032 Union 18249 Tank 96099 Seal...
  • Page 31 DALì LINER PLUS FOR SANITATION TANK 20L RIF. 4890 Always indicate code and quantity for each part required. Pos. Code Description Pos. Code Description 4064 Tank 4111 Complete cover 4274 Belt 4314 Screw 69014 Screw 52017 4250 Base 4308 Ring 4834 Complete suction+delivery system 4309...
  • Page 32 DALì LINER PLUS FOR SANITATION COMPLETE FRAME 4874 WARNING: Always indicate code and quantity for each part required. www.larius.com ED. 1 - 06/2020 - Cod. 150144...
  • Page 33 DALì LINER PLUS FOR SANITATION Pos. Code Description Pos. Code Description 4265 Wire stopper 4256 Handle 4870 Plating 4865 Handlebar 4260 Pivoting wheel 4866 Block 4409 Screw Screw 7043 + 32005 95096 Washer Washer 4872 Plate 4825 Plate 4871 Plate 4824 Plate 4867...

  • Page 34: Xfilter Group

    DALì LINER PLUS FOR SANITATION FILTER GROUP REF. 16200 WARNING: Always indicate code and quantity for each part required. Pos. Code Description Q. tà Pos. Code Description Q. tà 96203 Gasket 33008 Manometer 0-400 bar 96204 Filter Base 16201 Filter tank 96026 Union 96020...

  • Page 35: Yaccessories

    DALì LINER PLUS FOR SANITATION ACCESSORIES suCTiOn sYsTeM SE9040 3350/1 SE9041 Code SE9040 Suction tube for 30 lt drums Code 3350/1 Suction tube for 200 lt drums Code SE9041 Suction tube for 1000 lt drums FilTers MesH Code 85014 FILTER 40 MESH Code 85012 FILTER 20 MESH Code 37215...
  • Page 36 DALì LINER PLUS FOR SANITATION aT250 airless Gun for sanitation High pressure spraying gun, max 250 bars. It includes the spraying nozzle and the 1/4” swivel fitting to connect to the tube. Code SE9050 Connection BSPP 1/4’’ Nozzle SFC 13-60 Code SE9050/1 Connection BSPP 1/4’’...
  • Page 37 DALì LINER PLUS FOR SANITATION suPer FasT-Clean nOZZle *Cod. Filter Ø inch Ø mm nozzle-angle recom. SFC07-20 0,007’’ 0,18 SFC07-40 200 M SFC09-20 0,009’’ 0,23 SFC09-40 SFC11-20 0,011’’ 0,28 SFC11-40 SFC13-20 SFC NOZZLE SUPER SFC13-40 0,013’’ 0,33 FAST-CLEAN SFC13-60 Yellow (see table) SFC15-20 100 M...

  • Page 38: Zpump For Sanitation

    DALì LINER PLUS FOR SANITATION PUMP FOR SANITATION Giotto Cod. SE9020 220V Cod. SE9021 110V Giotto with gravity hopper da 50 Lt. Cod. SE9022 220V Cod. SE9023 110V Mirò Cod. KSE9080 220 V Cod. KSE9081 110 V Cod. KSE9082 220 V with trolley Cod.
  • Page 39 DALì LINER PLUS FOR SANITATION GHIBLI Cod. SE9000 ZEUS Cod. SE9010 110V Cod. SE9011 220V Cod. SE9012 petrol www.larius.com ED. 1 - 06/2020 - Cod. 150144...

  • Page 41: Ce Declaration Of Conformity

    DALì LINER PLUS FOR SANITATION CE DECLARATION OF CONFORMITY Company LARIUS srl Via Antonio Stoppani 21 - 23801 Calolziocorte (LC) ITALY Tel: +39 0341 621152 Fax: +39 0341 621243 E-mail: larius@larius.com Declares under his owns resonsibility that the product: DALI' LINER PLUS for sanitation complies with the directives: - EC Directive 2006/42 Machinery Directive...
  • Page 42 LARIUS srl Via Antonio Stoppani 21 - 23801 Calolziocorte (LC) ITALY TEL. +39 0341 621152 - Fax +39 0341 621243 - larius@larius.com www.larius.com...
