P6EX-A+ User's Manual
4: Reference Information – 4.6
Name: Function
J17: LAN Wake-up
J18: Modem Wake-up Connects to internal modem for system wake-up
J19: Case Fan power For case-mounted cooling fan power cable
J16: Case Features Connector
1 – 3 4 – 5
Pin 1-3: Power On LED; Pin 4-5: Suspend Switch; Pin 6-8: Suspend LED; Pin
9-10: Reset Switch; Pin 11-12: Keyboard Lock; Pin 13-16: Speaker; Pin 17-18:
Hard Disk LED; Pin 19-20: Power Switch
J16 Pin Assignments
Power LED
1 +
2 +
3 -
Suspend
4 I
5 G
Suspend LED
6 +
7 +
8 -
Reset
9 I
10 G
Description
LAN activity wake-up header
on modem ring
6 – 8 9 – 10 11 – 12 13 – 16 17 – 18 19 – 20
Keyboard Lock
11 I
12 G
Speaker
13 P
14 G
15 G
16 O
HDD LED
17 +
18 -
Power On
19 I
20 G
