P6EX-A+ User's Manual
4: Reference Information – 4.3
Jumper Configuration & Connector Summary
This section lists the jumper setting options for this mainboard
and the onboard connectors. The settings are listed as follows:
• The two pins shorted by a jumper cap on a three-or-more-pin
jumper, e.g. 1-2
or
• For a two-pin jumper, On, if the cap is in place, and Off, if a
cap is not in place.
In the jumper illustrations, the Pin 1 position is shaded and
the jumpers, shown in a "bird's eye" view, look like this:
A jumper with a cap in position looks like this:
The default settings are noted in the summary table.
In practice, for an Off setting
on a two-pin jumper, place
the cap over one pin so that it
doesn't get lost.
