Wayne 331301-001 Operating Instructions Manual

Please read and save these instructions. Read carefully before attempting to assemble, install, operate
or maintain the product described. Protect yourself and others by observing all safety information.
Failure to comply with instructions could result in personal injury and/or property damage! Retain
instructions for future reference.
Operating Instructions
Description
This sewage pump is suitable for
pumping sewage, effluent, wastewater,
groundwater and other nonexplosive,
noncorrosive liquids with up to two inch
solids. The RPP50 pump includes a wide
angle float switch that turns the pump on
and off as the fluid level rises and falls.
The RPPCAP50 is provided with a "Switch
Genius" capacitive water sensor. When
water is detected, the pump will start
automatically. These pumps are intended
for use in domestic sewage lift stations.
Unpacking
Inspect this unit before it is used.
Occasionally, products are damaged
during shipment. If the pump or
components are damaged, return the
unit to the place of purchase for
replacement. Failure to do so could
result in serious injury or death.

Safety Guidelines

This manual contains information that is
very important to know and understand.
This information is provided for SAFETY
and to PREVENT EQUIPMENT PROBLEMS.
To help recognize this information,
observe the following symbols.
Specifications
Power supply requirements
Circuit requirements
Motor duty
Motor
Horsepower
Motor full load
Liquid temperature range
Max. operating position
Dimensions
Intake
Discharge
Cut-in level (factory set)
Cut-out level (factory set)
Differential
Switch
Power cord
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
© 2007 Wayne Water Systems
1/2 HP Cast Iron
Sewage Pump
an imminently hazardous situation
which, if not avoided, will result in
death or serious injury.
a potentially hazardous situation
which, if not avoided, could result in
death or serious injury.
a potentially hazardous situation
which, if not avoided, MAY result in
minor or moderate injury.
important information, that if not
followed, may cause damage to
equipment.
General Safety
Information
CALIFORNIA PROPOSITION 65
or its power cord may contain
chemicals known to the State of
California to cause cancer and birth
defects or other reproductive harm.
Wash hands after handling.
RPP50
120V, 60 hz
15 amps (min)
Intermittent
120V, 1 Phase
1/2
6.3 amps
40°F to 120°F
45 o from vertical
14" x 12"
2"
2" NPT female
16"
7.5"
8.5"
90 o wide angle
mechanical tether switch
18 gauge 3 Conductor
with plug
For parts, product & service information
visit www.waynepumps.com
Danger
indicates
Warning
indicates
Caution
indicates
Notice
indicates
This
product
RPPCAP50
120V, 60 hz
15 amps (min)
Intermittent
120V, 1 Phase
1/2
6.3 amps
40°F to 120°F
45 o from vertical
14" x 12"
2"
2" NPT female
11"
7"
4"
"Switch Genius"
capacitive water sensor
18 gauge 3 Conductor
with plug
Models RPP50 and RPPCAP50
GENERAL SAGETY INFORMATION
1. Know the pump application,
limitations, and po ten tial hazards.
Do not use to pump
flammable or explosive fluids
such as gasoline, fuel oil,
kerosene, etc. Do not use in flammable
and/or explosive atmospheres. Use pump
only with liquids compatible with pump
component materials. Failure to follow
this warning can result in personal
injury and/or property damage.
2. Make certain that the power source
(electric motor) conforms to the
requirements of the equipment.
Disconnect power before
servicing. If the power dis -
con nect is out of sight, lock
in the open po si tion and tag it to
prevent unexpected application of
power. Failure to do so could result in
fatal electrical shock!
3. Release all pressure within the system
before ser vic ing any component.
4. Drain all liquids from the system
before servicing.
contains dielectric motor oil for motor
heat transfer. Care should be taken when
disposing of this oil. Do not use this
pump in ponds or fountains because the
motor oil can be harmful to aquatic life.
5. Secure the discharge line before
starting the pump. An unsecured
discharge line will whip, possibly
Construction
Motor housing.......Cast iron
Volute ....................Cast iron
Impeller...................Glass reinforced PBT
Seal plate ...............Cast Iron
Shaft seal ...............Mechanical
Performance
GALLONS PER HOUR AT TOTAL
HEAD IN FEET
0 5 10
5700 4560 3240
331301-001 12/07
This
pump
15
900
