Wayne 321205-001 Operating Instructions & Parts Manual

operating Instructions & Parts Manual
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.

Table of Contents

Descripion . . . . . . . . . . . . . . . . . . . . . . . .1
Unpacking . . . . . . . . . . . . . . . . . . . . . . .1
Safety .Guidelines . . . . . . . . . . . . . . . . . .1
General .Safety .Information . . . . . . . . .1
Installation . . . . . . . . . . . . . . . . . . . . . . .2
Operation . . . . . . . . . . . . . . . . . . . . . . . .2
Maintenance . . . . . . . . . . . . . . . . . . . . .3
Troubleshooting .Chart . . . . . . . . . . . . . . . . . . . . . . . . . .4
Replacement .Part .Information . . . . . 6-7
Warranty . . . . . . . . . . . . . . . . . . . . . . . . .8
Description
These .self-priming .transfer .pumps .are .
designed .to .easily .transfer .water .from .
one .point .to .another . . .Model .PC1, .12 .
Volt .Transfer .Pump .is .convenient .when .
normal .power .is .not .readily .available . . .
Typical .applications .include .removing .
water .from .pool .covers, .clogged .
drains, .stock .tanks, .water .basins, .boats, .
cisterns, .etc . .Model .PC2, .115 .Volt .
Transfer .Pump .is .great .for .household .
usage . . .Typical .applications .include .
removing .water .from .waterbeds, .
clogged .sinks, .basements, .etc . . .Note: .Do .
NOT .use .PC2 .in .pool .areas . .The .motors .
on .both .models .PC1 .and .PC2 .are .non-
submersible .
© .2008 .Wayne .Water .Systems

Unpacking

Inspect .this .unit .before .it .is .used . .
Occasionally, .products .are .damaged .
during .shipment . .If .the .pump .or .
components .are .damaged, .return .
the .unit .to .the .place .of .purchase .for .
replacement . .Failure .to .do .so .could .
result .in .serious .injury .or .death .
reaD & follow all InSTrUCTIonS
Save TheSe InSTrUCTIonS
Safety Guidelines
This .manual .contains .information .
that .is .very .important .to .know .and .
understand . .This .information .is .
provided .for .SAFETY .and .to .PREVENT .
EQUIPMENT .PROBLEMS . .To .help .
recognize .this .information, .observe .the .
following .symbols .
hazardous situation which, if not
avoided, WILL result in death or serious
injury.
hazardous situation which, if not
avoided, COULD result in death or
serious injury.
hazardous situation which, if not
avoided, MAY result in minor or
moderate injury.
information, that if not followed, may
cause damage to equipment.
noTe: .Information .that .requires .special .
attention .
REMINDER: Keep your dated proof of purchase for warranty purposes!
Attach it to this manual or file it for safekeeping.
For .parts, .product .& .service .information
visit .www.waynepumps.com
Self-Priming
Transfer Pumps
Do noT DISCarD
Danger indicates an
imminently
Warning indicates a
potentially
Caution indicates a
potentially
Notice indicates
important
PC1 and PC2 Series
General Safety Information
CalIfornIa ProPoSITIon 65
This product or
its power cord may
contain chemicals known to the State
of California to cause cancer and birth
defects or other reproductive harm.
Wash hands after handling.
General SafeTy
Do not submerge
motor or allow
motor to be exposed to water. Personal
injury and/or death could result. Keep
pump and power cords away from
liquids. Model PC1 becomes very hot
during operation.
Do not pump gasoline or
other explosive liquids. Do
not operate pump where
flammable or explosive fumes or gases
are present as a fire or explosion could
result. Pump should only be used to
pump clear water. Do not run pump
dry.
1 . . Read .all .instructions .
before .operation .
2 . . . . P rotect .electrical .cord .
from .sharp .objects, .hot .
surfaces, .oil .and .chemicals . . .Avoid .
kinking .the .cord .and .replace .
damaged .cords .immediately .
This pump has been
evaluated for use
with water only.
321205-001 .11/08
