Wayne 330502-001 Operating Instructions And Parts Manual

Operating Instructions and Parts Manual
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Description
A sewage system consists of a pump,
control switch, and a basin for use in
applications where less than six toilets
(units) are discharged into the basin.
The system is generally controlled by a
float switch with a plug-in-plug which
accepts the pump plug and in turn
plugs into a 120 volt outlet.
The float switch is a wide angle
differential switch that rises with the
liquid level and turns the pump on. As
the liquid level decreases the float
lowers and turns the pump off. The
CSECAP40 and CSECAP50 are provided
with a solid-state electronic "Switch-
Genius" water level control. When

Specifications

Power supply requirements
Circuit requirements
Motor duty
Motor
Horsepower
Motor full load
Liquid temperature range
Max. operating position
Dimensions
Intake
Discharge
Cut-in level (factory set)
Cut-out level (factory set)
Differential
Switch
Power cord
REMINDER: Keep your dated proof of purchase for warranty purposes!
© 2007 Wayne Water Systems
Sewage
Pump
water is detected, the pump will start
automatically. This pump is intended
for use in domestic sewage lift stations.
It is suitable for pumping sewage,
effluent, wastewater, groundwater and
other nonexplosive, noncorrosive
liquids with up to 2 inch solids.
Unpacking
Inspect this unit before it is used.
Occasionally, products are damaged
during shipment. If the pump or
components are damaged, return the
unit to the place of purchase for
replacement. Failure to do so could
result in serious injury or death.
CSECAP40
CSE50T CSECAP50
120V, 60 hz 120V, 60 hz
15 amps (min) 15 amps (min)
Intermittent Intermittent
120V, 1 Phase 120V, 1 Phase
1/2 4/10 (CSECAP40)
1/2 (CSECAP50)
12.0 8.7
40°F to 120°F 40°F to 120°F
45 o from vertical 45 o from vertical
14 inches x 12inches 14 inches x 12inches
2 inches 2 inches
2 inch NPT female 2 inch NPT female
19 inches 11 inches
9 inches 3 inches
10 inches 7 inches
90 o wide angle "Switch-Genius"
mechanical capacitive
tether switch water sensor
16 gauge 16 gauge
3 Conductor w/plug 3 Conductor w/plug
Attach it to this manual or file it for safekeeping.
For parts, product & service information
visit www.waynepumps.com
CSECAP40, CSECAP50, CSE50T

Safety Guidelines

This manual contains information that
is very important to know and
understand. This information is
provided for SAFETY and to PREVENT
EQUIPMENT PROBLEMS.
To help recognize this information,
observe the following symbols.
an imminently hazardous situation
which, if not avoided, will result in
death or serious injury.
a potentially hazardous situation
which, if not avoided, COULD result in
death or serious injury.
a potentially hazardous situation
which, if not avoided, MAY result in
minor or moderate injury.
important information, that if not
followed, may cause damage to
equipment.
SAVE THESE INSTRUCTIONS!
Construction
Motor body material .......................Cold rolled steel
Motor housing .................................Cast iron
Volute ...............................................Cast iron
Impeller.............................................Glass reinforced PBT
Seal plate ..........................................Cast Iron
Shaft seal ..........................................Mechanical
Performance
GALLONS PER MINUTE AT TOTAL HEAD IN FEET
Model 5'
CSECAP40 90
CSECAP50, CSE50T 113
Danger
indicates
Warning
indicates
Caution
indicates
Notice
indicates
10' 15'
62 23
90 33
330502-001 11/07
