Operating Instructions and Parts Manual
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or prop-
erty damage! Retain instructions for future reference.
Description
This self-priming portable utility pump
is designed to be used as a transfer
pump for such applications as emptying
water heaters, swimming pools, live-
stock tanks, boats, etc. Pump can also
be used for an intermittent pressure
boost for applications such as washing
cars, cleaning driveways, etc. The motor
is air cooled; it is not designed to oper-
ate under water.
NOTE: This pump is not intended for
permanent installation or long, extend-
ed periods of continuous operation.
Safety Guidelines
This manual contains information that is
very important to know and under-
stand. This information is provided for
SAFETY and to PREVENT EQUIPMENT
PROBLEMS. To help recognize this infor-
mation, observe the following symbols.
Danger indicates
an imminently haz-
ardous situation which, if not avoided,
will result in death or serious injury.
Warning indicates
a potentially haz-
ardous situation which, if not avoided,
could result in death or serious injury.
Caution indicates a
potentially haz-
ardous situation which, if not avoided,
may result in minor or moderate injury.

Specifications

Motor . . . . . . . . . . . . . .Single Phase - 115V, 60 Hz, 8,000 RPM . . . .Horsepower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1/2 HP
Motor . . . . . . . . .Series Wound (brush type) AC/DC Operation . . . .Inlet/Outlet Openings . . . . . . . . . . . . . . . . . . . . . . .3/4" NPT
Impeller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .SAN . . . .Pump Housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Cast iron
Motor Housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Cast iron . . . .Motor Shaft . . . . . . . . . . . . . . . . . . . . . . . .Cold rolled steel
Shaft and Volute Seal . . . . . . . . . . . . . . . . . . . . . . . . . . .Buna-N . . . .Motor Bearings . . . . . . . . . . . . . . . .Permanently lubricated
Maximum Fluid Temperature . . . . . . . . . . . . . . . . . . . . . .120˚F . . . .
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
© 2005 Wayne Water Systems
Self-Priming Portable
Utility Pump
Notice indicates
important informa-
tion, that if not followed, may cause
damage to equipment.
General Safety
Information
Do not submerge
motor or allow
motor to be exposed to water. Personal
injury and/or death could result.
Do not use to pump flam-
mable or explosive fluids
such as gasoline, fuel oil,
kerosene, etc. Do not use
in a flammable and/or explosive atmos-
phere. Pump should only be used to
pump clear water. Personal injury
and/or death could result.
Risk of electrical
shock. All wiring
must be performed by a qualified elec-
trician.
Do not walk on wet
areas until all power is
turned off. Failure to fol-
low this warning could
result in fatal electrical shock.
1. Read all instructions before
operation.
2. Disconnect power and release all
pressure within the system before
servicing any component.
For parts, product & service information
visit www.waynepumps.com
Cast Iron Utility Series
3. Drain all liquids from system before
servicing.
Secure the dis-
charge line before
starting the pump. An unsecured dis-
charge line may whip. Personal injury
and/or property damage could result.
4. Periodically inspect pump and sys-
tem components, checking for
weak and/or worn hoses. Insure all
connections are secure.
5. Provide a means of pressure relief
in the case of an obstructed dis-
charge line.
6. Protect electrical cord from sharp
objects, hot surfaces, oil and chemi-
cals. Avoid kinking the cord and
replace damaged cords immediately.
Installation
Always disconnect power
source before attempting
to install, service, or
maintain the pump. Never
handle a pump with wet hands or
when standing on wet or damp sur-
face or in water. Fatal electrical shock
could occur.
1. A ground fault circuit interrupter
(GFCI) is required.
Risk of electrical shock!
This pump is supplied
with a grounding conduc
