Operating Instructions and Parts Manual
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Description
This submersible sump system is
designed for indoor home sump
applications. The system consists of
a primary sump pump and a back-up
sump pump.
The primary system operates on
120-volt household electric power. It
is equipped with a 3-prong grounding
type power cord. The motor is oil filled
and sealed for cooler running and is
designed to operate under water. The
primary pump is provided with Switch
Genius™ Technology to control the
pump. When water is detected, the
pump will start automatically.
The battery operated back-up sump
pump is included in the event that
the primary pump cannot function. It
does not replace the primary pump.
A float switch automatically turns on
the backup sump pump when water
activates the float. A battery (not
included) must be installed to operate
the back-up sump pump.
Model WSS10 consists of a WSCAP30
primary pump and an ESP15 backup
pump. Model WSS20 consists of a
CDUCAP725 primary pump and an
ESP15 backup pump. Model WSS30
consists of a CDUCAP850 primary pump
and an ESP25 backup
pump.
Unpacking
Inspect this unit before it is used.
Occasionally, products are damaged
during shipment. If the pump or
components are damaged, return
the unit to the place of purchase for
replacement. Failure to do so could
result in serious injury or death.
REMINDER: Keep your dated proof of purchase for warranty purposes!
© 2009 Wayne Water Systems
Submersible Sump
System
Specifications
Power supply
requirements
Motor
Liquid temperature
range
Circuit requirements
Dimensions
Cut-in level
(factory set)
Cut-out level
(factory set)
Construction
Motor
Glass reinforced
thermoplastic ▲ ●
housing
Thermoplastic ▲ ●
Volute
Impeller
Glass reinforced
thermoplastic
Shaft
Stainless steel
Seals
1-1/2 inch NPT ▲
Discharge
1-1/2 inch socket ●
▲ Primary pump
Attach it to this manual or file it for safekeeping.
For parts, product & service information
visit www.waynepumps.com
WSS10
120V, 60 hz ▲
12V DC ●
Single phase, oil
filled ▲
40°F to 120°F
15 amps (min) ▲
11 inches high x
11-1/2 inches high x
9 inches base
9-3/4 inches base
8 inches
Approx. 3 inches
WSS10
WSS20
Cold rolled steel ▲
Glass reinforced
thermoplastic ●
Cast iron ▲
Glass reinforced
thermoplastic ●
Glass reinforced
thermoplastic
Low carbon steel
Buna N
Buna N
1-1/2 inch NPT ▲
1-1/4 inch or
1-1/4 inch or
1-1/2 inch socket ●
● Back-up pump
WSS10, WSS20, WSS30
WSS20
120V, 60 hz ▲
120V, 60 hz ▲
12V DC ●
12V DC ●
Single phase, oil
Single phase, oil
filled ▲
40°F to 120°F
40°F to 120°F
15 amps (min) ▲
15 amps (min) ▲
11-1/2 inches high x
12 inches base
8 inches
Approx. 3 inches
Approx. 3 inches
WSS30
Cold rolled Steel ▲
Glass reinforced
thermoplastic ●
Cast iron ▲
Glass reinforced
thermoplastic ●
Glass reinforced
thermoplastic
Low carbon steel
Buna N
1-1/2 inch NPT ▲
1-1/2 inch socket ●
353501-001 2/09
WSS30
filled ▲
8 inches
