- Page 1 Sample Concentrator operator'S manual Issue 14 10/15...
-
Page 3: Table Of Contents
ContentS page IntroduCtIon Warning Operator safety Specification Installation Diagram of Sample Concentrator Guarantee operatIon Preparation Operation addItIonal InFormatIon User maintenance Solvent evaporation temperatures Diagram of gas chamber Replacement parts... -
Page 4: Introduction
Please read all the information in this user manual before using the Sample Concentrator. The Techne Sample Concentrator has been designed to provide a quick and convenient method of accelerating the concentration by evaporation of solvents from samples prior to analysis. It is designed to ®... -
Page 5: Operator Safety
SaFety advICe beFore uSe operator SaFety All users of Techne equipment must have available the relevant literature needed to ensure their safety. It is important that only suitably instructed personnel operate this equipment, in accordance with the instructions contained in this manual and with proper safety standards and procedures. -
Page 6: Diagram Of Sample Concentrator
2 psi. Pressure in excess of 2 psi will cause gas to be vented and wasted. ® Place the Techne Dri-Block heater onto the base of the Sample Concentrator. It is positioned by means of two spigots on the base board which align with two centrally located screw heads on the ®... -
Page 7: Guarantee
This user’s manual has been prepared solely for the convenience of Techne customers and nothing in this manual shall be taken as a warranty, condition or representation concerning the description,... -
Page 8: Operation
operatIon preparation ® Place the aluminium insert blocks to be used into the Dri-Block unit. The blocks should touch each other and be positioned centrally. Loosen the locking knob on the carriage. Remove the gas chamber, disconnecting the gas pipe if necessary, and lay the chamber upside down on a suitable work surface. - Page 9 FSC400d matrix plate FSC496d matrix plate Press each needle firmly, pointed end first, through the guide holes and through the sealing pad behind so that it is held firmly in position. Build up the desired pattern of needles to suit the arrangement of test tubes to be used.
-
Page 10: Operation
InSertIng the needleS Replace the gas chamber onto the carriage and tighten the locking knob. Re-connect the gas pipe if necessary. proCeSSIng oF SampleS Warning - remember high temperatures are dangerous. The heater, insert blocks, sample vessels, needles and samples may be very hot. Always take the precautions listed earlier in this manual. By turning the carriage handle, on the right hand side, counter clockwise raise the gas chamber to take the needles well away from the heater. -
Page 11: Additional Information
To replace the sealing pad After many repeated needle insertions the self sealing property of the sealing pad may start to degrade. Spare pads can be obtained from your supplier or from Techne. Replacing the pad is simply accomplished as follows: •... -
Page 12: Solvent Evaporation Temperatures
Solvent evaporatIon temperatureS IupaC name Common name boiling point (°C) at pressure (mbar) at 1013 mbar pressure which b.p is 40°C 2-propanone Acetone 1-pentanol Pentyl alcohol Benzene Benzene 1-butanol Butyl alcohol 2-methyl-2-propanol Tert-butyl alcohol Chlorobenzene Chlorobenzene Chloroform Trichloromethane Cyclohexane Cyclohexane Ethoxyethane Diethyl ether Atmospheric... - Page 13 Solvent evaporatIon temperatureS continued IupaC name Common name boiling point (°C) at pressure (mbar) at 1013 mbar pressure which b.p is 40°C Methanol Methyl alcohol Dichloromethane Methylene chloride Atmospheric Pentane Pentane Atmospheric Propan-1-ol Propyl alcohol 1,1,1,2,2-pentachloroethane Pentachloroethane 1,1,2,2-tetrachloroethane Tetrachloroethane 1,1,1 -trichloroethane Trichloroethane Tetrachloromethane Carbon tetrachloride...
-
Page 14: Diagram Of Gas Chamber
dIagram oF gaS Chamber Matrix plate Sealing plate Support strip... -
Page 15: Replacement Parts
The following replacement parts and accessories may be obtained from your supplier or from Techne. Part Number Description F7209 Pack of 100 x 76mm long needles F7210 Pack of 100 x 127mm long needles FSC4NCS Pack of PTFE coated needles, 100 x 76mm long... - Page 16 bibby Scientific - France bibby Scientific uS Bâtiment le Deltaparc Silic pars Nord 2, 3 Terri Lane, 7 rue du Canal, Suite 10, BP 55437 Villepinte, Burlington, 95944 ROISSY Charles de Gaulle, NJ 08016, USA France Tel: +1 609 589 2560 Tel: +33 (0) 1 48 63 78 00 Fax: +1 609 589 2571 Fax: +33 (0) 1 48 63 78 01...
