9. Specifications

Standard Feature
Symbologies
Depth of Field
Characteristics
Dimensions
Weight
Power
Trigger Switch
Light Source
Image Sensor
Interface
Indication
Performance
Resolution
Print Contrast
Scan Rate
Scan Angle
Environment
Light Strength
Temperature
Humidity
Drop
Sealing
Regulatory
Regulatory
Approvals
*ID TECH reserves the right to enhance and modify specifications without
prior notice. Please check with an ID TECH sales representative for most
updated specifications.
UPC-A, UPC-E, EAN-13, EAN-8, Codabar, Code
39 Full ASCII, China Post, Plessey, MSI, Code
93, Code 128,
Industrial 2 of 5, Interleave 2 of 5, Matrix 2 of
5, Code 11, ISBN, ISSN, Code32 (Italian
Pharmcode), Code39
extended, GS1-128 and ITF-14, SISAS, GS1
Omnidirectional, GS1 Limited, Aviation25,
RSS14
25~100mm (Code39, 4mil, PCS90%)
15~330mm (EAN, 13mil, PCS90%)
102mm x 71mm x 177mm
190g
DC5V±1%
>1,000,000 cycles
RED LED 620nm~630nm
2500 point pixel CCD image sensors
USB-HID, USB-Virtual COM
LED, Beeper
3mil (0.76mm)
Min. 20%
>=270 time/s
Yaw±55°, Rotation±30°, Pitch±65°
70,000 Lux
Operating temp.: -20°C to 50°C
Storage temp.: -40°C to 70°C
5% to 95% (Non-condensing)
Withstands multiple times 1.5meters drops to
concrete
IP42
CE, FCC, BSMI
