HC Bridge SRC User Guide
Power Safety
1. The unit is not supplied with a mains lead allowing you to use IEC distribution of mains
cables of your choice. Any mains cable used must fulfil the following:
I. Refer to the ratings label on the rear of the unit and always use suitable mains
cords.
II. The unit should ALWAYS be earthed with the earth on both the IEC sockets (when
both are used).
III. Please use - compliant 60320 C13 TYPE SOCKETS. When connecting to supply
outlets ensure that appropriate sized conductors and plugs are used to suit local
electrical requirements.
IV. Maximum cord length should be 4.5m (15').
V. The cord should bear the approval mark of the country in which it is to be used.
2. The appliance coupler is used as the disconnect device, ensure that it is connected to an
unobstructed wall outlet.
3. The mains inlets are designed for connection to a single phase AC supply however each
inlet can safely be connected to a separate phase of a three phase mains supply.
Warning: if connected to separate phases up to 400V potential phase to phase may be
present.
4. The clear markings regarding redundant power supplies detailed on the unit must be
transferred into the installation to ensure both power sources are removed before qualified
personnel service the unit.
GB The apparatus shall be connected to mains socket outlets with a protective earthing
connection
DEN Apparatets stikprop skal tilsluttes en stikkontakt med jord, som giver forbindelse til
stikproppens jord
FIN
Laite on liitettävä suojamaadoituskoskettimilla va rustettuumpistorasiaan
NOR
Apparatet må tikoples jordet stikkontakt
SWE Apparaten skall anslutas till jordat uttag
ATTENTION! This equipment must be Earthed. Refer to manual for installation
instructions.
CAUTION! Disconnect all power sources before removing any panel (s). No user-
serviceable parts inside – to be serviced only by qualified personnel.
WARNING! Un-Earthed metal parts may be present inside enclosure. Check for
hazardous voltages before touching.
For protection against risk of fire – replace only with same type / rating of fuse. Do
not expose to rain or moisture.
For EU
The stagebox is CE compliant and fully conforms with the current protection requirements
of the European community council directives on EMC and LVD. Note that any cables
supplied with SSL equipment may be fitted with ferrite rings at each end. This is to comply
with the current regulations and these ferrites should not be removed. Any modifications
to this equipment may adversely affect the CE compliance of this product.
