HC Bridge SRC Guida Operativa REVISION: 1.1...
Page 2
As research and development is a continual process, Solid State Logic reserves the right to change the features and specifications described herein without notice or obligation. Solid State Logic cannot be held responsible for any loss or damage arising directly or indirectly from any error or omission in this manual.
Page 3
HC Bridge SRC – Guida Operativa Contents Table of Contents HC Card Reset Introduction Appendix A – Physical Specifications Overview Appendix B - GPIO Connector Pin Outs Key Features GP Inputs HC Bridge SRC Front Panel GP Outputs HC Bridge SRC Rear Panel Status LEDs and User Buttons Appendix C –...
Page 4
Le connessioni dalle gabbie SFP sul retro sono collegate in loop tra le due schede Dante HC per fornire un dispositivo Dante SRC autonomo a 256 canali.. L'HC Bridge SRC contiene anche 12 coppie di GPIO da utilizzare con le console System T collegate. Key Features •...
Page 5
HC Bridge SRC – Guida Operativa Contents Status LEDs and User Buttons LK1 S and LK2 S indicate the NET1 S and NET2 S indicate the current sync status SRC 1 and SRC 2 current sync status of the of the respective HC card:...
Page 6
HC Bridge SRC – Guida Operativa Contents Hardware Connections Mains Power Connections L'HC Bridge comprende alimentatori ridondanti connettori IEC; entrambi gli alimentatori possono alimentare singolarmente l'unità. L'ideale sarebbe collegarli a circuiti di alimentazione separati garantire ridondanza dell'alimentazione CA in ingresso.
Page 7
Una console System T funzionante a 48 kHz sarebbe in grado di instradare l'audio da e verso i dispositivi a 48 kHz. Con un HC Bridge SRC contenente una scheda HC impostata a 96 kHz, sarebbe possibile instradare 256 canali da e verso i dispositivi Dante funzionanti a 96 kHz. Impostando entrambe le schede Dante HC all'interno dell'HC Bridge SRC a 96 kHz, il numero di canali raddoppierebbe a 512.
Page 8
HC Bridge SRC – Guida Operativa Contents Appendices Appendix A – Physical Specifications HC Bridge SRC Height 1RU, 44.5mm (1.75”) Width 483mm (19”) Depth 340mm (13.4”) Weight 4.5kg Power <100W Pag. 8 di 13...
Page 9
HC Bridge SRC – Guida Operativa Contents Appendix B - GPIO Connector Pin Outs GP Inputs Gli ingressi vengono attivati applicando una tensione CA o CC compresa tra 4V e 24V. La corrente assorbita è di circa 10 mA. Durata minima dell'impulso di ingresso 50 mS.
Page 10
HC Bridge SRC – Guida Operativa Contents GP Outputs Tutte le chiusure degli interruttori di uscita avvengono tramite relè DIL. NON utilizzare queste uscite per commutare direttamente carichi capacitivi o reattivi; utilizzare SEMPRE un relè esterno separato con contatti di potenza adeguata.
Page 11
HC Bridge SRC – Guida Operativa Contents Appendix C – Safety Notices General Safety Leggere e conservare questo documento. Rispettare tutte le avvertenze e seguire le istruzioni. Questo apparecchio elettrico non deve essere utilizzato in prossimità di acqua. La pulizia deve essere effettuata solo con panni asciutti o con prodotti compatibili con i dispositivi elettrici, mai quando l'unità...
Page 12
HC Bridge SRC – Guida Operativa Contents Power Safety The unit is not supplied with a mains lead allowing you to use IEC distribution of mains cables of your choice. Any mains cable used must fulfil the following: Fare riferimento all'etichetta dei valori nominali posta sul retro dell'apparecchio e utilizzare sempre cavi di rete adeguati.
Page 13
è stato acquistato il prodotto. RoHS Notice Solid State Logic si è conformata e questo prodotto è conforme alla Direttiva 2011/65/UE dell'Unione Europea sulla restrizione delle sostanze pericolose (RoHS) e alle seguenti sezioni della legge californiana che fanno riferimento alla RoHS, ovvero le sezioni 25214.10, 25214.10.2 e 58012, Health and Safety Code;...
