HC Bridge SRC User Guide
GP Outputs
All output switch closures are via DIL relay.
DO NOT use these outputs to directly switch capacitive or reactive loads; ALWAYS use a separate
external relay with suitable contact rating.
DIL Relay Ratings:
• 100V DC, 125V AC
• 100mA max.
GP Outputs
Connector Type:
Pin
Description
1
Output
1A
14
Output
1B
2
Output
2A
15
Output
2B
3
Output
3A
16
Output
3B
4
Output
4A
17
Output
4B
5
Output
5A
18
Output
5B
6
Output
6A
19
Output
6B
7
Output
7A
20
Output
7B
8
Output
8A
21
Output
8B
9
Output
9A
22
Output
9B
10
Output
10A
23
Output
10B
11
Output
11A
24
Output
11B
12
Output
12A
25
Output
12B
13
+12V Output
25-way D-type Female
Notes:
450 mA maximum
Contents
Page 10 of 13
