THERMO-FINISHER
Wall Mounted Food Finisher
Installation and Operating Manual
Do not operate this equipment unless you have
read and understood the contents of this manual!
Failure to follow the instructions contained in this
manual may result in serious injury or death. This
manual contains important safety information
concerning the maintenance, use, and operation
of this product. If you're unable to understand the
contents of this manual, please bring it to the
attention of your supervisor. Keep this manual in
a safe location for future reference.
TFWM Series
I&W #07.05.250.00
Register your unit online!
See IMPORTANT OWNER INFORMATION
for more information.
No opere este equipo al menos que haya leído y
comprendido el contenido de este manual!
Cualquier falla en el seguimiento de las
instrucciones contenidas en este manual puede
resultar en un serio lesión o muerte. Este manual
contiene importante información sobre seguridad
concerniente al mantenimiento, uso y operación
de este producto. Si usted no puede entender el
contenido de este manual por favor pregunte a su
supervisor. Almacenar este manual en una
localización segura para la referencia futura.
®
© 2010 Hatco Corporation
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hatco THERMO-FINISHER TFWM Series
Summary of Contents for Hatco THERMO-FINISHER TFWM Series
- Page 1 Si usted no puede entender el attention of your supervisor. Keep this manual in contenido de este manual por favor pregunte a su a safe location for future reference. supervisor. Almacenar este manual en una localización segura para la referencia futura. © 2010 Hatco Corporation...
-
Page 2: Table Of Contents
Register your unit! Completing online warranty registration will prevent delay in 24 Hour 7 Day Parts and Service obtaining warranty coverage. Access the Hatco website at Assistance available in the United States www.hatcocorp.com, select the Parts & Service pull-down and Canada by calling (800) 558-0607. -
Page 3: Important Safety Information
This unit has no “user-serviceable” parts. If service is • Do not attempt to repair or replace a damaged power required on this unit, contact an Authorized Hatco Service cord. The cord must be replaced by Hatco, an Agent or contact the Hatco Service Department at 800-558- Authorized Hatco Service Agent, or a person with 0607 or 414-671-6350;... -
Page 4: Model Description
This unit is intended for commercial use only — NOT for countertops. Damage to non-metallic countertop material household use. is not covered under the Hatco warranty. Clean unit daily to avoid malfunctions and maintain Use non-abrasive cleaners on glass and metal surfaces. -
Page 5: Model Designation
Figure 4. Plug Configurations electrician to determine and install the proper voltage NOTE: Receptacle not supplied by Hatco. and size electrical receptacle. NOTE: Specification label located on the side of the unit. See •... -
Page 6: Dimensions
SPECIFICATIONS Dimensions Width Depth Height Footprint Footprint Adjustable Shelf Heights Model (C)* Width (D) Depth (E) TFWM-3900 42-3/16″ 16-9/16″ 18-3/8″ 40-1/2″ 12-1/4″ 2-3/4″, 4-1/2″, and 6-1/4″ (1072 mm) (420 mm) (466 mm) (1027 mm) (311 mm) (70, 115, and 159 mm) TFWM-3939 42-3/16″... -
Page 7: Installation
INSTALLATION General 1. Remove the unit from the carton. Two or more people are required for this step. Thermo-Finisher food finishers are shipped with most ® components installed and ready for operation. The following 2. Remove the information packet. installation instructions must be performed before connecting NOTE: To prevent delay in obtaining warranty coverage, electricity and operating the unit. -
Page 8: Installing A Wall Mounted Unit
INSTALLATION Installing a Wall Mounted Unit 3/16″ Pilot Holes 1/2″ Sheathing Mounting the food finisher on a wall requires special Wall Bracket considerations and procedures due to the weight of the unit. Follow the guidelines below when determining the location for wall mounting as well as during installation. -
Page 9: Operation
NOTICE This unit is designed and recommended for use on metallic countertops. Damage to non-metallic countertop material is not covered under the Hatco warranty. Startup 1. For corded units, make sure the unit is plugged into a properly grounded electrical receptacle of the correct voltage, size and plug configuration. -
Page 10: Maintenance
• Do not attempt to repair or replace a damaged power 6. Inspect the removed air filter and replace with a new filter, cord. The cord must be replaced by Hatco, an if necessary. NOTI E: Never operate the unit without Authorized Hatco Service Agent, or a person with the filter installed. -
Page 11: Troubleshooting Guide
Unit not plugged in. Plug unit into proper power supply. Circuit breaker tripped. Reset circuit breaker. If circuit breaker continues to trip, Contact Authorized Service Agent or Hatco for assistance. POWER ON/OFF (I/0) switch is Contact Authorized Service Agent or Hatco for defective. -
Page 12: Options And Accessories
OPTIONS AND ACCESSORIES Countertop Conversion Kit The countertop conversion kit allows the wall mounted food finisher to be installed on a countertop. Components of the kit include a rear panel and four 4″ (102 mm) legs . Use the following procedure to install the kit. 1. - Page 13 NOTES Form No. TFWMM-0810...
- Page 14 NOTES Form No. TFWMM-0810...
-
Page 15: Hatco Limited Warranty
Hatco’s option, to repair or replacement Drawer Warmer Elements (metal sheathed) using new or refurbished parts or Product by Hatco or a Hatco- authorized service agency (other than where Buyer is located Drawer Warmer Drawer Rollers and Slides... -
Page 16: Authorized Parts Distributors
HATCO AUTHORIzED PARTS DISTRIBUTORS ALABAMA IOWA NEW yORK TExAS Jones McLeod Appl. Svc. Electric Motor Service Co. Acme American Repairs, Inc. GCS Service Birmingham 205-251-0159 Davenport 319-323-1823 Brooklyn 718-456-6544 Fort Worth 800-433-1804 Goodwin Tucker Group Alpro Service Co. Armstrong Repair Service...
