Product Overview; Specifications; Operation; Starting The Trimmer - Toro Flex-Force Power System Operator's Manual

Product Overview

Specifications

Appropriate Temperature Ranges
Charge/store the battery pack
at
Use the battery pack at
Use the trimmer at
Store the trimmer at
*Charging time will increase if you do not charge the
battery within this range.
Store the tool, battery pack, and battery charger in an
enclosed clean, dry area.
5°C (41°F) to 40°C (104°F)*
-30°C (-22°F) to 49°C (120°F)
0°C (32°F) to 49°C (120°F)
0°C (32°F) to 49°C (120°F)*

Operation

Starting the Trimmer

1. Make sure that the vents on the trimmer are
clear of any dust and debris.
1. Trimmer venting areas
2. Align the cavity in the battery pack with the
tongue on the handle housing
3. Push the battery pack into the handle until the
battery locks into the latch
1. Battery latch
4. To start the trimmer, squeeze the lockout trigger,
then squeeze the variable-speed trigger
6).
Note:
Slide the speed range switch to change
the speed of the trimmer.
10
Figure 4
(Figure 5).
(Figure 5).
Figure 5
g293133
g268418
(Figure
