Installing the Guard

Parts needed for this procedure:
1 Guard
Procedure
1. Using the provided Allen wrench, remove the 2 socket head screws, 2 washers, and 2 spacers from the
trimmer base (A of
2. Align the guard onto the trimmer base (B of
3. Secure the guard onto the base of the trimmer with the 2 socket head screws, 2 washers, and 2 spacers
previously removed (C of
4

Installing the Strap

Parts needed for this procedure:
1 String trimmer strap (Not included)
Procedure
If you are using the machine with battery model 81860 or 81875, a string trimmer strap is recommended.
Install the strap according to the assembly instructions provided by the strap manufacturer.
Figure 3).
Figure 2).
Figure 3).
Figure 3
9
g293134
