1
Unfolding the Shaft
Parts needed for this procedure:
1 Allen wrench
Procedure
1. Unfold the shaft (A of
2. Align the locking button on the lower shaft with the slotted hole on the upper shaft and slide the 2 shafts
together (B and C of
Note:
The locking button clicks into the slotted hole when both shafts are secured (D of
3. Using the provided Allen wrench, tighten the screw on the shaft connector until it is secure (E of
Figure 1).
Figure 1).
Figure 1
7
Figure 1).
Figure 1).
g280969
