W04FXO - Quick Installation Guide - English
Aug 14, 2020 18:55
W04FXO - Quick Installation Guide - English
The steps below help you to connect and configure the FXO gateway. Thanks to W04FXO gateway, you
can connect analog lines to your IP PBX, but not only; you can enhance your legacy PBX with Unified
Communications capabilities.
Updated: June 2015
Supported starting from WMS version 2.0.16043.9
Permalink:
https://confluence.wildix.com/x/Vwg8AQ
Read the white paper:
https://drive.google.com/open?id=10kpqi9yJM6gZ7E_YhkmHX6g0pSOTL0KB
Quick Overview
Quick Overview
Rear panel
Reset switch
Power supply
Input: AC100V~240V, 50/60Hz
Output: DC 12V, 1.5A
Network ports
2 Ethernet ports RJ-45, 10/100 base-T
1 WAN port
1 LAN port configured in Bridge
FXO ports
4 analog ports RJ-11
Front panel
1 Power LED indicating that the gateway is powered
1 Status LED indicating that the gateway functions
1 Proxy LED indicating that the gateway is registered on SIP proxy
W04FXO - Quick Installation Guide - English
Page 1 of 4
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wildix W04FXO
Summary of Contents for Wildix W04FXO
- Page 1 W04FXO - Quick Installation Guide - English The steps below help you to connect and configure the FXO gateway. Thanks to W04FXO gateway, you can connect analog lines to your IP PBX, but not only; you can enhance your legacy PBX with Unified Communications capabilities.
