W01/02PRI – Qiuck Installation Guide
The steps below help you to connect and configure your PRI gateway. W01PRI and W02PRI are ISDN VoIP media
gateways offer respectively 30 or 60 voice channels.
Version: January 2015
Connection to power supply
Connection to Ethernet
Connection to power supply
Connect the gateway using the power supply and the cable provided with the PRI gateway, as it is shown on the
picture.
Connection to Ethernet
On the rear panel of the gateway there are five network ports:
ETH5 port: used as WAN port
ETH1 – ETH4: used as LAN port
4/20/2017
1/4
Advertisement
Table of Contents
Related Manuals for Wildix W01PRI
Summary of Contents for Wildix W01PRI
- Page 1 W01/02PRI – Qiuck Installation Guide 4/20/2017 The steps below help you to connect and configure your PRI gateway. W01PRI and W02PRI are ISDN VoIP media gateways offer respectively 30 or 60 voice channels. Version: January 2015 Connection to power supply...
- Page 2 PRI gateway. For remote/unreachable media gateways behind NAT/Firewall, follow our online guide to remote provisioning. Trunk parameters: https://manuals.wildix.com/trunk-settings/#bripri Connection to the line On the rear panel of the gateway, there are one or two modules with an Ethernet port marked as...
- Page 3 E1/T1 (Slot2 and Slot3). Connect your Pri line to this port, as it is shown on the picture below. Reset of the gateway In case you need to reconfigure the gateway, you should perform a reset procedure, as shown on the picture. The switch marked as “Reset/Default”...
