W02/04BRI - Quick Installation Guide - English
Feb 10, 2020 22:24
W02/04BRI - Quick Installation Guide - English
The steps below help you to connect and configure your BRI gateway. W02BRI and W04BRI are ISDN
VoIP media gateways that offer respectively 4 or 8 voice channels.
Updated: June 2015
Permalink:
https://confluence.wildix.com/x/VQg8AQ
Connection to power supply (old generation models without PoE)

Connection to Ethernet

Connection to power supply (old generation models without PoE)
Connect the gateway using the power supply and the cable provided with the gateway, as it is shown on the
picture:
Connection to Ethernet
The network port is situated on the rear panel of the gateway, marked as "
configured in the DHCP client mode.
Connect the cable as it is shown on the picture:
W02/04BRI - Quick Installation Guide - English
Network
". It is used as a WAN port and
Page 1 of 3

Advertisement

loading
Need help?

Need help?

Do you have a question about the W02BRI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Wildix W02BRI

  • Page 1 Feb 10, 2020 22:24 W02/04BRI - Quick Installation Guide - English The steps below help you to connect and configure your BRI gateway. W02BRI and W04BRI are ISDN VoIP media gateways that offer respectively 4 or 8 voice channels. Updated: June 2015 Permalink: https://confluence.wildix.com/x/VQg8AQ...
  • Page 2 W02/04BRI - Quick Installation Guide - English The gateway should be connected via Ethernet cable to the same network as the PBX or an external DHCP server (for instance its Router) As soon as the DHCP server assigns an IP address to the gateway, you can pass to the next step of the gateway configuration You should connect to the PBX in order to configure the gateway In case the PBX is used as a DHCP server, the gateway is detected on the network automatically...
  • Page 3 W02/04BRI - Quick Installation Guide - English In case you need to reconfigure the BRI gateway, you should perform a reset procedure, as shown on the picture. The switch marked as “ Reset/Default ” is situated on the rear panel of the gateway. Use the paper clip or the object of the similar shape to press the button Hold the button until all the LEDs of the gateway stop blinking and remain turned on (circa 10 seconds) Release the button and wait for the reboot of the gateway...
